Summary of Contents for Artesian Spas ISLAND SPAS ELITE Series

  • Page 3: Certificate Of Authenticity

    Thank you for your purchase. This certificate hereby verifies that the spa you have purchased from an Artesian Spas (May Manufacturing, LLC) authorized dealer is authentic, brand new and original. The spa has been crafted and built in the U.S.A in accordance with industry quality standards.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Certificate of Authenticity..........Important Safety Instructions........Electrical Requirements and Installation..... Codes and Compliance........Electrical Wiring............. 60 Hz GFCI Wiring Schematic......50 Hz Residential Wiring Schematic..... 50 Hz Island Elite Spas Single/Dual/Three Phase Spa Start Up..............Selecting a Location..........Inspection..............
  • Page 6 Draining Your Spa..........Pillow Care............Jet Care............Removing, Installing and Cleaning Filters..Winterizing Your Spa........Spa Cabinet Care..........Cleaning Your Spa Interior....... Cover Care............Chemical Treatment of Water......Artesian Spas Island Elite Warranty....... Artesian Spas Island Elite Parts List & Diagram...

  • Page 7: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS PLEASE TAKE THE TIME TO READ ALL OF THESE WARNINGS AND CAUTIONS PRIOR TO USING YOUR SPA. PLEASE, be a responsible spa owner. When installing and using this spa, always adhere to basic safety precautions. Be sure to list emergency tele- phone numbers at the telephone nearest the spa, including physician, hospital, ambulance, police, and the fire department.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS 7. DANGER - Risk of Electric Shock - Do not permit any electrical ap- pliance such as a light, telephone, radio, or television, within 5 feet (1.5m) of a spa. 8. WARNING - To reduce the risk of injury: a) The water in a spa should never exceed 40ºC (104ºF).
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS 4. DANGER- Risk of Electric Shock. Do not permit any electric appliance, such as a light, telephone, radio, or television, within 5 feet (1.5m) of a spa or hot tub. 5. WARNING - Risk of Electric Shock. Install at least 5 feet (1.5m) from inside wall of hot tub or spa using nonmetallic plumbing.
  • Page 10 IMPORTANT SAFETY INSTRUCTIONS Marking for equipment assemblies WARNING REDUCE THE RISK OF ELECTROCUTION Install at least 5 feet from water using nonmettalic plumbing. Do not install under spa skirt or within an enclosure that would restrict ventilation. If blower is included, install at least 1 foot above maximum water level. REDUCE THE RISK OF CHILD DROWING 1.
  • Page 11 IMPORTANT SAFETY INSTRUCTIONS 7. When the power supply connections or power supply cord(s) are dam- aged: if water is entering the audio/video compartment or any electrical equipment compartment area; if the protective shields or barriers are showing signs of deterioration; or if there are signs of other potential dam- age to the unit, turn off the unit and refer serviceing to qualified service personnel.

  • Page 12: Electrical Requirements And Installation

    ELECTRICAL REQUIREMENTS AND INSTALLATION The following information is provided for hooking up electrical supply to your new spa. A qualified, licensed, electrician must perform this work. Failure to follow these instructions will terminate all warranty coverage and can cause serious injury or death. Codes and Compliance North American 60 Hz 5X/6X JETS 3/4 PUMPS Voltage...
  • Page 13 6) Connect the power to the spa Connect each color to its respective terminal block location. The Ground (green) wire must be connected to the grounding terminal which is outside of the System box. The Grounding wire must first enter the system box and then access the grounding terminal via a hole on the side of the box adjacent to the grounding terminal as shown in the picture above.

  • Page 14: 60 Hz Gfci Wiring Schematic

    60 Hz GFCI WIRING SCHEMATIC 240 Volt Residential Wiring Schematic with G.F.C.I. House Breaker Box G.F.C.I. Breaker Box Red (Hot) White Spa System Box Green Green White Red Hot Red Hot White Green Black Outside Ground Rod Red Hot Green Green Ground Wire to Ground Bar Black White...

