- Page 2 Always power the device with the correct rated voltage. ◼ Install the device in a suitable electrical cabinet by following recommended installation instructions. ◼ Failure to take these precautions could cause serious injuries or death. ⓒ 2014 Rootech Inc. All Rights Reserved Page 2...
- Page 3 ◼ About the Manual Rootech, Inc. reserves the right to make changes in the product specifications shown in this User Guide without prior notice. We recommend that customers should obtain the latest information on product specifications and the manual before making orders.
- Page 4 Rootech will decide at its discretion whether to repair or replace it or give a refund for the product for when the warranty period for the product expired or issues related to the product are not applicable for warranty terms and conditions.
- Page 5 The original purchaser should recognize that such defects and failures may cause inaccuracies or malfunctions. No agency, corporate entity, or employee of Rootech or other companies has authority to amend, modify or extend the terms and conditions of this warranty in any way without express written authorization from Rootech, Inc.
- Page 6 1.32 February 8, 2022. Changed the image and text on the cover page, the product’s dimensions, and information on certifications Updated the document according to the latest version of the documentation ⓒ 2014 Rootech Inc. All Rights Reserved Page 6...
-
Page 7: Table Of Contents
EVENT LED / LCD Backlight of Accura 2300[S] .......................... 21 DO Operation Setup in Setup Mode of Accura 2300[S] ....................... 22 Full-Screen Display Mode of Accura 2300[S] ..........................23 Appendix A Specifications ........................24 Appendix B Ordering Information ......................25 ⓒ 2014 Rootech Inc. All Rights Reserved Page 7... - Page 8 Fig 2.4 Operation of the Event LED [Reset with the SET Button While the Event Occurs] ............16 Fig 3.1 GAS Concentration ppm .................................... 21 Fig 3.2 Status of the GAS Event ..................................... 21 ⓒ 2014 Rootech Inc. All Rights Reserved Page 8...
-
Page 9: Chapter 1 Installation And Wiring
Chapter 1 Installation and Wiring Before Installation Components Fig 1.1 Accura GAS Components mounting Accura 2350-GAS Mounting wings L/S RJ12 6C communication line screws Dimensions Fig 1.2 Accura 2350-GAS Front Fig 1.3 Accura 2350-GAS Rear ⓒ 2014 Rootech Inc. All Rights Reserved Page 9... -
Page 10: Installation
1) Determine where to install the module considering the flow path of combustible gases. 2) If there is no specific gas flow path, install it in the upper part of the installation space, considering the rise of gas. ⓒ 2014 Rootech Inc. All Rights Reserved Page 10... -
Page 11: Din-Rail Mounting
The number of Accura 2350-GAS modules that can be connected to Accura 2300 or Accura 2300S is limited to 6 with 3 modules connected to each of RJ12-1 and RJ12-2 ports. Fig 1.7 Communication Cable Connection ⓒ 2014 Rootech Inc. All Rights Reserved Page 11... -
Page 12: Chapter 2 Accura 2350-Gas Operation/Setup
10 kΩ based on the methane concentration of 1000 ppm, and measurements are performed in the condition where the load resistance of the gas sensor is 18 kΩ. 2. An Over event consists of a start event and an end event. ⓒ 2014 Rootech Inc. All Rights Reserved Page 12... -
Page 13: Operation Mode
When an event occurs, the maximum ppm value of gas and the event LED blink. Users can reset the event mode by long pressing the SET button, and the screen returns to the display mode. Setup mode Configures events and remote control ⓒ 2014 Rootech Inc. All Rights Reserved Page 13... -
Page 14: Button Operation
If there is no button operation for 10 seconds in the setup mode, the screen automatically returns to the display mode. If there is no button operation for 25 seconds in the edit mode, it automatically returns to the display mode. ⓒ 2014 Rootech Inc. All Rights Reserved Page 14... -
Page 15: Lcd Screen
The screen displays the output voltage of the gas sensor of Accura 2350-GAS module as the ppm value converted as shown in Figure 2.2. Display Description PPM [d][d][d] Gas ppm [parts per million] 100 – 10.0k Displays a value from 100 ppm to 10,000 ppm ⓒ 2014 Rootech Inc. All Rights Reserved Page 15... -
Page 16: Event Mode
Fig 2.4 Operation of the Event LED (Reset with the SET Button While the Event Occurs) with hysteresis threshold end event start event start event Gas Over Start Event End Event Button Clear Button clear ⓒ 2014 Rootech Inc. All Rights Reserved Page 16... -
Page 17: Setup Mode
1. An Over event consists of a start event and an end event. ⓒ 2014 Rootech Inc. All Rights Reserved Page 17... - Page 18 Remote Control Setup Remote Control on[On, Default] Remote device setup and control is enabled via communication. oFF[Off] Remote device setup and control is disabled via communication. ⓒ 2014 Rootech Inc. All Rights Reserved Page 18...
-
Page 19: Communication Setup
Sets up the hysteresis value for event detection The end level of the event is determined by subtracting the hysteresis value from the threshold value (threshold –hysteresis). Setup range: 10 – 999 [PPM] Default: 500 [PPM] ⓒ 2014 Rootech Inc. All Rights Reserved Page 19... -
Page 20: Led Indicator
If the remote control function is enabled in the Accura 2350-GAS module, the event LED can be reset by pressing the EVENT button on Accura 2300[S]. Once users check the event by pressing the button, the LED is automatically reset. ⓒ 2014 Rootech Inc. All Rights Reserved Page 20... -
Page 21: Chapter 3 Accura 2300[S] Operation/Setup
GAS module can be reset remotely by long-pressing the EVENT button on Accura 2300[S]. However, if remote control settings are disabled, its LED can be reset only with the SET button on the Accura 2350- GAS module. ⓒ 2014 Rootech Inc. All Rights Reserved Page 21... -
Page 22: Do Operation Setup In Setup Mode Of Accura 2300[S]
Users can clear the output status in the event log mode by long-pressing the EVENT button on Accura 2300[S]. In the event log mode, users can check event data and can also clear the event alarm and DO signals. ⓒ 2014 Rootech Inc. All Rights Reserved Page 22... -
Page 23: Full-Screen Display Mode Of Accura 2300[S]
Accura 2350-GAS User Guide Chapter 3 Accura 2300[S] Operation/Setup Full-screen Display Mode of Accura 2300[S] It displays the measured values of Accura 2300[S] and the selected Accura 2350 module. ⓒ 2014 Rootech Inc. All Rights Reserved Page 23... -
Page 24: Appendix A Specifications
Storage temperature -20 to 85 ℃ (-40 to 185 ℉) Operating humidity 5 to 95 % (non-condensing) Operating altitude Up to 2,000 m 1. Compliant with the UL61010-1 standard (3rd edition) ⓒ 2014 Rootech Inc. All Rights Reserved Page 24... -
Page 25: Appendix B Ordering Information
Accura 2350-GAS User Guide Appendix B Ordering Information Appendix B Ordering Information Model Accura 2350 - GAS ⓒ 2014 Rootech Inc. All Rights Reserved Page 25... - Page 26 Accura 2300/2350, Accura 2300S/2350, Accura 2700/2750, Accura 3000, Accura 3300E, Accura 3300S/3300, Accura 3500S/3500, Accura 3550S/3550, Accura 3700, Accura 5500, and Accura 7500 are trademarks of Rootech Inc. Contact us for detailed product specifications and ordering information. Information contained herein is subject to change without notice.
