Icom IC-F3001 Service Manual Addendum page 3

Mar. 2010
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R36 7030005050 S.RES ERJ2GEJ 103 X (10K)
R37 7030004980 S.RES ERJ2GEJ 101 X (100)
R38 7030005120 S.RES ERJ2GEJ 102 X (1K)
R41 7030005530 S.RES ERJ2GEJ 100 X (10)
R42 7030005240 S.RES ERJ2GEJ 473 X (47K)
R44 7030005530 S.RES ERJ2GEJ 100 X (10)
R45 7030005240 S.RES ERJ2GEJ 473 X (47K)
R47 7030004980 S.RES ERJ2GEJ 101 X (100)
R48 7030005310 S.RES ERJ2GEJ 124 X (120K)
R51 7030008370 S.RES ERJ2GEJ 561 X (560)
R52 7030008370 S.RES ERJ2GEJ 561 X (560)
R53 7030008340 S.RES RR0510P-182-D (1.8K)
R54 7030011000 S.RES RR0510P-392-D (3.9K)
R55 7030008340 S.RES RR0510P-182-D (1.8K)
R56 7030011000 S.RES RR0510P-392-D (3.9K)
R57 7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
R61 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R62 7030005220 S.RES ERJ2GEJ 223 X (22K)
R65 7030005720 S.RES ERJ2GEJ 563 X (56K)
R66 7030008300 S.RES ERJ2GEJ 184 X (180K)
R67 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R68 7030005170 S.RES ERJ2GEJ 474 X (470K)
R69 7030005060 S.RES ERJ2GEJ 333 X (33K)
R70 7030005090 S.RES ERJ2GEJ 104 X (100K)
R71 7030005050 S.RES ERJ2GEJ 103 X (10K)
R72 7030005120 S.RES ERJ2GEJ 102 X (1K)
R73 7030005050 S.RES ERJ2GEJ 103 X (10K)
R76 7030005120 S.RES ERJ2GEJ 102 X (1K)
R77 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
R78 7030004990 S.RES ERJ2GEJ 221 X (220)
R80 7410001130 S.ARR EXB28V102JX
R81 7030005100 S.RES ERJ2GEJ 154 X (150K)
R82 7030005050 S.RES ERJ2GEJ 103 X (10K)
R83 7030004970 S.RES ERJ2GEJ 470 X (47)
R87 7030005090 S.RES ERJ2GEJ 104 X (100K)
R88 7510001730 S.THE ERTJOEP 473J
R89 7030010080 S.RES ERJ2RHD 104 X (100K)
R101 7030005230 S.RES ERJ2GEJ 334 X (330K)
R102 7030005170 S.RES ERJ2GEJ 474 X (470K)
R103 7030009290 S.RES ERJ2GEJ 562 X (5.6K)
R104 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R105 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R106 7030005310 S.RES ERJ2GEJ 124 X (120K)
R107 7030008290 S.RES ERJ2GEJ 183 X (18K)
R108 7030005090 S.RES ERJ2GEJ 104 X (100K)
R109 7030005530 S.RES ERJ2GEJ 100 X (10)
R110 7030008280 S.RES ERJ2GEJ 271 X (270)
R111 7030005110 S.RES ERJ2GEJ 224 X (220K)
R112 7030004970 S.RES ERJ2GEJ 470 X (47)
R113 7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
7030008370 S.RES ERJ2GEJ 561 X (560)
R114 7030005090 S.RES ERJ2GEJ 104 X (100K)
R115 7030005090 S.RES ERJ2GEJ 104 X (100K)
R116 7030005080 S.RES ERJ2GEJ 823 X (82K)
R117 7030005090 S.RES ERJ2GEJ 104 X (100K)
R118 7030005100 S.RES ERJ2GEJ 154 X (150K)
R119 7030005310 S.RES ERJ2GEJ 124 X (120K)
R120 7030005590 S.RES ERJ2GEJ 680 X (68)
R121 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R122 7030004970 S.RES ERJ2GEJ 470 X (47)
R123 7030005530 S.RES ERJ2GEJ 100 X (10)
R125 7030008370 S.RES ERJ2GEJ 561 X (560)
R126 7030004980 S.RES ERJ2GEJ 101 X (100)
R127 7030005110 S.RES ERJ2GEJ 224 X (220K)
R128 7030005010 S.RES ERJ2GEJ 681 X (680)
R129 7030005000 S.RES ERJ2GEJ 471 X (470)
R130 7030005530 S.RES ERJ2GEJ 100 X (10)
R131 7030005000 S.RES ERJ2GEJ 471 X (470)
R132 7030005050 S.RES ERJ2GEJ 103 X (10K)
R134 7030005090 S.RES ERJ2GEJ 104 X (100K)
R135 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R136 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R137 7030008410 S.RES ERJ2GEJ 392 X (3.9K)
R138 7030005000 S.RES ERJ2GEJ 471 X (470)
R139 7030005310 S.RES ERJ2GEJ 124 X (120K)
R140 7030008410 S.RES ERJ2GEJ 392 X (3.9K)
R141 7030005220 S.RES ERJ2GEJ 223 X (22K)
R142 7030005090 S.RES ERJ2GEJ 104 X (100K)
R146 7030004970 S.RES ERJ2GEJ 470 X (47)
R147 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R148 7030005120 S.RES ERJ2GEJ 102 X (1K)
R149 7030007060 S.RES ERJ2GEJ 684X (680K)
All manuals and user guides at all-guides.com
[MAIN UNIT]
H/V REF
M.