  • Page 15: 50 Hz Residential Wiring Schematic

    50 Hz RESIDENTIAL WIRING SCHEMATIC 230 Volt/50 Hz Residential Wiring Schematic with 2 Pole RCD Breaker Box 230 VAC House Breaker Box RCD Breaker Box Blue (Neutral) Blue (Neutral) Brown (Hot) Green Green Spa System Box Yellow Yellow (Ground) (Ground) Brown Green Outside Ground Rod...

  • Page 16: 50 Hz Island Elite Spas Single/Dual/Three Phase

    PHASE 50 Hz ISLAND ELITE SPAS SINGLE/DUAL/THREE Single Service, TN and TT Electrical Systems (1 X 16 Amp or 1 X 32 Amp) 3 Wires (1 Line + 1 Neutral + 1 Protective Earth) Protective Earth wire (Green / Yellow) must be connected to system ground terminal as marked.
  • Page 17 50 Hz ISLAND ELITE SPAS SINGLE/DUAL/THREE PHA SE 3-Phase Service, TN and TT Electrical Systems (3 x 16 Amp) 5 Wires (3 Lines + 1 Neutral + 1 Protective Earth) Protective Earth wire (Green / Yellow) must be connected to system ground terminal as marked.

  • Page 18: Spa Start Up

    SPA START-UP Please read each step of the Start-up section prior to doing the step. SELECTING A LOCATION In preparation for installing your new Artesian spa, you should ensure that your chosen location meets some minimum guidelines: 1) Place your spa on a surface that is large enough for the entire spa to fit.

  • Page 19: Inspection

    SPA START-UP INSPECTION You will want to inspect your spa, prior to filling it up with water. Look for and remove any debris in the spa tub and in the filter. Verify that pump plugs are installed on the pumps and the pump unions are tight. FILLING THE SPA WITH WATER NOTE: DO NOT fill your spa with hot water straight out of your water heater or tap.

  • Page 20: Turning The Power On

    SPA START-UP FILLING THE SPA WITH WATER 5) Once the water level is filled over the foot-well, you can pull the hose out of the filter line and continue filling the spa from the filter well. 6) Fill the spa to the bottom of the pillows. NOTE: DO NOT OVER-FILL YOUR TUB! 7) With the front panel off, verify there are no leaks at the pump union.

  • Page 21: Priming The Pump

    SPA START-UP NOTE: When power is turned on, your spa is automatically pro- grammed to start circulating water through the circulation pump. Each pump and/or blower will come on consecutively for approxi- mately 1 minute to automatically purge the system. Adjust your tem- perature by pressing the up button on your touch pad until the de- sired temperature is displayed.

  • Page 22: Topside Controller Instructions

    TOPSIDE CONTROLLER INSTRUCTIONS UP AND DOWN SPA OPERATION BUTTONS MAIN BUTTONS MENU SCREEN LIGHT BUTTON BUTTON TOPSIDE CONTROLLER SPEED CONTROL PUMP BUTTON AIR VENTURI DIRECT FLOW CONTROLLER...

  • Page 23: The Main Screen

    THE MAIN SCREEN Important information about spa operation can be seen quickly from the Main Screen. The actual water temperature can be seen in large text and the desired or set temperature is shown in smaller text. The time-of-day, ozone/uv, filter operation, messages, heat range, menu option and panel lock are also displayed on the main screen.

  • Page 24: Spa Operation

    SPA OPERATION There are three ways to operate the spa functions from the spa side. You can turn the spa pumps and lights from the topside though the buttons on the left hand side of the control panel, or you can use the spa menu using the navigation buttons or you can use the short cut setting.
  • Page 25 SPA OPERATION Temperature Up Button: The temperature up button will increase the set point temperature Temperature Down Button: The Temperature down button will decrease the set point. Menu Button: Will open the menu screen. Use the pump/menu navigation buttons to navigate the menu options. Using the Spa Menu and navigation buttons: Menu Button: Press the Menu Button to activate the menu.
  • Page 26 SPA OPERATION Navigation Buttons Us the navigation buttons to highlight the operation you would like to per- form. Icons and operation of the icons when highlighted and the select button is pressed. Back button: Will return you to the main menu Jets 1: First press of the Select button will activate pump 1 (if pump is not currently on).

