- Page 2 Accura 2350-TEMP User Guide Notice Manual Rootech Inc. reserves the right to make changes in the device specifications shown in this User Guide without notice. Therefore, we recommend that customers should check the latest information on specifications of the device before making orders.
- Page 3 Rootech will decide at its discretion whether to repair or replace it or give a refund for the product for when the warranty period for the product expired or issues related to the product are not applicable for warranty terms and conditions.
- Page 4 Warranty Accura 2350-TEMP User Guide Rootech shall not be liable for any other claims except the claims made by customers, including the original purchaser, his employees, agents, or contractors for any loss, damage, or expense incurred related to the purchased product when the above warranty terms and conditions are not fulfilled.
- Page 5 Accura 2350-TEMP User Guide Revision History Revision History The revision history of the Accura 2350-TEMP user guide is as follows. Revision Date Description 1.10 2020. 9. 29 First issue ⓒ 2020 Rootech Inc. All Rights Reserved Page 5...
-
Page 6: Table Of Contents
Digital Output (DO) ....................................21 Function ........................................... 22 Measuring External Temperature of the Distribution Panel ....................22 Collecting Internal Temperature Data of the Distribution Panel ..................22 Temperature Events ....................................22 Page 6 ⓒ 2020 Rootech Inc. All Rights Reserved... - Page 7 Accura 2300S Setup Mode .................................. 37 Accura 2300S Event Log Mode ................................37 APPENDIX A Specifications .............................. 40 Accura 2350-TEMP Module ................................. 40 Accura TSEN ........................................ 41 General ........................................... 41 APPENDIX B Ordering Information ..........................42 ⓒ 2020 Rootech Inc. All Rights Reserved Page 7...
- Page 8 Fig 3.1 Accura 2350-TEMP Device Composition ........................18 Fig 3.2 Event Alarms and Reset ............................... 23 Fig 4.1 Temperature Events Screen ..............................38 Fig 4.2 Event Occurrence Time ................................. 38 Fig 4.3 DI Events Screen ..................................39 Page 8 ⓒ 2020 Rootech Inc. All Rights Reserved...
-
Page 9: Chapter 1 Installation & Wiring
Fig 1.1 Accura 2350-TEMP Accura 2350-TEMP Front Accura 2350-TEMP Rear Accura 2350-TEMP Side Fig 1.2 Accura TSEN Components Fig 1.3 Accura 2350-TEMP Components Accura 2350-TEMP device RJ12 communication cable Fixing wheel ⓒ 2020 Rootech Inc. All Rights Reserved Page 9... -
Page 10: Dimensions
Chapter 1 Installation and Wiring Accura 2350-TEMP User Guide Fig 1.4 Accura TSEN Components Accura TSEN device Fixing wings/screws Dimensions Fig 1.5 Accura 2350-TEMP Front Fig 1.6 Accura 2350-TEMP Rear Fig 1.7 Accura TSEN Page 10 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 11: Installation Example
Accura TSEN devices are installed inside the distribution panel. The Accura 2350-TEMP module has 1 DI(Digital Input) and 1 DO(Digital Output) channel, allowing for installation of the event reset switch and warning light. Fig 1.8 Accura 2300/2350-TEMP Installation Diagram ⓒ 2020 Rootech Inc. All Rights Reserved Page 11... -
Page 12: Step 1: Accura 2350-Temp Installation
You can easily turn the wheel with your hands. If you use excessive force when turning the wheel, it can cause damage to the LCD screen of the Accura 2350-TEMP module. Fig 1.9 Accura 2350-TEMP Panel Installation Fig 1.10 Mounting Accura 2350-TEMP to the Panel through Holes Page 12 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 13: Connection With Accura 2300S Using The Communication Cable
① Connect the RJ12 6C communication cable to RJ12A/ RJ12B ports. (Accura 2350-TEMP receives power from Accura 2300S via the RJ12 6C communication cable). Fig 1.11 Connection between Accura 2350-TEMP and Accura 2300S using the Communication Cable ⓒ 2020 Rootech Inc. All Rights Reserved Page 13... -
Page 14: Step 2: Accura Tsen Installation
