PORTABLE AIR CONDITIONER (LOCAL)
ZORI
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
V 11/21
24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZORI and is the answer not in the manual?

Questions and answers

Related Manuals for Argo ZORI

Summary of Contents for Argo ZORI

  • Page 1 PORTABLE AIR CONDITIONER (LOCAL) ZORI OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 Appliance is filled with flammable gas R290. Before installing and using the appliance, read the owner manual. Before installing the appliance, read the installation manual. Any repairs you need, contact the nearest authorized Service Centre and strictly follow manufacturer’s Service Manual. The Refrigerant R290 ...
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a local air conditioner designed for domestic use.  Only use this air-conditioner as described in this manual.  Ensure that the required voltage and frequency 220-240V~ / 50 Hz. match the available power source. ...
  • Page 4  Do not install the air conditioner in rooms where it may receive water splashes (e.g. laundry rooms).  Before moving or cleaning the device, ensure that it is unplugged from the socket.  Do not move the air conditioner while it is operating; first turn the appliance off, check for any condensate build-up and empty it if necessary.
  • Page 5 WARNING!  The air conditioner must be positioned at least 50 cm from the wall or any other obstacles, on a flat and stable surface so as to avoid water leaks.  The air conditioner is fitted with a system for protecting the compressor from overload.

  • Page 6: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE FRONT VIEW REAR VIEW CONTROL PANEL AND FUNCTION BUTTONS AIR EXPULSION HOSE WITHOUT REMOTE CONTROL REAR CLIP HORIZONTAL FINS POWER CORD WHEELS CORD HOOK AIR FILTER 10) REMOTE CONTROL AIR EXPULSION HOSE END FITTING Min/max operating limits (internal temperature) Cooling: 16 °C DB / 35 °C DB Dehumidification: 16 °C DB / 35 °C DB Cooling mode room temperature adjustment range: 16 °C DB / 30 °C DB...

  • Page 7: Appliance Start-Up

    Before starting the appliance, press "PUSH" on the air delivery flap to manually open the flaps. To optimize the air flow, it is advisable to keep the air delivery flaps completely open during operation. PRE-OPERATING CHECKS AND OPERATIONS The following space must be maintained to ensure the operating efficiency of the portable air conditioner. APPLIANCE START-UP Open the packaging and remove the box from above.
  • Page 8 Flat fitting for positioning between the air discharge Hose outlet and the hose Cord winder Screws Drain hose Round fitting for window unit, Window unit kit (3 pcs) to be positioned between the Window unit (B) Cap (C) A+B+C end of the tube and the window unit (A) Position the product vertically on a flat and stable surface, as close as possible to a window and at least 50 cm from walls or other nearby obstacles.
  • Page 9 USE WITH END FITTING FOR WINDOW Connect the flat fitting to the hose, extend the hose as far Next, slide the flat fitting downwards into the grooves (B) and as necessary for reaching the outside and it connect to secure it with the hook (A). the back of the air conditioner.
  • Page 10 6. Slide the flat fitting downwards into the grooves (B) and Insert the flat fitting onto the hose. secure it with the hook (A). The outlet must be between 40 cm and 130 cm above the ground. Avoid tight curves or bends in the flexible hose 8.

  • Page 11: How To Use The Appliance

    HOW TO USE THE APPLIANCE This appliance can be used for cooling, dehumidifying and ventilating. When switching between modes, the fan continues to rotate but the compressor stops: the compressor will start after 3 minutes. This delay protects the compressor from potential damage. Cooling, Fan Dehumidifying THE DISCHARGE TUBE MUST ALWAYS BE CONNECTED to the appliance: the only exception is when the...
  • Page 12 HOW TO ELIMINATE CONDENSATE This appliance automatically vaporises condensate in the cooling mode. When the air conditioner operates in cooling mode, there is no need to drain condensate continuously; only in certain weather conditions with very humid air may it occur that water deposits inside the unit. When its inner tank is full, the air conditioner beeps 8 times and the message "H8"...
  • Page 13 1. Remove the continuous drain cap by turning it 2. Remove the rubber plug counter clockwise 3. Insert the drainage hose into drain connector Avoid bends in the drainage tube. V 11/21...

  • Page 14: Remote Control Operation

    REMOTE CONTROL OPERATION 1. Press the tab positioned on the back side of remote controller to remove the cover along the arrow direction 2. Insert the batteries (AAA, LR03, 1,5V - supplied) into the remote control, respecting the polarity indicated. 3.
  • Page 15 FOR OPTIMUM OPERATION OF THE REMOTE CONTROL, ADDRESS THE TRANSMITTER HEAD TOWARDS THE RECEIVER LOCATED ON THE AIR CONDITIONER. To operate the remote control, press the ON / OFF button on the handset. The icon on the remote control display will flash once and you will hear a sound signal indicating that the signal has been sent to the air conditioner.
  • Page 16 ON/OFF BUTTON Press this button to switch the unit on or off. When switched on, the device will emit an audible signal and will begin to operate according to the latest settings (Memory function). MODE SELECTION BUTTON (MODE) (on remote control and on the unit) Press this button to select the various operating modes, according to the following sequence: Cool ->...

  • Page 17: Safety Functions

    TIMER BUTTON (on both the remote control and portable unit) Press this button for 1 second to set the timer. 1） Timer-on (automatic switch on) When the appliance is off, set the time after which you want to turn on the unit. Press the + or - buttons to set the ignition interval (each press corresponds to 0.5 hours) up to 10 hours.

  • Page 18: Care And Maintenance

    CARE AND MAINTENANCE WARNING! Prior to carrying out any cleaning or maintenance, unplug the unit from the power socket. 1. Cleaning the air filters The air conditioner is equipped with two filters, one rear and one side. The air filters must be checked at least once every two weeks of operation.
  • Page 19 TIPS FOR MAXIMISING COMFORT AND MINIMISING CONSUMPTION CHECK that:  the unit's extraction and delivery grilles are always unobstructed;  the air filters are always clean: a dirty filter will decrease the passage of air and thus reduce the unit performance;...
  • Page 20 Specialist’s Manual Aptitude requirement for maintenance man (repairs. should be done only be specialists). a) Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specifìcation.
  • Page 21 ---lf an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant; ---Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected; ---Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded.
  • Page 22 Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chiarine shall be avoided as the chiarine may react with the refrigerant and corrode the copper pipe-work. If a leak is suspected, all naked flames shall be removed/extinguished. If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by means of shut off valves) in a part of the system remote from the leak.
  • Page 23 k. Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked. Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and signed. For appliances containing flammable refrigerants, ensure that there are labels on the equipment stating the equipment contains flammable refrigerant.