  • Page 27: Temperature Operation

    SPA/TEMPERATURE OPERATION Light: First Press of the select will turn on the lights. A second press of the select button will turn the lights off. The Island Spas lighting systems have diffe rent modes. To cycle through the dif- ferent modes you must turn the light on and off, once the desired mode is selected, leave the light on.

  • Page 28: Settings Screen

    THE SETTINGS SCREEN THE SETTINGS SCREEN The Settings Screen is where all programming and other spa behaviors are controlled. Menu Button: Press the Menu Button to activate the menu. Jets 3/ Down navigation: Use the Down button and highlight Settings in the menu. Settings Temp Range High Heat Mode...

  • Page 29: Temp Range

    THE SETTINGS SCREEN Temp Range The first setting available to change is Temp Range. This system incorpo- rates two temperature range settings. The specific range that is selected (High or Low) will be displayed in the upper right hand corner of the main screen.

  • Page 30: Time Of Day

    THE SETTINGS SCREEN Jets 4/Navigate Left Button: Press the left button to high light the Back Icon -OR- Jets 3/Down navigation: Press the down button to go to Time of Day Time of Day When the time of day is highlighted. Jets 2/Navigate right Button: Press the Right button to go to the Time of Day Menu.
  • Page 31 THE SETTINGS SCREEN NOTE: To change from AM to PM you will need to adjust the hours past 12. Jets 2/Navigate right Button: Press the Right button to High Light the minutes. Jets 1/Navigate up Button: To increase the minutes. Jets 3/Down navigation: To decrease the minutes.

  • Page 32: Setting Filter Cycle

    THE SETTINGS SCREEN Setting Filter Cycle When the Filter Cycle is highlighted. Jets 2/Navigate right Button: Press the Right button to go to the Filter Cycle Menu. The screen will change to Filter Cycle menu. Filter Cycles Filter Cycle 1 Starts at 12:00 AM Runs 0 HR 0 Min Ends at 12:00 AM...
  • Page 33 THE SETTINGS SCREEN Jets 3/Down navigation: To decrease the Filter Cycle 1 Start time Minutes. Jets 2/Navigate right Button: Press the Right button to high light Filter Cycle 1 Start time minutes. (NOTE: Changing the minutes goes by 15 minute intervals). Jets 1/Navigate up Button: To increase the Run Time Hours.
  • Page 34 THE SETTINGS SCREEN Jets 1 / Navigate up Button: To tun Filter Cycle 2 on or off. -OR- Jets 3/Down navigation: To turn Filter Cycle 2 on or off. Jets 2/Navigate right Button: Press the Right button to high light Filter Cycle 2 Start time Hour.
  • Page 35 THE SETTINGS SCREEN Jets 1/Navigate up Button: To increase the Run Time Hours. Jets 3/Down navigation: To decrease the Run Time Hours. NOTE:The panel calculates the end time and displays it automati- cally. In order to maintain sanitary conditions, as well as protect against freez- ing, the system will purge water from their respective plumbing by briefly running the pumps at the beginning of each filter cycle.

  • Page 36: Invert Display

    THE SETTINGS SCREEN Invert Display Normal: Display will be towards the inside of the spa. Inverted; Display will be towards the outside of the spa. When the display is inverted, the navigation buttons will also be inverted to work with the display. Jets 3/ Down navigation: Press the down button until Lock is highlighted.
  • Page 37 THE SETTINGS SCREEN Jets 3/Down navigation Press the down button until Panel is highlighted. The screen will change and go back to the main display. o unlock the system. Hit Menu Button Jets 2/Navigate right Button: Press the Right button to highlight Settings OFF/ON. Then press the following buttons.