② Once one side of the device is latched on the rail, push the other side towards the panel so that Accura TSEN can get snapped onto both ends of the DIN rail flanges. Fig 1.13 Accura TSEN DIN Rail Mounting Page 14 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 15: Connection With Accura Tsen Using The Communication Cable
① Connect the Ethernet communication cable to RJ45A/ RJ45B ports. (Accura 2350-TEMP supplies power to Accura TSEN via the RJ45 Ethernet communication cable). Fig 1.14 Wiring Accura 2350-TEMP and Accura TSEN Devices with the Communication Cable ⓒ 2020 Rootech Inc. All Rights Reserved Page 15... -
Page 16: Chapter 2 Accura Tsen Operation/Setup
Up to 5 Accura TSEN devices can be connected to the Accura 2350-TEMP module using the daisy-chain method. The factory default ID number is set to 0. ID 0 indicates the standby ID and does not support communication. Page 16 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 17: Reset Button
STS21 (located at the bottom end of the device) Sensirion’s CMOS sensor technology Accuracy error typ. 1.0 ℃ Temperature -20 − 100 ℃ measuring range Response time Maximum 30 seconds [τ 63%] ⓒ 2020 Rootech Inc. All Rights Reserved Page 17... -
Page 18: Chapter 3 Accura 2350-Temp Operation/Setup
「Chapter 1 Installation and Wiring > Step 1: Accura 2350-TEMP Installation」. Device Composition The device composition of the Accura 2350-TEMP module is as follows. Fig 3.1 Accura 2350-TEMP Device Composition Front Rear Page 18 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 19: Power Supply
Long press Change display mode to EVENT mode. ENTER Long press Enter function 1. Press the button and release it immediately. 2. Release the button after pressing it for 0.5 seconds. ⓒ 2020 Rootech Inc. All Rights Reserved Page 19... -
Page 20: Rj12 Communication Port
Wire specs 0.21 – 3.5 mm (24 – 12AWG) Insulation method Uninsulated Input type Open/Closed contact point (internal power is used) Minimum time the contact 20 msec point is in closed status Page 20 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 21: Digital Output (Do)
DO when an event occurs. Item Description Port name DO, DOG / Mechanical Relay, Form-A Connector type Screw-type terminal Wire specs 1.5 – 3.5 mm (16 – 12AWG) Insulation AC 2,000V/1min. Output rating 5A/250Vac, 5A/30Vdc ⓒ 2020 Rootech Inc. All Rights Reserved Page 21... -
Page 22: Function
After the delay time passes in the state where the measured temperature exceeds the threshold level, a start event occurs. If the measured temperature drops below the preset threshold of - 2 ℃, an end event occurs. Page 22 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 23: Dio Events
However, there is no event alarm for DI and DO events. Users can check data on the contact point status and occurrence time of DI and DO events by entering the event mode on the LCD screen. ⓒ 2020 Rootech Inc. All Rights Reserved Page 23... -
Page 24: Display Mode
Indicates the number of connected Accura TSEN devices 1. d → decimal number, the number cannot exceed 5. It indicates the ID of the Accura TSEN device with the highest temperature. Page 24 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 25: In Tsen Column
Detailed Temperature Data Screen Description Current temperature for the Accura 2350-TEMP module Average temperature after resetting the Max/Min values Maximum temperature after resetting the Max/Min values Minimum temperature after resetting the Max/Min values ⓒ 2020 Rootech Inc. All Rights Reserved Page 25... -
Page 26: Digital Io Column
It indicates information on the Accura 2350-TEMP module and Accura TSEN device. Screen Description Serial Num Serial number of the product Firmware Ver Firmware version Bootloader Ver Bootloader version Hardware Ver Hardware version Page 26 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 27: Setup Mode
Column 4 EVENT SETUP DIO SETUP INTERFACE SETUP SYSTEM Button Operation Button Description DISPLAY Mode Short press Select the screen with the left/right and up/down buttons. Long press Enter SETUP mode ⓒ 2020 Rootech Inc. All Rights Reserved Page 27... - Page 28 3. If there is no button operation during the timeout for completing the setup(default: 600 seconds) in the SETUP mode/ the mode where you can change settings, the screen automatically returns to the DISPLAY mode. Page 28 ⓒ 2020 Rootech Inc. All Rights Reserved...
