950171
CURIO CABINET
BLACK
Assembly INSTRUCTION
COASTER FINE FURNITURE
www.coastercompany.com
PAGE 1 OF 6
2013/06/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 950171 and is the answer not in the manual?

Questions and answers

Summary of Contents for Coaster 950171

  • Page 1 950171 CURIO CABINET BLACK ASSEMBLY INSTRUCTION COASTER FINE FURNITURE www.coastercompany.com PAGE 1 OF 6 2013/06/21...
  • Page 2 ITEM:950171 ASSEMBLY INSTRUCTION PLASTIC BAR DOOR GLASS 1555X382mm INNER SHELF SUPPORT SIDE GLASS 1576X345mm TOP WOOD PANEL BACK GLASS BOTTOM WOOD PANEL 1576X387mm SHELF GLASS www.coastercompany.com PAGE 2 OF 6...
  • Page 3 ITEM:950171 ASSEMBLY INSTRUCTION ALLEN BOLT-LARGE METAL WITH ADHESIVE SMALL BOLT PLASTIC MAGNET METAL CONTACT ADHESIVE SETP 1 : Assemble the Bottom Wood Panel (G) and Inner Shelf Support (E) with Washer (3) and Allen Bolt-Large (2) as illustrated. Tighten bolt with Allen Key (13).
  • Page 4 ITEM:950171 ASSEMBLY INSTRUCTION Step 2 : Insert Back Glass (C) into the Plastic Bars (D) into the side that is less deep.Reference the image closely for this step. Step 3 : Insert each Side Glass (B) downard and into the Plastic Bar (D).
  • Page 5 ASSEMBLY INSTRUCTION ITEM:950171 Step 4 : Place shelf glass (H) on the inner shelf support . Step 5 : Insert Hinge Inserts (5) and Hingers (4) into the top and bottom Panels (F&G) of the frame as illustrated. Insert Plastic Magnets (8) into the top and bottom Panels (F&G) of the frame as illustrated.
  • Page 6 ITEM:950171 ASSEMBLY INSTRUCTION Step 6 : Place Adhesives (11) on top and bottom corners of the Door Glass (A) as illustrated in diagram. Place Handle (9) and Metal Contact (10) on Door Glass (A) over the adhesives. Place Metal With Adhesive (6) on the bottom and top corners of the glass door, then slide the glass door into the Hingers(4).