  • Page 38: Hold

    THE SETTINGS SCREEN Jets 4/Navigate Left Button: Press the left button to highlight Back Icon Back Select Jets 3/Down navigation: Press the Down Button until Hold is highlighted. Hold Hold mode is used to disable the pump during service functions, clean- ing or replacing the filters.

  • Page 39: Utilities

    THE SETTINGS SCREEN Utilities The Utilities menu is used for trouble shooting and for technicians. As this is for service personnel we will just explain what each subject is. We do not recommend to change anything unless walked through the setting with a technician.

  • Page 40: Temp Display

    THE SETTINGS SCREEN Temp Display Jets 2/Navigate right Button: Press the Right button to highlight Temp Display. Press the select button to change from F° (Fahrenheit) to C° (Celsius) or from C° (Celsius) to F° (Fahrenheit). Jets 3/Down navigation. Press the Down Button until Time Display is highlighted. Time Display Press the select button to change from 12HR to 24HR or 24HR to 12HR time display.

  • Page 41: Dolphin Not Used

    THE SETTINGS SCREEN Dolphin (Not Used) Jets 3/Down navigation: Press the Down Button until Dolphin is highlighted. This option is not available. Color Jets 3/Down navigation: Press the Down Button until Color is highlighted. Press the select button to change Back Ground color on the display. Color options are: Blue, Red, Purple, Grey, and Green.

  • Page 42: General Messages

    GENERAL MESSAGES Most messages and alerts will appear at the bottom of the normally used screens. Several alerts and messages may be displayed in sequence Some messages can be reset from the panel. Message that can be reset will appear with a “right arrow” at the end of the message. This message can be selected by navigating to it and pressing the select button.

  • Page 43: Heater Related Messages

    HEATER-RELATED MESSAGES The water flow is low – M016 There may not be enough water flow through the heater to carry the heat away from the heating elements. Heater start up will begin again after about 1 minute. Flow-Related Checks Check for low water level, suction flow restriction (filters) closed valved, or trapped air.

  • Page 44: Sensor-Related Messages

    SENSOR-RELATED/MISC. MESSAG ES The heater is too hot* – M030 One of the water temperature has detected 118°F (47.8°C) in the heater and the spa is shut down. You must clear the message when water is below 108°F (42.2°C) Flow-Related Checks Check for low water level, suction flow restriction (filters) closed valved, or trapped air.

  • Page 45: System Related Messages

    SYSTEM-RELATED MESSAGES Program memory failure – M022 Call you dealer for service The settings have been reset– M021 Call you dealer for service if this message appears on more than one power-up The clock has failed –M020 Call you dealer for service Configuration error (Spa will not Start Up) Call you dealer for service The GFCI test failed (System Could Not Test the GFCI) –...

  • Page 46: Reminder Messages

    REMINDER MESSAGES Not all messages may be displayed. Check the pH May appear on a regular schedule, i.e. every 7 days. Check pH with a test kit and adjust pH with the appropriate chemicals. Check the sanitizer May appear on a regular schedule, i.e. every 7 days. Check sanitizer level and other water chemistry with a test kit and adjust with the appropriate chemicals.

  • Page 47: Direct Flow Control Panel

    DIRECT FLOW CONTROL PANEL SPEED CONTROL PUMP BUTTON AIR VENTURI The Direct Flow individual control panels let you control the spa from the seat. Speed Control: The speed control will change the water flow from the jets, from a vigorous massage to a softer massage.

  • Page 48: Maintaining Your Spa

    MAINTAINING YOUR SPA DRAINING YOUR SPA Your spa needs to be drained, cleaned, waxed, and refilled about every six months. More frequent water changes may be necessary if bather load is heavy. A hose bib has been provided below the left side of your front access panel, to assist you in draining your spa.

  • Page 49: Jet Care

    MAINTAINING YOUR SPA JET CARE We recommend that you clean your jets when you drain your spa. However, if you do need to clean your jets in between this can be ac- complished with a full spa. 1) To remove the jet inserts turn the jet counterclockwise until it stops.

