USER MANUAL CZ-680/ZEN 3D PRO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEN 3D PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Cozzia ZEN 3D PRO

Summary of Contents for Cozzia ZEN 3D PRO

  • Page 1 USER MANUAL CZ-680/ZEN 3D PRO...
  • Page 3 Hello. Cozzia CZ-680. At Cozzia we understand that every body is different and have carefully designed your massage chair with that in mind. For replacement parts and tech support, please call our service and warranty hotline, or visit www.cozziausa.com...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Dimensions Contents INTRO Move & Clearance Components Massage Points CHAIR Specifications Interface 9-12 Pre-Programed Massage 13-18 Demo 19-20 Custom Massage 21-25 MASSAGE Spot Massage 26-28 Settings 29-34 Auto Program Descriptions 35-38 Safety 39-41 Grounding Instructions Troubleshooting CARE Care and Storage Warranty 43-44...

  • Page 5: Dimensions

    DIMENSIONS First, let’s get your chair inside. 50.4” 51.2” 32.7” 36.8” 28” 23.4” 52.8” 54.1” 13.6” 30.5” 29.1” 30.5” Seat Base Backrest Side Panels...

  • Page 6: Intro Contents

    CONTENTS Everything you need for a relaxing experience. CZ-680 CZ-680/ZEN 3D PRO USER MANUAL CZ-680/ZEN 3D PRO User Manual Installation Manual Warranty Postcard Power Cord Wired Touch-Pad CZ-680 Massage Chair...

  • Page 7: Move & Clearance

    Move & Clearance A few simple steps to find the best place for your new chair. HOW TO MOVE Lift and hold the bottom of the chair Lower down the backrest 45 degrees onto wheels CLEARANCE 31.5” 8” 8” 31.5” Reserve space on the left and right Reserve space in the front and back...

  • Page 8: Components

    CHAIR COMPONENTS Some of your chair’s most important features. Pillow LED + Speaker Shoulder Panel Wired Tablet Backrest Holder Handrest Seat Pad Side Panel Calf Rest Wheel Foot Rest Note: The speaker will only operate when the massage chair is powered on To play music using your massage chair’s speakers please connect your smartphone, tablet, or other electronic device to your chair using bluetooth...

  • Page 9: Chair Massage Points

    MASSAGE POINTS 24 Air Bags 2 Heating Pads 24 Air Bags 2 Rollers Back Massage Mode Air Bag Heating Pad Roller...

  • Page 10: Specifications

    CHAIR SPECIFICATIONS A few important facts about your massage chair. Model No. Max. Time Rate Dimensions (L x W x H) Chair Dimension: 51.2" x 32.7" x 50.4" CZ-680 30 minutes Reclined Dimension: 72.8" x 32.7" x 40.6" Shipping Weight Usage Condition Storage Condition Storage temperature: -20 。...

  • Page 11: Interface

    WIRED TOUCH-PAD INTERFACE We have designed your massage chair’s controller with a user-friendly interface to make using your chair even easier. Home Screen Settings Demo Pre-Programed Massage...
  • Page 12 Create New Program...
  • Page 13 Spot Massage...
  • Page 14 Massage Controls Adjust Strength Name of Program Time Left Power Intensity Foot Roller Light Color Variation Adjust Chair Angle Back Heat...

  • Page 15: Pre-Programed Massage

    PRE-PROGRAMED MASSAGE We have designed your chair with multiple massage options for your changing needs. Follow these simple instructions to begin a new pre-programed massage. Choose 1 of our 10 pre-programed massages (Gentle, Relax, Therapy, Vigourous, Swedish, Japanese, Full Body Stretch, Lower Back Stretch, Upper Back Stretch, Hip and Waist Stretch)
  • Page 16 Pre-Programed Massage Interface...
  • Page 17 Using the arrows, you can adjust the standard shoulder position...
  • Page 18 Adjust Massage Strength Interface In this interface, you can adjust massage 3D strength, tapping speed, kneading strength and air intensity...
  • Page 19 Adjust Chair Angle Interface Adjust your chair quickly by choosing one of the three preset seating positions. You can also press and hold the arrows to adjust parts of the chair independently...
  • Page 20 Change the Light Interface Choose 1 of the 3 types of LED light patterns...

  • Page 21: Demo

    DEMO In order to allow you to quickly understand the many features of this massage chair, we have created a demo mode for you. Choose the "Demo" icon to begin the demo program...
  • Page 22 Demo Interface...
  • Page 23 CUSTOM MASSAGE Every body is different. That’s why we’ve given you the option to customize your massage to meet your specific needs. Follow these simple instructions to create a new custom massage. You can create up to 3 custom programs. To delete a custom massage program, press and hold the icon of the massage you want to delete and choose the “x”.
  • Page 24 Select the massage area that you prefer...
  • Page 25 Select your favorite massage actions. The knead, tap, clap, and shiatsu massages can be combined with swedish or roll...
  • Page 26 Choose the "Custom 1" icon to start your program...
  • Page 27 Custom Interface...

