- Page 1 cc cc USER MANUAL X-RIDE X-RIDE...
- Page 2 Congratulations ! You are the happy new owner of a MASH which embodies a new spirit, a new trend : a motorcycle with a look and a philosophy «Vintage», synonymous of freedom. Please read this manual thoroughly before using your MASH.
- Page 3 Important Cautions About running-in of a motorcycle The first 1000 km operation is very important in the entire service life of a motorcycle. A correct running-in can guarantee both the longest service life and the best performance of the vehicle. Running-in can polish machined surfaces and form smooth engagement.
-
Page 4: Table Of Contents
Observing the following recommendations will ensure the reliability of your motorcycle and prolong its life. The staff of MASH authorized dealers (list available by consulting the website www.mash-motors.fr) have the skills and technical qualifications required to carry out maintenance and provide quality service. -
Page 5: I Main Technical Data
I - Main Technical Data Mash X-Ride 50cc Euro 5 Engine Type Single cylinder 4T, air cooled Engine Capacity 49 cc Compression Ratio 9.0 : 1 Idle speed 1500±100RPM Power max 2.8 hp at 7000 rpm (2.1kW) Torque max. 2,7 Nm at 5000 rpm... -
Page 6: User Instruction
II - User Instruction Preparation before use • Read the user manual carefully This user’s manual describes the standard and safety method as well as basic • Maintain and check the vehicle before using it maintenance. Read it carefully. • It is necessary to have the driving license corresponding to your vehicle and that The images and illustrations in this manual may differ from those of your vehicle, if it is insured... -
Page 7: Installation Position Of Parts
Battery and 8. Engine Light fuse box Lights up in case of engine malfunction. If this light comes on, you must visit an authorized Mash dealer for diagnosis.. 9. Gear indicator 10. Neutral indicator: Illuminates when in neutral Front Footrests... -
Page 8: Ignition Switch
11. Kilometers/Miles setting: Ignition OFF, press and hold the “info” switch, then turn the key to ON (keeping the info key pressed). keeping the info key pressed). When the display is on, release the “info” switch. A short pulse (minus 1 second) will switch from kms to miles. A long impulse (3 seconds) will select “Sensor”... -
Page 9: Control System
V - Control system Right handlebar control system Left handlebar control system Electric starter button Press this button to start the engine. Dimmer switch Caution Press the button, using the switch allows Make sure that the vehicle is always in you to choose the distance of the headlights : neutral position (N or 0) and always operate high or low. -
Page 10: Essentials Of Driving
VI - Essentials of driving Caution Make sure that the vehicle is always in neutral position (N or 0) and always Fuel tank cap operate the clutch lever before starting the engine To open the fuel tank cap, insert the key and To start the engine turn it clockwise. - Page 11 • Always start the vehicle first and start as gently and carefully as possible. If you park the motorcycle on a slope, stop it uphill to prevent it from • If you hear any abnormal noise while driving, contact a MASH dealer to have descending.
-
Page 12: Controls And Setting
VII - Controls and setting Parking and using the steering lock Place the motorcycle on level ground and put on the side stand. Running-in Then turn the handlebars to the stop on the left side and position the key switch in The importance of a good running-in of the new vehicle has been stressed in the the steering lock position (padlock logo). - Page 13 Lubricant Pre-ride inspection By using a high quality lubricant suitable for a four stroke engine, you will extend Before road, remember to check the following points. Never underestimate the the life of your engine. Please select the type of high quality IPONE SAE10W40 importance of inspection.
- Page 14 First turns of the wheel with the motorcycle Caution Start the engine with the transmission in neutral, the clutch engaged and the rider in the normal driving position. Pass a gear report Press down firmly on the clutch grip, wait a brief moment, lower the selector to engage first gear, gently turn the throttle toward you and slowly and smoothly release the clutch lever.
-
Page 15: Inspection And Maintenance
Perform periodic maintenance in strict accordance with the instructions given in this manual. Please note that the service interval is 3000 kms. Do not forget to certify them in the maintenance sheets of the warranty booklet provided by your MASH dealer. Back to summary... - Page 16 * Steering, bearings * Exhaust and top engine mounting screws Legend: I: Carry out an inspection, cleaning, adjustment, tightening, lubrication or replacement. N: Cleaning. R: Replacement. S: Tightening * This item should be serviced by a MASH dealer Back to summary...
- Page 17 Respect the polarity of the battery by connecting the red wire to the positive (+) Spark plug terminal and the black wire to the negative (-) terminal. Improper connection will After driving the first 1000 km, then every 3000 km, clean the carbon deposits from damage the charging system and the battery.
- Page 18 Engine oil Brakes The longevity of the engine depends on the quality of the oil used, the frequency The front brake is equipped with a disc. Check the brakes after the first 1000 km, of its replacement and the checking of the oil level. then every 3000 km.
- Page 19 Once the position has been adjusted, lock it using the lock nut (2). Please maintain The proper functioning of the brakes is essential for driving safety. Have the brake system periodically inspected by your authorized MASH dealer. a clearance of between 10 and 20 mm (3).
- Page 20 / fuel mixture. Prohibition and inability to adjust the injection system. Therefore, it is not possible and strictly forbidden to adjust the motorcycle’s injection system. If the EFI warning light on the meter comes on, you must go to an authorized Mash dealer in Caution order to carry out a diagnosis.
- Page 21 Adjusting the play of the throttle cable Adjusting the transmission chain 1. Loosen the lock nut. To adjust: 2. Turn the nut so that the cable play is between 0.5 1. Secure the motorcycle on its side stand or center stand (if equipped). and 1.0 mm.
- Page 22 Tires Storage and cleaning Check the tire pressure and their tread after the first 1000 km, then every 3000 Prolonged non-use of the motorcycle during winter or another season requires specific operations requiring suitable materials, equipment and techniques. km. In addition to periodic checks, get in the habit of checking tire pressure from time to time to prolong tire life and ensure maximum safety.
- Page 23 2. Remove the spark plug; press the starter to let the engine run for a few moments Cleaning : before reinstalling the spark plug. Cleaners that are too acidic or aggressive are not recommended for washing the 3. Replace the battery. Note: Do not forget to connect the positive pole before the motorcycle.
- Page 25 Copyright in this manual and its ultimate interpretation is ours. Under no circumstances may this document or any part of it be reproduced or cited without our prior written permission. All information, descriptions, illustrations and specifications contained herein reflect the state of our knowledge at the time of publication. However, we reserve the right to modify this manual at any time in the event of improvements or other changes.
- Page 27 Trouvez votre revendeur JOIN US ON SOCIAL NETWORKS: @MASH_MOTORCYCLES @MASHMOTORCYCLES @MASH MOTORS FRANCE Mash préconise...