  • Page 50: Removing, Installing And Cleaning Filters

    MAINTAINING YOUR SPA REMOVING, INSTALLING AND CLEANING FILTERS These are the steps needed to successfully replace your filters You should replace your disposable spa filters and clean your nondisposable filters every four months. 1) Turn off all power to your spa and remove the filter lid by lifting it out towards you.

  • Page 51: Winterizing Your Spa

    MAINTAINING YOUR SPA WINTERIZING YOUR SPA It is not recommended that you drain your spa completely during freezing conditions. We recommend that you leave your spa full of water with the power on to keep the tub from freezing. If you decide to drain your spa during freezing conditions, contact your dealer for help.

  • Page 52: Cover Care

    MAINTAINING YOUR SPA COVER CARE Cleaning of your spa cover is an important part of routine maintenance. Dirt acts as an abrasive to the vinyl topcoat, and can also cause wear to folds, seams, and stitching. Mildew growing on damp, dirty vinyl will begin to actually root in the fabric, accelerating failure.
  • Page 53 MAINTAINING YOUR SPA CHEMICAL TREATMENT OF WATER Because of this residual effect, at some point it becomes easier and more cost-effective to drain, clean and refill your spa with new water. We rec- ommend that the water be changed at least every six months. At this time you should also clean or replace your filters.

  • Page 54: Artesian Spas Island Elite Warranty

    ARTESIAN SPAS ISLAND ELITE WARRANTY This section is a description of your warranty. Here you will find descrip- tions of what is covered under your Island Elite Class Spa warranty and what can void your warranty. PLEASE READ THE WARRANTY THOROUGHLY.
  • Page 55 for a period of seven years from the original start date of the war- ranty. The warranty period starts either the day of delivery to the customer or eighteen (18) months from the date of manufacturing, whichever date comes first. THIS WARRANTY IS GIVEN ONLY TO THE ORIGINAL OWNER, AND TERMINATES UPON TRANS- FER OF OWNERSHIP.
  • Page 56 ARTESIAN SPAS ISLAND ELITE WARRANTY FIVE-YEAR ELECTRICAL WARRANTY (i.e. pumps, equipment packs, heater, topside control, etc). The man- ufacturer warrants all electrical equipment to be free from defect and workmanship for five years from the original start date of the warranty.
  • Page 57 THIS WARRANTY IS GIVEN ONLY TO THE ORIGINAL OWNER, AND TERMINATES UPON TRANSFER OF OWNERSHIP. COM- MERCIAL APPLICATIONS ARE EXCLUDED FROM THIS AND ALL WARRANTIES. This warranty does not cover normal darkening, staining, or aging. The spa cabinet requires care and maintenance by the consumer. Damage caused by weather, poor water chemistry, and/or improper maintenance will not be covered under this warranty.
  • Page 58 ARTESIAN SPAS ISLAND ELITE WARRANTY Do not return the spa cover to the manufacturer. This will delay the replacement or repair of the cover. The spa manufacturer is not respon- sible for lost covers. LIGHTING The LED lighting is guaranteed to work upon delivery. There is no war- ranty covering the LED lighting.
  • Page 59 Light Bulbs of Any Kind Removing a Spa from a Structure Pillows Filters Chemical Misuse / Damage Filter Lids Any Part not Purchased from Artesian Spas Jet Inserts Valve Handles Pump Seals Draining and filling the Spa Acts of Nature...

  • Page 60: Artesian Spas Island Elite Parts List & Diagram

    (2) HEATER (2) HEATER (8) DIVERTER VALVE (1) SPA PACK (1) SPA PACK (7) PILLOWS (4) PUMP (9) AIR CONTROL (9) AIR CONTROL/ ON/OFF VALVE © 2016 Artesian Spas (May Manufacturing, LLC) | Last Revised 06/21/2016| Subject to change without notice.
  • Page 65 © 2016 Artesian Spas (May Manufacturing, LLC) | 11-1410-11 Rev_R062416...