-
Page 29: Event Setup
1. d → decimal number, the number cannot exceed 5. It indicates the ID of the Accura TSEN device. 2. It indicates the highest temperature on the Accura TSEN device. 3. It indicates the lowest temperature on the Accura TSEN device. ⓒ 2020 Rootech Inc. All Rights Reserved Page 29... -
Page 30: Dio Setup
Polarity of the logic value for the contact point Normal of the DI - Normal mode 0: Open point 1: Closed point - Reverse mode 0: Closed point 1: Open point Page 30 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 31: Interface Setup
LCD Backlight Screen Setup item Range Default Timeout 30 – 999 sec 60 sec Brightness 0 – 100 % 70 % Contrast 1 – 40 % 18 % ⓒ 2020 Rootech Inc. All Rights Reserved Page 31... -
Page 32: System Setup
Summary Type Sets up the main screen of the SUMMARY Highest column Highest / All TSEN 1. It indicates the ID number assigned as the factory default value. Communication is unavailable. Page 32 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 33: Event Mode
Digital inputs/output events provide data on the status of the contact point. Entire Screen Column 1 (ALL EVENT) Column 2 (TEMP EVENT) Column 3 (DIO EVENT) ⓒ 2020 Rootech Inc. All Rights Reserved Page 33... - Page 34 Long press Return to the DISPLAY mode after checking event data. DISPLAY Mode 1. Press the button and release it immediately. 2. Release the button after pressing it for 0.5 seconds. Page 34 ⓒ 2020 Rootech Inc. All Rights Reserved...
-
Page 35: Chapter 4 Accura 2300S Operation/Setup
Accura 2350-TEMP module only through the setup mode on the device. Accura 2300S Display Mode Entire Screen It shows measurement data on the Accura 2300S device and the selected Accura 2350 module. ⓒ 2020 Rootech Inc. All Rights Reserved Page 35... - Page 36 ID on the top left part of the device. Module Column Description Accura 2350-TEMP Displays the measured values of internal temperatures of the Accura TSEN.1 device Displays the measured values of internal temperatures of the Accura TSEN.2 device Page 36 ⓒ 2020 Rootech Inc. All Rights Reserved...
-
Page 37: Accura 2300S Event Alarms
Users can also check detailed data on the events in the Accura 2350-TEMP module in the event log mode on the Accura 2300S device. Events on the Accura 2350-TEMP module include temperature events and DI/DO events. ⓒ 2020 Rootech Inc. All Rights Reserved Page 37... -
Page 38: Fig 4.1 Temperature Events Screen
Fig 4.2 Event Occurrence Time First row Year Second row Month, date Third row Hour, minute Fourth row Second, millisecond Page 38 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 39: Fig 4.3 Di Events Screen
Module where the event occurred: TEMP module Third row Digital input events Digital output events Fourth row cLoS The contact point is closed. oPEn The contact point is open. 1. d → decimal number. ⓒ 2020 Rootech Inc. All Rights Reserved Page 39... -
Page 40: Appendix A Specifications
STS21 (located at the front bottom of the device) Sensirion’s CMOS sensor technology Accuracy error typ. 1.0 ℃ Temperature -20 − 100 ℃ measuring range Response time [τ 63%] Maximum 30 seconds Page 40 ⓒ 2020 Rootech Inc. All Rights Reserved... -
Page 41: Accura Tsen
-20 to 65 C (-4 to 149 ℉) Storage temperature -40 to 85 C (-40 to 185 ℉) Operating humidity 5 to 95 % (non-condensing) 1. Compliant with the UL 61010-1 standard ⓒ 2020 Rootech Inc. All Rights Reserved Page 41... -
Page 42: Appendix B Ordering Information
APPENDIX B Ordering Information Accura 2350-TEMP User Guide APPENDIX B Ordering Information Model Name Accura 2350-TEMP Accura TSEN Page 42 ⓒ 2020 Rootech Inc. All Rights Reserved... - Page 43 ⓒ 2020 Rootech Inc. All Rights Reserved Accura EMeter, Accura 2300/2350, Accura 2300S/2350, Accura 2700/2750, Accura 3000, Accura 3300E, Accura 3300S/3300, Accura 3500S/3500, Accura 3550S/3550, Accura 3700, Accura 5500, Accura 7500 are trademarks of Rootech Inc. Contact Rootech for detailed specifications and order information.
