Image Controls (Analog input only)
Image Controls (Analog input only)
LEFT / RIGHT
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
Controls Vertical Image Position within the display area of the LCD.
H.SIZE
H.SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
Improves focus, clarity and image stability by increasing or decreasing this setting.
Colour Control System
Colour Control System
Colour Control System: Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are
Colour Control System:
Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are
standard and cannot be changed).
standard and cannot be changed).
R,G,B: Increases or decreases Red, Green or Blue colour depending upon which is selected.
R,G,B:
Increases or decreases Red, Green or Blue colour depending upon which is selected. The change in colour
will appear on screen and the direction (increase or decrease) will be shown by the bars.
will appear on screen and the direction (increase or decrease) will be shown by the bars.
NATIVE:
NATIVE: Original colour presented by the LCD panel that is unadjustable.
Original colour presented by the LCD panel that is unadjustable.
sRGB: sRGB mode dramatically improves the colour fidelity in the desktop environment by a single standard RGB
sRGB:
sRGB mode dramatically improves the colour fidelity in the desktop environment by a single standard RGB
colour space. With this colour supported environment, the operator could easily and confidently communicate colour
colour space. With this colour supported environment, the operator could easily and confidently communicate colour
without further colour management overhead in the most common situations.
without further colour management overhead in the most common situations.
NOTE: When MOVIE, GAMING, or PHOTO is selected as the DV MODE, NATIVE is selected automatically as the six
NOTE:
When MOVIE, GAMING, or PHOTO is selected as the DV MODE, NATIVE is selected automatically as the six
colour preset and cannot be changed.
colour preset and cannot be changed.
Tools
Tools
SHARPNESS:
SHARPNESS: Adjust the image to get distinct or as soft a picture as is preferred.
Adjust the image to get distinct or as soft a picture as is preferred.
EXPANSION: Selects the zoom mode.
EXPANSION:
Selects the zoom mode.
FULL: The image is expanded to 1680 x 1050, regardless of the resolution.
FULL:
The image is expanded to 1680 x 1050, regardless of the resolution.
ASPECT:
ASPECT: The image is expanded without changing the aspect ratio.
The image is expanded without changing the aspect ratio.
OFF:
OFF: The image is not expanded.
The image is not expanded.
NOTE: EXPANSION is available only resolution under 1280 x 1024.
NOTE:
EXPANSION is available only resolution under 1280 x 1024.
OFF TIMER:
OFF TIMER: Monitor will automatically power-down when the end user has selected a predetermined amount of
Monitor will automatically power-down when the end user has selected a predetermined amount of
time.
time.
LED BRIGHTNESS:
LED BRIGHTNESS: You can adjust the Blue LED brightness.
You can adjust the Blue LED brightness.
HOT KEY:
HOT KEY: You can adjust the brightness and contrast directly. When this function is set to ON, you can adjust the
You can adjust the brightness and contrast directly. When this function is set to ON, you can adjust the
brightness with left or right control and contrast with up or down control while the OSM menu is off.
brightness with left or right control and contrast with up or down control while the OSM menu is off.
FA
FACTORY PR
CTORY PRESET:
ESET: Selecting Factory Preset allows you to reset all OSM control settings back to the factory
Selecting Factory Preset allows you to reset all OSM control settings back to the factory
settings. The RESET button will need to be held down for several seconds to take effect. Individual settings can be
settings. The RESET button will need to be held down for several seconds to take effect. Individual settings can be
reset by highlighting the control to be reset and pressing the RESET button.
reset by highlighting the control to be reset and pressing the RESET button.
Menu Tools
Menu Tools
LANGUAGE: OSM control menus are available in eight languages.
LANGUAGE:
OSM control menus are available in eight languages.
OSM LEFT/RIGHT: You can choose where you would like the OSM control image to appear horizontally on your
OSM LEFT/RIGHT:
You can choose where you would like the OSM control image to appear horizontally on your
screen.
screen.
OSM DOWN/UP: You can choose where you would like the OSM control image to appear vertically on your screen.
OSM DOWN/UP:
You can choose where you would like the OSM control image to appear vertically on your screen.
OSM Turn Off:
OSM Turn Off: The OSM control menu will stay on as long as it is in use. In the OSM Turn Off submenu, you can
The OSM control menu will stay on as long as it is in use. In the OSM Turn Off submenu, you can
select how long the monitor waits after the last touch of a button to shut off the OSM control menu.
select how long the monitor waits after the last touch of a button to shut off the OSM control menu.
OSM Lock Out: This control completely locks out access to all
OSM Lock Out:
This control completely locks out access to all OSM control functions without Brightness and
Contrast. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the
Contrast. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the
OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then right control button and
OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then right control button and
hold down simultaneously. To deactivate the OSM Lock Out, press SELECT, then left control button and hold down
hold down simultaneously. To deactivate the OSM Lock Out, press SELECT, then left control button and hold down
simultaneously while in the OSM menu.
simultaneously while in the OSM menu.
RESOLUTION NOTIFIER:
RESOLUTION NOTIFIER: This optimal resolution is 1680 x 1050.
This optimal resolution is 1680 x 1050. If ON is
screen after 30 seconds, notifying you that the resolution is not at 1680 x 1050.
screen after 30 seconds, notifying you that the resolution is not at 1680 x 1050.
OSM control functions without Brightness and
If ON is selected, a message will appear on the
selected, a message will appear on the
English-9
