GENERAL
• Frequency range
• Number of conventional channels
• Type of emission
• Antenna impedance
• Operating temperature range
• Power supply voltage
• Current drain (Approx.)
• Dimensions
(Projections not included, approx.)
• Weight
M
TRANSMITTER
• Output power
• Modulation
• Maximum frequency deviation
• Frequency stability
• Spurious emissions
• Adjacent channel power
• Audio harmonic distortion
• FM hum and Noise (Except [EUR], [UK])
(Without CCITT FILTER)
• Residual modulation ([EUR], [UK])
(With CCITT FILTER)
• Limitting charact of modulator
• Audio input impedance
All manuals and user guides at all-guides.com
SPECIFICATIONS
: 136–174 MHz
: 16 channels
: [EUR] Wide: 16K0F3E (25.0 kHz)
Middle: 14K0F3E (20.0 kHz)
Narrow: 8K50F3E (12.5 kHz)
Except [EUR] Wide: 16K0F3E (25.0 kHz)
Narrow: 11K0F3E (12.5 kHz)
: 50 Ω (Nominal)
: –30˚C to +60˚C; –22˚F to +140˚F
–25˚C to +55˚C
: Specified Icom's battery packs only (7.2 V DC; negative ground)
: Receiving 75 mA (stand-by)
330 mA (max. audio)
Transmitting 1.3 A (at 5.0 W)
: With BP-264 58.0 (W)×111.0 (H)×31.0 (D) mm; 2
With BP-265 58.0 (W)×111.0 (H)×35.5 (D) mm; 2
: With BP-264 Approx. 330 g; 11
With BP-265 Approx. 270 g; 9
: 5 W
: Variable reactance frequency modulation
: Narrow ±2.5 kHz
Middle ±4.0 kHz
Wide ±5.0 kHz
: ±2.5 ppm
: 70 dB min.
0.25 µW (≤1 GHz), 1.0 µW (>1 GHz)
: Narrow 60 dB min., 70 dB typ.
Middle 70 dB min., 80 dB typ.
Wide 70 dB min., 80 dB typ.
: Wide, Middle 1.0% typ. at AF 1 kHz 40% deviation
Narrow 1.5% typ. at AF 1 kHz 40% Deviation
: Narrow 34 dB min., 40 dB typ.
Wide 40 dB min., 46 dB typ.
: Narrow 40 dB min.
Middle 43 dB min.
Wide 45 dB min.
: 60–100% of max. deviation
: 2.2 kΩ
