- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 723918 2PC NESTING COFFEE TABLE REVISION 0 : 03/08/2021 REVISION 1 : 09/23/2021 PAGE 1 OF 9 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
723918 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
723918 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION SMALL TOP FRAME 4PCS SMALL LEG HARDWARE IDENTIFICATION BOLT 32PCS 8PCS SUCTION CUP (1/4" x 12mm GD) ALLEN WRENCH 8PCS ∅ 12mm BLK) (4mm) PAGE 3 OF 9 PAGE 3 OF 9 COASTERFURNITURE.COM... - Page 4 723918 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 9 COASTERFURNITURE.COM...
- Page 5 723918 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 COMPLETE PAGE 5 OF 9 COASTERFURNITURE.COM...
- Page 6 723918 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 PAGE 6 OF 9 COASTERFURNITURE.COM...
- Page 7 723918 ITEM: ASSEMBLY INSTRUCTIONS STEP 7 STEP 8 COMPLETE PAGE 7 OF 9 COASTERFURNITURE.COM...
- Page 8 723918 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 908 DIA X 470 H (MM) Product Size : 35.75" DIA X 18.5" 470 mm 18.5" 437 mm 17" 908 mm 35.75" Note : Dimension tolerance ±5% PAGE 8 OF 9 COASTERFURNITURE.COM...
- Page 9 723918 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 546 DIA X 413 H (MM) Product Size : 21.5" DIA X 16.25" 377 mm 413 mm 14.75" 16.25" 546 mm 21.5" Note : Dimension tolerance ±5% PAGE 9 OF 9 COASTERFURNITURE.COM...
