Yolink YS4102-UC User Manual page 15

Smart sprinkler controller
Hide thumbs
Table of Contents

Advertisement

Wiring diagram
Common Wire (C)
Zone 1 (1)
Zone 2 (2)
Zone 3 (3)
Zone 4 (4)
1 2 3 4 5 6 M C C R
Common Wire (C)
Master Valve (M)
Zone 6 (6)
24V AC
Adapter
24V AC
Output
24V AC Common Wire (C)
24V AC Live Wire (R)
Zone 5 (5)
13