  • Page 28: Spot Massage

    SPOT MASSAGE This is a fixed massage area and actions program. Choose the “Spot Massage” button to take you to the Spot Massage page...
  • Page 29 Spot Massage Interface 1...
  • Page 30 Spot Massage Interface 2...

  • Page 31: Settings

    SETTINGS Choose the “Settings” button to take you to the settings page...
  • Page 32 Settings Interface...
  • Page 33 Trouble Shooting If your chair has any trouble, press the Trouble Shoot "Start" button for the chair to automatically detect problem areas. Use the error code provided when contacting our customer service team...
  • Page 34 Choose "Start" button and make sure the chair is not occupied during chair detection...
  • Page 35 Your chair is detecting possible malfunctions, please wait for the detection result...
  • Page 36 You can use your detection code when contacting the Cozzia customer service team about your chair...

  • Page 37: Auto Program Descriptions

    AUTO PROGRAM DESCRIPTIONS Let’s dig a little deeper and discover the details of our pre-programed massages. DEMO FOCUS AREA INTENSITY FOCUS TECHNIQUE KNEAD ROLL A 5 minute whole body massage for those on the go. GENTLE FOCUS AREA FOCUS AREA INTENSITY INTENSITY FOCUS TECHNIQUE...
  • Page 38 THERAPY FOCUS AREA INTENSITY FOCUS TECHNIQUE KNEAD CLAP A program designed to provide a soothing massage combined with air massage on shoulder and glutes. VIGOROUS FOCUS AREA FOCUS AREA INTENSITY INTENSITY FOCUS TECHNIQUE FOCUS TECHNIQUE KNEAD A program designed for those who enjoy a strong deep tissue massage and provides a boost of energy for users.
  • Page 39 JAPANESE FOCUS AREA FOCUS AREA INTENSITY INTENSITY FOCUS TECHNIQUE FOCUS TECHNIQUE SHIATSU SWEDISH This massage will focus on your midback and upper shoulders with a deep tissue massage using the shiatsu technique, that will create an acupressure effect. FULL BODY STRETCH FOCUS AREA INTENSITY FOCUS TECHNIQUE...
  • Page 40 UPPER BACK STRETCH FOCUS AREA FOCUS AREA INTENSITY INTENSITY FOCUS TECHNIQUE FOCUS TECHNIQUE KNEAD ROLL This program provides you with a upper body stretch, focusing on your shoulder and back muscles. HIP AND WAIST STRETCH FOCUS AREA INTENSITY FOCUS TECHNIQUE KNEAD ROLL This program provides you with a...

  • Page 41: Safety

    SAFETY PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS When using the massage chair, basic precautions should always be followed, including the following: We’re looking out for you. Read all instructions before using this massage chair. DANGER - To reduce the risk of electric shock: •...
  • Page 42 2. Safety Precautions SAVE THESE INSTRUCTIONS • To ensure safe and correct use of the massage chair, do not operate it without reading this This massage chair is intended for household use only. operation manual carefully. • Do not use the massage chair when the upholstery or seat is removed. This may cause 1.
  • Page 43 • This massage chair must only be professionally serviced or repaired. Only disassemble or repair the massage chair if directed by a Cozzia service rep. 6. Things to Be Noted About the Power Plug and Cord •...

  • Page 44: Grounding Instructions

    1. Ensure the chair is plugged into a working outlet are not functioning 2. Turn the power OFF and ON again Grounding Pin If you continue to have problems, please read the warranty card and contact the Cozzia service department. Grounded Outlet Grounded Outlet Box...

  • Page 45: Care Care And Storage

    Cozzia products have the following warranty: The Cozzia CZ-680 has a two-year in home and parts service warranty. Cozzia customer service will not issue Return Material Authorizations (RMAs) for products. Cozzia products will be either repaired by the consumer or •...
  • Page 46 (including damages for lost profits, business interruption, bodily injury, medical and the like). • Warranties are non-transferable. • Cozzia's sole liability and the purchaser's exclusive remedy shall be for the repair, or at Cozzia's option, for the replacement of the defective part.
  • Page 48 861 S. Oak Park Road, Covina, CA 91724 TEL: 1-877-977-0656 FAX: 1-800-521-4712 SERVICE@COZZIAUSA.COM WWW.COZZIAUSA.COM...
