Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to
them during installation to ensure that your product is fitted safely
and that it retains its high quality finish.
Eclipse Square
FI#01 004 R210304
Art No 21200
Ver No.
1.1 Nov 2015
Advertisement
Table of Contents
Related Manuals for HiB LIBRA 21400
Summary of Contents for HiB LIBRA 21400
- Page 1 Libra Eclipse Round Eclipse Square Thank you for purchasing this HiB product. Please read through these instructions carefully and refer back to them during installation to ensure that your product is fitted safely and that it retains its high quality finish.
- Page 2 Electrical Safety Information HiB recommends that all electrical bathroom products must be installed in accordance with current building and wiring regulations. If in doubt please contact an electrician. Before drilling ensure that there are no hidden cables or pipes in the wall.
- Page 3 Earth is Green and Yellow earth Earth supply is Green and Yellow Neutral is Blue neutral Neutral supply can be Blue or Black LUMINAIRE MAINS SUPPLY What’s in the Box? • Mag Mirror • Wall bracket • Fittings pack hib.co.uk...
- Page 4 Tools Required Pencil Spirit Level Drill Drill bit Screwdriver Figures WALL BRACKET FIXING POINT MIRROR BASE Fig 2. - Libra FIXING POINT MIRROR BASE WALL BRACKET Fig 3. - Eclipse ROCKER SWITCH...
- Page 5 8. Place the mirror onto the wall bracket and secure into place using the fixing(s) on the mirror base – take care not to trap wiring when assembling the mirror onto the wall bracket. 9. Switch on the domestic electrical mains supply to the mirror. hib.co.uk...
- Page 6 BLANK PAGE...
- Page 7 Turn On Illumination Pull the mirror away from the wall. Turn Off Illumination Push the mirror back towards the wall. ECLIPSE Turn On/Off Illumination Illumination is switched on and off by the rocker switch on the underside of the mirror base. hib.co.uk...
- Page 8 Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary.
