Technical Documentation
Combustion parameters
Supply pressure
Gas nozzle diameter
Flue flow rate at nominal heat output
Flue flow rate at min heat output
CO at Nom Q./Min.
2
CO with 0% O at Nom Q /Min.
2
NO with 0% O at Nom Q /Min.
X 2
Flue temperature at nominal output
Flue temperature at minimum output
Variable heat power
HEAT HEAT
OUTPUT OUTPUT
(kW) (kcal/h)
26.0 22360
25.0 21500 D.H.W.
24.0 20640
23.6 20253
22.0 18920
21.0 18060
20.0 17200
19.0 16340
18.0 15480
17.0 14620
16.0 13760
15.0 12900
CEN.
14.0 12040
HEAT.
13.0 11180
12.0 10320
D.H.W.
11.0 9460
10.0 8600
9.0 7740
8.0 6880
7.0 6020
6.0 5160
5.0 4300
4.0 3440
3.0 2580
- Flue temperature values refer to an air inlet temperature of 15°C.
- The data relevant to domestic hot water performance refer to a
dynamic inlet pressure of 2 bar and an inlet temperature of 15°C;
the values are measured directly at the boiler outlet considering that
to obtain the data declared mixing with cold water is necessary.
- The max. sound level emitted during boiler operation is < 55dBA.
STHSC ed 0710
METHANE (G20)
BURNER GAS PRESS. NOZZLES
FLOW RATE PRESSURE
(m /h) (mbar) (mm H
3
2.85 5.80
2.74 5.39
2.62 4.99
2.57 4.82
2.40 4.25
2.29 3.91
2.18 3.58
2.07 3.27
1.96 2.98
1.86 2.70
1.75 2.43
1.64 2.18
1.54 1.94
1.43 1.71
+
1.32 1.50
1.21 1.31
1.11 1.12
1.00 0.95
0.89 0.79
0.78 0.65
0.67 0.51
0.56 0.40
0.45 0.29
0.34 0.20
G20
mbar (mm H O) 20 (204)
2
mm 5,60
kg/h 42
kg/h 5
% 9,50 / 9,00
ppm 235 / 3
mg/kWh 44 / 12
°C 62
°C 49
BUTANE (G30)
BURNER GAS PRESS. NOZZLES
FLOW RATE PRESSURE
O) (kg/h) (mbar)
2
59.1 2.13 5.85
54.9 2.04 5.43
50.9 1.96 5.03
49.1 1.92 4.86
43.4 1.79 4.29
39.9 1.71 3.94
36.6 1.63 3.61
33.4 1.55 3.29
30.4 1.47 2.99
27.5 1.39 2.71
24.8 1.31 2.44
22.2 1.23 2.18
19.8 1.15 1.94
17.5 1.07 1.71
15.3 0.99 1.49
13.3 0.91 1.29
11.4 0.83 1.10
9.7 0.75 0.93
8.1 0.66 0.76
6.6 0.58 0.61
5.2 0.50 0.48
4.0 0.42 0.35
3.0 0.34 0.25
2.0 0.25 0.15
The sound level value is referred to semianechoic chamber tests
with boiler operating at max. heat output, with extension of flue
gas exhaust system according to product standards.
54
Technical Documentation
G30
29 (296) 37 (377)
4,00
38
5
12,30 / 11,80 10,60 / 10,10
680 / 4
148 / 26
68
54
PROPANE (G31)
BURNER GAS PRESS. NOZZLES
FLOW RATE PRESSURE
(mm H O) (kg/h) (mbar)
2
59.7 2.09 7.61
55.4 2.01 7.08
51.3 1.93 6.56
49.5 1.89 6.34
43.7 1.76 5.61
40.2 1.68 5.16
36.8 1.60 4.74
33.6 1.52 4.33
30.5 1.44 3.94
27.6 1.36 3.58
24.8 1.28 3.23
22.2 1.21 2.89
19.7 1.13 2.58
17.4 1.05 2.28
15.2 0.97 2.00
13.2 0.89 1.73
11.2 0.81 1.48
9.4 0.73 1.25
7.8 0.65 1.03
6.3 0.57 0.83
4.9 0.49 0.65
3.6 0.41 0.48
2.5 0.33 0.33
1.5 0.25 0.20
HERCULES Solar 26 1A
G31
4,00
43
5
220 / 4
35 / 13
62
49
(mm H O)
2
77.6
72.2
66.9
64.7
57.2
52.7
48.3
44.2
40.2
36.5
32.9
29.5
26.3
23.2
20.4
17.7
15.1
12.7
10.5
8.5
6.6
4.9
3.4
2.0
