Icom IC-F3001 Service Manual Addendum page 13

Feb. 2010
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R460 7410001140 S.ARR EXB28V104JX
R461 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R462 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R463 7030005050 S.RES ERJ2GEJ 103 X (10K)
R464 7030005090 S.RES ERJ2GEJ 104 X (100K)
R466 7410001140 S.ARR EXB28V104JX
R467 7410001140 S.ARR EXB28V104JX
R468 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
R469 7030009280 S.RES ERJ2GEJ 391 X
R470 7030005090 S.RES ERJ2GEJ 104 X (100K)
R471 7030007340 S.RES ERJ2GEJ 153 X (15K)
R472 7030005090 S.RES ERJ2GEJ 104 X (100K)
R473 7410001140 S.ARR EXB28V104JX
R474 7030007340 S.RES ERJ2GEJ 153 X (15K)
R475 7030005090 S.RES ERJ2GEJ 104 X (100K)
R476 7030005120 S.RES ERJ2GEJ 102 X (1K)
R477 7030005120 S.RES ERJ2GEJ 102 X (1K)
C2 4030017620 S.CER C1005 CH 1H 100C-T
C3 4030017410 S.CER C1005 CH 1H 240J-T
C4 4030017570 S.CER C1005 CH 1H 040B-T
C5 4030017650 S.CER C1005 CH 1H 270J-T
C6 4030017550 S.CER C1005 CH 1H 1R5B-T
C7 4030017640 S.CER C1005 CH 1H 150J-T
C8 4030017460 S.CER C1005 JB 1H 102K-T
C11 4030017460 S.CER C1005 JB 1H 102K-T
C15 4030017400 S.CER C1005 CH 1H 220J-T
C16 4030017390 S.CER C1005 CH 1H 180J-T
C17 4030017530 S.CER C1005 CH 1H 0R5B-T
C18 4030017460 S.CER C1005 JB 1H 102K-T
C20 4030017460 S.CER C1005 JB 1H 102K-T
C21 4030007070 S.CER C1608 CH 1H 330J-T
C23 4030007050 S.CER C1608 CH 1H 220J-T
C26 4030017460 S.CER C1005 JB 1H 102K-T
C27 4030017460 S.CER C1005 JB 1H 102K-T
C28 4030017460 S.CER C1005 JB 1H 102K-T
C29 4030016930 S.CER C1005 JB 1A 104K-T
C30 4030018890 S.CER C1005 JB 0J 224K-T
C31 4030016930 S.CER C1005 JB 1A 104K-T
C32 4030017460 S.CER C1005 JB 1H 102K-T
C33 4030017460 S.CER C1005 JB 1H 102K-T
C34 4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030020120 S.CER C1005 JB 0J 225M-T
4030020120 S.CER C1005 JB 0J 225M-T
4030020120 S.CER C1005 JB 0J 225M-T
4030020120 S.CER C1005 JB 0J 225M-T
4030020120 S.CER C1005 JB 0J 225M-T
4030020120 S.CER C1005 JB 0J 225M-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
4030018860 S.CER C1005 JB 0J 105K-T
C35 4030017420 S.CER C1005 CH 1H 470J-T
C36 4030017460 S.CER C1005 JB 1H 102K-T
C41 4030017460 S.CER C1005 JB 1H 102K-T
C43 4030017490 S.CER C1608 JB 1A 105K-T
C44 4030017460 S.CER C1005 JB 1H 102K-T
C46 4030017430 S.CER C1005 CH 1H 101J-T
C48 4030017460 S.CER C1005 JB 1H 102K-T
C49 4030017420 S.CER C1005 CH 1H 470J-T
C51 4030017460 S.CER C1005 JB 1H 102K-T
C52 4030017460 S.CER C1005 JB 1H 102K-T
C53 4030017460 S.CER C1005 JB 1H 102K-T
C54 4030016790 S.CER C1005 JB 1E 103K-T
C55 4030017490 S.CER C1608 JB 1A 105K-T
C56 4030017430 S.CER C1005 CH 1H 101J-T
C57 4030017460 S.CER C1005 JB 1H 102K-T
C58 4030017420 S.CER C1005 CH 1H 470J-T
C59 4030017460 S.CER C1005 JB 1H 102K-T
C60 4030017460 S.CER C1005 JB 1H 102K-T
C63 4030017650 S.CER C1005 CH 1H 270J-T
C64 4030016790 S.CER C1005 JB 1E 103K-T
C65 4030017460 S.CER C1005 JB 1H 102K-T
C71 4030017620 S.CER C1005 CH 1H 100C-T
C72 4030017460 S.CER C1005 JB 1H 102K-T
C73 4030017460 S.CER C1005 JB 1H 102K-T
C74 4030017590 S.CER C1005 CH 1H 070C-T
C75 4030017460 S.CER C1005 JB 1H 102K-T
C76 4030017460 S.CER C1005 JB 1H 102K-T
C77 4030017460 S.CER C1005 JB 1H 102K-T
C78 4030017460 S.CER C1005 JB 1H 102K-T
C79 4030016930 S.CER C1005 JB 1A 104K-T
C80 4030017460 S.CER C1005 JB 1H 102K-T
C81 4030017360 S.CER C1005 CH 1H 030B-T
C83 4030017540 S.CER C1005 CH 1H R75B-T
C85 4030017460 S.CER C1005 JB 1H 102K-T
C86 4030017660 S.CER C1005 CH 1H 330J-T
C87 4030017660 S.CER C1005 CH 1H 330J-T
C88 4030017660 S.CER C1005 CH 1H 330J-T
C89 4030017660 S.CER C1005 CH 1H 330J-T
All manuals and user guides at all-guides.com
[MAIN UNIT]
H/V REF
M.
