  • Page 1 Henny Penny Open Fryer Electric Model OE-100 TECHNICAL MANUAL...
  • Page 3 0 TO 3 YEARS: During this time, any frypot that fails due to manufacturing or workman- ship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.

  • Page 4: Table Of Contents

    3-1. INTRODUCTION ..................3-1 3-2. GENUINE PARTS ..................3-1 3-3. WHEN ORDERING ..................3-1 3-4. PRICES ......................3-1 3-5. DELIVERY ....................3-1 3-6. WARRANTY ....................3-1 RECOMMENDED SPARE PARTS FOR DISTRIBUTORS ......3-1 Henny Penny Distributor List (Domestic and International) FM06-001 Revised 4-02-09...

  • Page 5: Troubleshooting

    Model OE-100 SECTION 1. TROUBLESHOOTING 1-1. INTRODUCTION This section provides troubleshooting information in the form of an easy-to-read table. If a problem occurs during the first operation of a new fryer, recheck the installation per Section 2 of the Operator Manual.
  • Page 6 Model OE-100 Problem Cause Correction With switch in COOK Open circuit • Check to see if unit is plugged in. position and switch light not illuminated, • Check breaker or fuse at supply fryer is completely box. inoperative (no power).

  • Page 7: Maintenance

    Henny Penny Model OE-100 SECTION 2. MAINTENANCE 2-1. INTRODUCTION This section provides procedures for checking and replacement of the various parts used within the unit. Before replacing any parts, refer to Section 1, Troubleshooting. It will aid you in determining the cause of a particular malfunction.
  • Page 8 Model OE-100 2-3. REMOVING THE CONTROL PANEL (Continued) 2. Control panel swings out, hinged on the left side of the panel. When completely removing control panel, all wiring must be unplugged from control panel. Be sure to mark wires before removing.
  • Page 9 Model OE-100 4. Unplug electrical wires from control panel board that are attached 2-4. TEMPERATURE PROBE to temperature probe. (Continued) 5. Using a 1/2" wrench, loosen screw nut from pot fitting and pull temperature probe bulb straight out from pot fitting.

  • Page 10: High Temperature Limit Control

    Model OE-100 2-5. HIGH TEMPERATURE LIMIT CONTROL (Continued) Before following these steps, place POWER switch in the OFF position and unplug the power cord or open the wall circuit breaker. 1. If the tube is broken or cracked, the control will open, shutting off electrical power.

  • Page 11: Heating Elements

    Model OE-100 15. With excess capillary tube pulled out, tighten smaller nut. 2-5. HIGH TEMPERATURE LIMIT (Continued) Do not overtighten nut or damage to capillary tube may result. 16. Replace front panel. 17. Refill with shortening. 2-6. HEATING ELEMENTS Heating elements are available for 208 and 480 voltage.
  • Page 12 Model OE-100 2-6. HEATING ELEMENTS Replacement (Continued) 1. Drain the shortening from the frypot. 2. Remove the heating element wire from the terminals by removing the nuts and washer. Label each so it can be replaced in the same position on the new element.
  • Page 13 Model OE-100 2-7. CONTACTORS SHOCK HAZARD The following tests are performed with the wall circuit breaker closed and the Power switch in the ON position. Make connections before applying power, then take read- ings. Remove power before removing meter leads, or electrical shock may result.

  • Page 14: Contactors

    415 from 33 to 37 ohm reading 415 The Henny Penny OE-100 has a fan in the circuit which operates only 2-8. when the power switch is in the COOK position. The fan helps keep the control panel cool by pulling out heat from between the control panel and frypot.

  • Page 15: Cook/Pump Switch

    Model OE-100 2. Label and disconnect fan motor wires. 2-8. FAN (Continued) 3. Remove the four screws, washers, and nuts securing the fan to the heat shield. 4. Remove the fan from the heat shield. 5. Install the new fan on the heat shield and secure with the four screws, washers, and nuts.

  • Page 16: Fuses

    Model OE-100 2-10. FUSES SHOCK HAZARD To avoid electrical shock or property damage, move the power switch to “OFF” and disconnect main circuit breaker, or unplug cord at wall receptacle. Each unit is provided with two fuses to protect the internal circuitry.

  • Page 17: Filter Heater Switch

    Model OE-100 The Filter Heater Switch is a rocker type switch. With the switch in the 2-12. FILTER HEATER "ON" position, the filter heater will operate, melting any solidified SWITCH shortening in the filter lines. Checkout SHOCK HAZARD To avoid electrical shock or property damage, move the power switch to “OFF”...
  • Page 18 Model OE-100 This unit is equipped with a strip heater in the event solidified shorten- 2-13. FILTER HEATER ing accumulates in the filter pump lines. If this heater becomes defec- tive, replace by following these steps. SHOCK HAZARD To avoid electrical shock or property damage, move the power switch to “OFF”...

  • Page 19: Filtering System

    Model OE-100 The filtering system consists of the filter valve, motor and filter pump 2-14. FILTERING SYSTEM assembly, filter screen assembly, and tubing. The hose and fittings should be checked daily. Hot short- ening causes the rubber hose to age and deteriorate. If aging or discoloration is seen, the hose should not be used.

  • Page 20: Filter Valve

    Model OE-100 The filter valve is a 3/8 inch two-way stainless steel ball valve. If this 2-15. FILTER VALVE valve should develop leaks the entire valve must be replaced. SHOCK HAZARD To avoid electrical shock or property damage, move the power switch to “OFF”...

