Hunter 44377 Owner's Manual

7 day programmable thermostat
Hide thumbs Also See for 44377:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
5 MINUTE
I N S T A L L A T I O N
Owner's Manual
7 Day Programmable
M T W T F S S
Model
44372
44377
Form# 44040-01
20100511
©2010 Hunter Fan Co.

Advertisement

Table of Contents
loading

Related Manuals for Hunter 44377

Summary of Contents for Hunter 44377

  • Page 1 Owner’s Manual 5 MINUTE I N S T A L L A T I O N 7 Day Programmable M T W T F S S Model 44372 44377 Form# 44040-01 20100511 ©2010 Hunter Fan Co.

  • Page 2: Table Of Contents

    Additional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 0 Thermostat Assistance Troubleshooting and Support .

  • Page 3: At A Glance

    14 to alter your temperature settings. There is no need to program the thermosat at the wall it is mounted to! Remove the thermostat from the backplate by gripping the sides firmly and pulling it straight off. This allows you to program the thermostat in comfort.
  • Page 4 4. Confirms completion of an action or returns you to the Home screen. 5. Allows access to the advanced features of the thermostat. 6. Moves you forward or backward while setting up features or schedules. 7. Adjusts time and temperature settings as well as moving up or down menu lists.
  • Page 5 At A Glance Know Your Thermostat Done/ Home ©2010 Hunter Fan Company...
  • Page 6 NOTE: If you are unsure of your system type it may be necessary to contact our technical support department, your HVAC manufacturer, or a local HVAC technician to determine this. Improper selection of your system type could cause the thermostat to not operate your system properly.
  • Page 7 At A Glance Know Your Thermostat ©2010 Hunter Fan Company...
  • Page 8 17. Indicates the Thermostat is running in save away mode. 18. Will show when your heat pump or system is reporting a problem to the Thermostat. 19. Indicates in hours or days how long the Save Away period is set for.
  • Page 9 Filter Auto At Home Check H.P.! Hours Energy Savings: Good Know Your Thermostat Aux Em. Heat to Best! ©2010 Hunter Fan Company At A Glance Lock...

  • Page 10: Setup

    5. When finished, the thermostat will show “Updated!” to confirm your settings are saved. 6. Your thermostat will next prompt you to set your programming, see page 14 step 2 if you wish to alter your programs at this time.

  • Page 11: Mon

    Home Today Save Away Done/ Back Home Menu Schedule Home Today Save Away Next Done/ Back Home Schedule Updated! Home Today Save Away Done/ Next Back Home ©2010 Hunter Fan Company Setup Setting Day and Time Next Menu Next Menu...

  • Page 12: Scheduling

    * The scheduled temperature can be set in increments of 1°F (1°C). * After 15 minute without a key press, the thermostat will return to the home display screen. * When setting the schedule time, note the AM / PM indicator.

  • Page 13: Personal Scheduling Charts

    Heat Temp: Cool Temp: Start Time: End Time: Heat Temp: Cool Temp: Start Time: End Time: Heat Temp: Cool Temp: ©2010 Hunter Fan Company Scheduling Personal Scheduling Charts Home Heat Temp: F (20 Cool Temp: F (26 Heat Temp: F (20...
  • Page 14 2. Use the buttons to select “On” and then Note: If you do not wish to use the scheduling option on your thermostat, refer to page 22, step 2. 3. Monday will be flashing on the screen, to proceed with scheduling, press...

  • Page 15: Setting Your Schedule

    Schedule Schedule On Home Today Save Away Next Back Schedule Away Asleep At Home Home Today Save Away Next Back ©2010 Hunter Fan Company Scheduling Setting Your Schedule Done/ Next Home Menu Energy Savings: Good Best! Done/ Next Home Menu...
  • Page 16 “Cool to”. Set this temperature with your buttons and hit 7. The thermostat will start this process again for “Asleep”. Repeat steps 1-5 to schedule the time and set the temperature for your sleep period. When finished pressed Home”...

