Related Manuals for Coaster 900374N
Summary of Contents for Coaster 900374N
- Page 1 900374N WOOD MANTEL ASSEMBLY INSTRUCTION COASTER FINE FURNITURE www.coastercompany.com Page 1 of 6 2012/11/30...
-
Page 2: Assembly Tips
ITEM:900374N ASSEMBLY INSTRUCTION Warning! Use of power tools during assembly of this product may cause damage to the item. It is NOT recommended to use any type of electric screwdriver in the assembly of this product. ASSEMBLY TIPS: • Remove hardware from box and sort by size. -
Page 3: Assembly Instruction
ASSEMBLY INSTRUCTION ITEM:900374N PARTS IDENTIFICATION HARDWARE PACKAGE DESCRIPTION FIGURE A: BASE BOLT FLAT WASHER 36PCS B: LEFT SIDE CABINET WOOD DOWEL 20PCS Knob (with bolt) 2PCS C: RIGHT SIDE SCREW 2PCS CABINET TOUCH-UP PEN D:CENTER FRONT PANEL E: MANTEL/TOP CENTER SHELF www.coastercompany.com... - Page 4 ASSEMBLY INSTRUCTION ITEM:900374N PARTS IDENTIFICATION PARTS IDENTIFICATION G: LEFT UPPER H: RIGHT UPPER SIDE PANEL SIDE PANEL CENTER INSERT BACK SUPPORT STEP 1 STEP 2 Locate the Left Side Cabinet (B), Right Side Locate Base (A) and set out fi nished side up on the Cabinet (C), Center Front Panel (D), and set out fl...
- Page 5 ITEM:900374N ASSEMBLY INSTRUCTION STEP 3 STEP 4 Insert one Wood Dowel (3) into each of the Insert one Wood Dowel (3) into each of the pre-drilled holes in the top edges of the pre-drilled holes. Assembly from step 2. Locate Center Shelf (F) Locate the upper side panels (G, H) on the top of and lay fi...
- Page 6 ITEM:900374N ASSEMBLY INSTRUCTION STEP 7 Install PLEASE READ ALL “ELECTRIC Insert FIREPLACE INSERT” INSTRUCTIONS From PRIOR TO INSTALLING ELECTRIC INSERT Back IN YOUR COMPLETED FIREPLACE MANTEL. INSTALL THE INSERT IN YOUR FIREPLACE CLOSE TO ITS FINAL POSITION. Lift insert carefully into the back of the unit and center in the insert opening.