LOCATION
B 49.6/13.1 R151
B 49.6/14 R152
B 51.8/15.2 R153
T 53/17.7 R154
T 56.6/19.4 R155
B 56.5/21.3 R156
B 57.7/18.6 R157
T 63.4/17.7 R158
T 62.5/19.3 R301
B 56.5/22.9 R302
B 60.5/24.4 R303
T 55.7/23.7 R304
T 57.9/25.9 R310
T 61.8/23.7 R311
T 58.9/25.9 R312
T 60.7/25.9 R313
B 61.1/28.9 R314
B 64.4/27.8 R315
B 65.4/26.2 R316
B 66.3/26.2 R317
B 62.3/18 R318
B 61.5/30.7 R321
B 61.5/31.6 R322
B 63.7/30.9 R323
B 50.3/29.5 R324
B 50.3/27.9 R325
B 54.7/28.9 R326
T 48.3/26.3 R327
T 46.7/25.4 R328
T 46.7/24.2 R329
T 44.4/29.9 R330
B 62/35.3 R331
T 40.1/19.4 R341
T 46.1/19.8 R342
B 61.5/29.8 R343
T 58.2/9.6 R344
T 57.3/12.3 R345
B 28.7/32.3 R346
B 28.7/33.2 R347
B 31/30.7 R348
B 17.4/25.8 R349
B 18.4/25.8 R350
B 22.8/26.9 R351
B 22.6/30 R352
B 22.8/28.7 R353
B 23.5/30 R354
B 23.5/25.6 R355
B 24.4/30 R356
B 27.1/25.6 R359
[USA-11] B 29.2/27.5 R360
[USA-12] R361
[USA-13] R362
[EUR-21] R363
[EUR-22] R364
[EUR-23] R366
[UK-01] R368
[UK-02] R369
[UK-03] R370
[EXP-11] R371
[EXP-12] R372
[EXP-13] R373
[EXP-21] R374
[EXP-22] R375
[EXP-23] R377
[EXP-01] R378
[EXP-03] R379
[EXP-31] R381
[CHN-31] R382
[AUS-21] R383
[AUS-22] R384
[AUS-23] R385
[RUS-21] R386
[RUS-22] R387
[RUS-23] R388
B 30.1/25.6 R389
B 31/25.6 R390
B 35.4/29.3 R391
B 33.4/25.1 R393
B 36.4/25.1 R394
B 36.4/29.3 R395
B 39.4/25.1 R396
B 41.2/27.7 R397
B 42.4/25.1 R398
B 39.4/29.8 R401
B 35.6/40.8 R402
B 39/40.8 R403
B 37.3/40.8 R405
B 39.1/44.4 R406
B 37.4/23.5 R407
B 36.4/23.5 R408
B 35.4/23.5 R412
B 47.4/17.6 R413
B 40.4/40.3 R414
T 43/36.7 R416
T 43/37.6 R417
T 45.7/36.4 R418
B 43/35.5 R420
B 48.3/35.5 R421
B 46.5/34.6 R423
B 46.5/33.7 R424
B 46.5/31.9 R426
B 45.6/44 R427
B 47.1/42.2 R428
T 37.8/31.4 R429
T 37.8/29.6 R430
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
2
PARTS
DESCRIPTION
NO. NO.
