- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 723609 SOFA TABLE REVISION 0 : 12/09/2019 PAGE 1 OF 6 COASTERFURNITURE.COM...
- Page 2 723609 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
- Page 3 723609 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION BOTTOM CROSSBAR 2PCS HARDWARE IDENTIFICATION SHORT BOLT 24PCS (1/4" x 12mm) MEDIUM BOLT 8PCS (1/4" x 18mm) LONG BOLT 8PCS (1/4" x 45mm) SUCTION CUP 4PCS ∅ 10mm) 4PCS (20 x 20mm)
- Page 4 723609 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 723609 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 723609 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 1200 X 400 X 762 H (MM) Product Size : 47 " X 15 " X 30" 60 mm " 50 mm 2" 50 mm 2" 60 mm 762 mm " 30" 838 mm 60 mm 33"...