LOCATION
B 77.7/30 C90
B 84/30.8 C93
B 84/29.9 C94
T 71.8/37.7 C101
T 73.4/34.8 C102
B 69.5/40 C103
B 69.5/37 C104
T 70/41.6 C105
T 70/39.5 C106
B 74.7/46.1 C107
B 72.6/45.4 C108
B 72.6/47.2 C109
B 77.7/46.1 C111
B 72.6/46.3 C112
B 79.5/30 C113
B 75.9/46.1 C114
B 85.2/34.5 C115
C116
C117
B 10.3/6.1 C118
B 7.4/12 C120
B 11.5/11.4 C121
B 12.4/11.4 C122
B 11.5/13 C123
B 12.4/13 C124
B 14.5/17.2 C127
B 20.6/20.1 C130
B 16.2/14.1 C132
B 17.9/11.3 C134
B 19.4/11.7 C135
B 17.9/9.6 C141
B 20.4/14.1 C145
B 21.3/10.4 C149
B 22.7/10.4 C150
T 29.9/5.9 C151
T 39.2/5.9 C152
T 33.6/11.3 C153
T 30.8/11.3 C154
T 34.8/5.9 C155
T 35.7/11.3 C156
T 36.6/9.6 C157
T 36.6/7.6 C158
[USA-11] T 37.5/7.6 C159
[USA-12] C160
[USA-13] C167
[EUR-21] C168
[EUR-22] C169
[EUR-23] C171
[UK-01] C172
[UK-02] C173
[UK-03] C174
[EXP-11] C175
[EXP-12] C176
[EXP-13] C178
[EXP-21] C179
[EXP-22] C180
[EXP-23] C181
[EXP-01] C182
[EXP-03] C183
[EXP-31] C184
[CHN-31] C186
[AUS-21] C188
[AUS-22] C189
[AUS-23] C191
[RUS-21] C192
[RUS-22] C193
[RUS-23] C195
B 37.5/9.2 C196
B 44.6/9.5 C197
B 28/17.6 C198
B 27.8/20.3 C199
T 32.7/16.6 C200
B 32.8/12.4 C201
B 32.3/9.2 C202
B 31.4/9.2 C203
B 23.4/22.7 C206
B 32.8/14.4 C210
B 37.5/10.9 C211
B 39.3/10.9 C214
B 33.5/16.6 C215
B 39.9/13.1 C216
B 40.5/14.9 C217
B 44.6/11.3 C218
B 44.6/10.4 C220
B 44.6/12.2 C223
B 46.4/14.9 C224
B 49.6/12.1 C225
B 51.2/14 C226
B 51.8/16.6 C227
B 51.2/17.8 C228
T 53/19.4 C231
T 58/18.9 C232
T 54.1/20.4 C233
B 58.6/18.6 C234
T 64.3/17.7 C235
T 58.9/18.9 C236
B 64.3/21.2 C238
B 62.5/25.9 C239
T 58.5/17.3 C240
T 58.9/21.2 C241
T 57.1/21.2 C242
T 57/25.9 C243
T 58/21.2 C244
T 56.1/25.9 C251
T 57.9/27.5 C252
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