7030005600 S.RES ERJ2GEJ 273 X (27K)
7030005210 S.RES ERJ2GEJ 822 X (8.2K)
7030007300 S.RES ERJ2GEJ 332 X (3.3K)
7030005210 S.RES ERJ2GEJ 822 X (8.2K)
7030005600 S.RES ERJ2GEJ 273 X (27K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030008010 S.RES ERJ2GEJ 123 X (12K)
7030005720 S.RES ERJ2GEJ 563 X (56K)
7030005030 S.RES ERJ2GEJ 152 X (1.5K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030007300 S.RES ERJ2GEJ 332 X (3.3K)
7030006610 S.RES ERJ2GEJ 394 X (390K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030008300 S.RES ERJ2GEJ 184 X (180K)
7030005720 S.RES ERJ2GEJ 563 X (56K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005040 S.RES ERJ2GEJ 472 X (4.7K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005160 S.RES ERJ2GEJ 105 X (1M)
7030005160 S.RES ERJ2GEJ 105 X (1M)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030008290 S.RES ERJ2GEJ 183 X (18K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005210 S.RES ERJ2GEJ 822 X (8.2K)
7030005160 S.RES ERJ2GEJ 105 X (1M)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030010040 S.RES ERJ2GEJ-JPW
7030010040 S.RES ERJ2GEJ-JPW
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005060 S.RES ERJ2GEJ 333 X (33K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005100 S.RES ERJ2GEJ 154 X (150K)
7030005700 S.RES ERJ2GEJ 274 X (270K)
7030005100 S.RES ERJ2GEJ 154 X (150K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030009290 S.RES ERJ2GEJ 562 X (5.6K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030008410 S.RES ERJ2GEJ 392 X (3.9K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005060 S.RES ERJ2GEJ 333 X (33K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005700 S.RES ERJ2GEJ 274 X (270K)
7030005700 S.RES ERJ2GEJ 274 X (270K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030008310 S.RES ERJ2GEJ 564 X (560K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005310 S.RES ERJ2GEJ 124 X (120K)
7030005060 S.RES ERJ2GEJ 333 X (33K)
7030005030 S.RES ERJ2GEJ 152 X (1.5K)
7030008010 S.RES ERJ2GEJ 123 X (12K)
7030005800 S.RES RR0510P-102-D (1K)
7030005810 S.RES RR0510P-152-D (1.5K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005700 S.RES ERJ2GEJ 274 X (270K)
7030005310 S.RES ERJ2GEJ 124 X (120K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030008300 S.RES ERJ2GEJ 184 X (180K)
7030008310 S.RES ERJ2GEJ 564 X (560K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030010040 S.RES ERJ2GEJ-JPW
7030011290 S.RES ERJ12YJ1R8U (1.8)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030010040 S.RES ERJ2GEJ-JPW
7030004980 S.RES ERJ2GEJ 101 X (100)
7030005040 S.RES ERJ2GEJ 472 X (4.7K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005230 S.RES ERJ2GEJ 334 X (330K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7210003061 VAR TP76N00N-15F-A103-2251A
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030005230 S.RES ERJ2GEJ 334 X (330K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030008300 S.RES ERJ2GEJ 184 X (180K)
7030005160 S.RES ERJ2GEJ 105 X (1M)
H/V
M.
LOCATION
B 51.7/39
B 53.9/35.1
B 55.5/38.5
B 57.5/36.9
B 58.8/39.8
B 19.4/24.1
B 31/23.9
B 59.4/35.7
B 68.4/12.4
B 66.6/12.4
B 67.5/12.4
B 69.3/10.7
T 66.2/36.7
T 64.6/37.9
T 64.6/39.6
T 62.6/39.6
T 63.7/41.2
T 63.7/42.8
T 67.3/42.8
T 66.4/39.6
T 67.3/39.6
T 73.7/27.7
B 69.1/33
B 70/33
B 70.9/33
T 72.8/29.5
T 73.7/29.5
T 75.5/29.5
T 75.5/27.7
T 77.9/29.5
T 74.5/32.9
T 77.4/31.6
T 84.8/31.1
T 84.8/29.4
T 84.8/27.7
T 86.6/27.7
T 85.7/26
T 85.7/24.3
B 81.3/15.6
T 82.3/34.6
T 83.2/34.6
T 86.6/24.3
T 75.5/24.3
T 71.8/12
T 72.7/10.2
T 75.4/10.2
T 73.7/24.3
T 85.7/23.1
B 56/10.5
B 56/9.6
B 25.1/43.9
B 51.6/7.5
B 57.8/8.7
T 59.5/5.5
B 57.8/9.6
T 61.7/8.7
T 61.7/10.4
B 61.7/11
T 74.5/8.4
T 80.2/8.4
T 84.7/10.2
T 86.5/10.2
T 85.6/12
T 84.7/13.8
T 86.5/15.6
T 84.7/15.6
T 70.9/15.6
T 71.8/13.8
T 70.9/13.8
T 80.9/15.4
T 74.5/13.8
T 73.6/13.8
T 73.6/15.6
B 82.8/17.3
B 83.7/17.3
B 77.2/15.6
T 74.5/15.6
B 61.7/7.8
B 60.8/6.2
B 60.8/7.8
B 61.7/6.2
B 60.8/4.6
B 61.7/9.4
T 66.2/35.8
B 68.5/22.5
B 67.5/28.7
T 33.6/35.3
B 12.2/45.6
T 34/37.9
B 35.6/46.3
B 15.9/39.5
T 20.4/33.4
B 20.2/33.7
B 21.5/35.8
B 21.3/37.1
B 19.8/37.9
T 79.6/32.3
T 6.9/37.8
T 5.2/38.7
B 69.3/6.3
B 69.3/4.6
B 65.1/3.1
B 66.8/3.1
B 72.1/3.1
S.=Surface mount