  • Page 17: Energy Savings

    At Home Home Today Save Away Next Back Schedule Schedule Updated! Home Today Save Away Next Back ©2010 Hunter Fan Company Scheduling Setting Your Schedule Heat to Cool to Energy Savings: Good Best! Done/ Next Home Menu Done/ Next Home Menu...
  • Page 18 Scheduling Setting Your Schedule 10. The day select screen will now show “Copy Day” and ask you if you wish to copy the day you just scheduled to any other days. Select “YES” and “NO”. 11. Select each day you wish to copy the schedule to by using the on or off and the Next day will indicate it has been selected.
  • Page 19 Today Save Away Done/ Back Home Menu Schedule Home Today Save Away Next Back Schedule Schedule Updated! Home Today Save Away Next Back ©2010 Hunter Fan Company Scheduling Setting Your Schedule Tues Done/ Next Home Menu Done/ Next Home Menu...

  • Page 20: Temporary Temperature Change

    Note: Temporary Temperature Change is not a permanent setting. Your thermostat will only run the new temperature until the next scheduled period change. After your thermostat changes to a new schedule set, your thermostat will forget the temporary setting and resume your existing schedule.
  • Page 21 Temporary Schedule Change Schedule At Home Auto Home Today Save Away Good Done/ Next Back Home Schedule Schedule On Home Today Save Away Done/ Next Back Home ©2010 Hunter Fan Company Scheduling Heat to Energy Savings: Best! Next Menu Next Menu...

  • Page 22: Turning Off Scheduling

    Scheduling Turning Off Scheduling To turn off your schedule and have the thermostat permanently set to one temperature: 1. Press the button once. Schedule 2. Use the button to switch to Off and select 3. The screen will show “Updated!” and return you to the home screen.

  • Page 23: Home Today 2

    Energy Savings: Away Good Best! Done/ Back Home Menu Schedule Updated! Home Today Save Away Done/ Back Home Menu Schedule Schedule On Home Today Save Away Next Back Next ©2010 Hunter Fan Company Scheduling Turning Off Scheduling Done/ Next Home Menu...
  • Page 24 The Home Today feature allows you to override your schedule for 1 day. It can be used for example if you are home on a day when you would normally have the thermostat‘s “Away” mode active. When used, the Home Today feature will select your At Home temperature to run at for the course of the day until your scheduled Asleep time starts, then revert back to running your normal schedule.

  • Page 25: Home Today

    Best! Done/ Back Home Menu Schedule Updated! Home Today Save Away Done/ Back Home Menu Schedule Home Today Save Away Good Done/ Next Back Home Next ©2010 Hunter Fan Company Scheduling Home Today Heat to Energy Savings: Best! Next Menu...

  • Page 26: Save Away

    Scheduling Save Away The Save Away feature allows you to set a lower or higher temperature for the time you will be away from your home outside of your normal Away schedule. This can include days you will be away for vacation, or a few hours away from your home. The Save Away feature can be set for as little as 1 hour or as much as 30 days.
  • Page 27 Done/ Back Home Menu Schedule Updated! Home Today Save Away Done/ Back Home Menu Schedule Home Today Hours Save Away Good Done/ Next Back Home Next ©2010 Hunter Fan Company Scheduling Save Away Heat to Energy Savings: Best! Next Menu...

  • Page 28: Features

    Features Alerts This chapter will outline the various alerts the thermostat will report to you and how to respond to them. 1. Low Battery: This icon will appear when your batteries are starting to run low on power and should be changed to avoid system interruptions, (Figure 1) Change the batteries by gripping the sides of the thermostat firmly and pulling straight back, (Figure 1a).

  • Page 29: Alerts

    Back Home Menu Schedule Home Today Save Away Done/ Back Home Menu Next Schedule Filter At Home Auto Home Today Save Away Good Done/ Next Back Home ©2010 Hunter Fan Company Features Alerts Heat to Energy Savings: Best! Next Menu...
  • Page 30 Features Alerts 3. Auxiliary Heat: On multi-stage heat pumps this alert indicates your second stage heat is running. 4. Check System: Some heat pump systems are equipped with the ability to check system performance, indicated by the presence of an “L” wire attached to the mounting plate.
  • Page 31 Heat to Today Save Energy Savings: Away Good Best! Done/ Back Home Menu Schedule At Home Auto Home Today Save Away Good Done/ Next Back Home ©2010 Hunter Fan Company Features Alerts Heat to Check H.P.! Energy Savings: Best! Next Menu...

