NOTE: This manual contains only a general description of the products shown. While uses and performance capabilities are
described, under no circumstances shall the products be used by untrained or unqualified individuals and not until the product
instructions including any warnings or cautions provided have been thoroughly read and understood. Only these instructions
contain the complete and detailed information concerning proper use and care of these products.
For information on availability outside the US, contact your local MSA representative.
3

Description

3.1

Overview and Description of the Thermal Imaging Camera

Figure 3 The EVOLUTION 6000 camera
All EVOLUTION 6000 Series Thermal Imaging Cameras are:
• equipped with a 320 x 240 uncooled microbolometer heat sensor which provides clear, high resolution images
• equipped with a large screen, high definition display
• equipped with a built-in flashlight and laser pointer
• dustproof and waterproof for short periods submerged under water up to a depth of 3 feet (1 m) corresponding to IP 67
• able to be configured through a desktop PC through our FireService Utility software
• available with multiple carrying and attachment options
In addition to the above features, the EVOLUTION 6000+ TIC:
• features a 2X/4X digital zoom feature
• is equipped with up to five user-selectable palettes in addition to standard "white-hot" imagery
• includes a solid state compass to aid in navigation
• offers an optional laser range finder to accurately measure distances (replaces flashlight and laserpointer if selected)
• able to be configured on the camera or through a desktop PC using MSA's FireService Utility software
Our most advanced camera, the EVOLUTION 6000X TIC, offers all of the above and also includes:
• a fully integrated video recording system with USB download capability
• the ability to snap, store and download still pictures through the integrated USB connection