  • Page 32: Menu Options

    Under your menu options you have the ability to reset your filter counter, change your day/time , span settings, temperature measurement, as well as locking the thermostat. After making changes to each menu option, the thermostat will show “Updated” and save your changes.
  • Page 33 Home Today Save Away Next Back Schedule Reset Filter Home Today Save Away Next Back ©2010 Hunter Fan Company Features Menu Options Reset Filter Set Day/Time Span 1 Span 2 Span 3 Temp F/C Lock Done/ Next Home Menu Set Day/Time...
  • Page 34 1 which will allow the system to turn on .5 above or below the set temperature and run for .5 set temperature. Example: If your thermostat is set to turn on at 72 of 2, your thermostat will activate your furnace at 71 . For cooling at 72 and shut down at 71 .
  • Page 35 Back Home Menu Schedule Span 1 Home Today Save Away Done/ Next Back Home Schedule Home Span 3 Today Save Away Done/ Next Back Home ©2010 Hunter Fan Company Features Menu Options Span 2 Next Menu Temp F/C Next Menu...
  • Page 36 Features Menu Options 1. LOCk/UNLOCk: Allows you to lock the thermostat so random keypress’ will not change your settings. Use the Choose “YES” to lock the thermostat or “NO” to keep the thermostat unlocked. Press , the screen will flash “Updated” and return to menu options or press Next to return the home screen.
  • Page 37 Schedule Reset Filter Set Day/Time Span 1 Span 2 Home Span 3 Today Temp F/C Save Lock Away Next Back ©2010 Hunter Fan Company Features Menu Options Auto Heat to Energy Savings: Lock Good Best! Done/ Next Home Menu Lock...

  • Page 38: Energy Saver Bar

    Energy Saver Bar The Energy Saver Bar indicates estimated energy savings. The preset schedules in the thermostat have been designed to give you optimal energy savings, five bars. Altering these schedules has a direct impact on the energy saver indicator. Altering the temperatures and/or times that the schedules run could decrease the estimated energy savings.
  • Page 39 Heat to Today Save Energy Savings: Away Good Best! Done/ Back Home Menu Schedule At Home Auto Home Today Save Away Good Done/ Next Back Home ©2010 Hunter Fan Company Features Energy Saver Bar Heat to Energy Savings: Best! Next Menu...

  • Page 40: Additional Features

    Additional Features Armchair Programming There is no need to stand at the wall where the thermostat is mounted while programming or changing settings. Simply remove the thermostat from the wall and make the necessary changes in the comfort of a chair. You can also set your programming and settings before you even install the thermostat.

  • Page 41: Thermostat Assistance

    Solution: 1. Check the time in all programs for proper am/pm time. 2. Ensure thermostat is not in “Save Away” mode. 3. Make sure the thermostat is set to the proper day. Problem: Auto / Fan does not turn on.
  • Page 42 Thermostat Assistance Troubleshooting and Support Problem: Fan runs continuously. Solution: 1. Check fan setting to see if it is set to on. 2. Move HG/HE switch to opposite position. Problem: Heating or cooling does not turn on or off. Solution: 1.

  • Page 43: Technical Support

    Thermostat Assistance Troubleshooting and Support Technical Support If you need any assistance with installion or setup of your new Hunter Thermostat, please call us, our technical support staff is ready to help! USA: 1-888-830-1326 Canada: 1-866-268-1936 Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am to 5:00 pm on Saturday, Central Time.

  • Page 44: Warranty

    Thermostats LIMITED WARRANTY The Hunter Fan Company warrants your Hunter Thermostat to be free from defects in material or workmanship for a period of one year from the date of sale to the original user or consumer purchaser. If your Hunter Thermostat malfunctions or fails within the warranty period because of a defect in material or workmanship, we will replace it.
  • Page 45 Proof of purchase is required when requesting warranty service. IN NO EVENT SHALL HUNTER FAN COMPANY BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED...