  • Page 21: Pump Removal

    Model OE-100 3. To reassemble, place rotor on drive shaft, and place rollers into 2-16. FILTER PUMP rotor. REPAIR (Continued) A small amount of shortening might be needed to hold the bottom roller into place until cover plate is put on. Make sure O-ring is in proper position on plate.

  • Page 22: Pump And Motor Replacement

    Model OE-100 2-18. PUMP AND MOTOR REPLACEMENT SHOCK HAZARD To avoid electrical shock or property damage, move the power switch to “OFF” and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove the cover from the junction box and remove the wire nuts attaching wires leading into the flexible conduit going to the motor.
  • Page 23 Model OE-100 5. Close door and turn power switch on. Unit is now ready for 2-19. COOLING FAN operation. MAINTENANCE (Continued) If the fan needs a more thorough cleaning, or E-4 persists after cleaning the fan guard, follow the following steps.
  • Page 24 Model OE-100 2-18...
  • Page 25 Model OE-100 1197 2-19...
  • Page 26 Model OE-100 2-20 1197...
  • Page 27 Model OE-100 2-21...
  • Page 28 Model OE-100 2-22 1294...
  • Page 29 0 TO 3 YEARS: During this time, any frypot that fails due to manufacturing or workman- ship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.

  • Page 31: Parts Information

    This section lists the replaceable parts of the Henny Penny Open Fryer, Electric. 3-2. GENUINE PARTS Use only genuine Henny Penny parts in your fryer. Using a part of lesser quality or substitute design may result in damage to the unit or personal injury.
  • Page 32 Model OE-100 Figure 3-1 OE-100 Frypot & Drain Valve...
  • Page 33 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 FRYPOT & DRAIN VALVE 30323 Cover, Fry Pot ..............25412 Handle ................LW02-005 Lockwasher (#10-24x3/8 PH) ........... SC01-038 Screw ................30039 Pot Weld Assembly ............... 30086 Bracket - Pan Support ............
  • Page 34 Model OE-100 Figure 3-2. OE-100 Heating Elements...
  • Page 35 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 HEATING ELEMENTS Heating Elements ..............√ √ √ √ √ 30292-1 480 Volts, 7333 Watts √ √ √ √ √ 30292-2 208 Volts, 7333 Watts √ √ √ √ √...
  • Page 36 Model OE-100 Figure 3-3. OE-100 Insulation...
  • Page 37 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 INSULATION 30146 Insulation - Bottom ..............WA02-001 Washer - Insulation ..............30140 Insulation - Front & Back ............30169 Insulation - End ..............30056 Insulation Support W/A ............SC02-018 Screw - Thread Forming (#8 AB) ..........
  • Page 38 Model OE-100 Figure 3-4. OE-100 Fan, Contactors, and High Limit Assembly...
  • Page 39 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 FAN, CONTACTORS, AND HIGH LIMIT ASSEMBLY 30079 Bracket - Contactor .............. SC02-018 Screw - Thread Forming (#8) ..........√ √ √ √ √ 3 14930 Kit - Contactor ..............
  • Page 40 Model OE-100 Figure 3-5. OE-100 Frame Assembly 3-10...
  • Page 41 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 FRAME ASSEMBLY 37593 Frame Assembly ..............30131 Insulation ................30125 Counter Top Weld Assembly ..........30047 Panel - Left Side ..............SC03-005 Screw - Self Drilling (#8 x 1/2) ..........
  • Page 42 Model OE-100 Figure 3-6. Control Panel Assembly 1209 3-12...
  • Page 43 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY CONTROL PANEL ASSEMBLY √ √ √ √ √ 1 41262RB Control Panel Assembly (includes items 2 thru 14) ....30003 Hinge - Slip Joint Female ........... 30004 Hinge - Slip Joint Female ...........
  • Page 44 Model OE-100 Figure 3-7. OE-100 Lower Filter Plumbing Components 3-14...
  • Page 45 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 LOWER FILTER PLUMBING COMPONENTS 67589 Motor and Pump, Filter ............√ √ √ √ √ 67583 Motor, 1/2 Horse .............. √ √ √ √ √ 17476 Pump Seal Kit ..............
  • Page 46 Model OE-100 Figure 3-8. OE-100 Filter Assembly 3-16...
  • Page 47 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 FILTER ASSEMBLY Filter Screen Assembly ............17510(use 14671) 65211 Crumb Catcher ..............Top Screen ................ 17502(use 14671) Bottom Screen ..............17503(use 14671) 17505 Filter Clips ................. √ √ √ √ √ 6 12101 Filter Envelope ..............
  • Page 48 Model OE-100 Figure 3-9. OE-100 Supersorb Filter 1093 3-18...
  • Page 49 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY OE-100 SUPERSORB FILTER Union-Female Fitting ............. 17430(use 69289) 37855 Filter Pan Assembly ............... 37135 Filter Clamp Ring Assembly ........... 36596 Handle-Filter Lock ..............NS03-023 Nut 1/4-20 Acorn Cap ............30944 Support-Filter Pad ..............
  • Page 50 Model OE-100 Figure 3-10. Upper Filter Plumbing Components 3-20...
  • Page 51 Model OE-100 FIGURE UNITS & ITEM PART NUMBER DESCRIPTION ASSY 3-10 UPPER FILTER PLUMING COMPONENTS 17407 CONNECTOR, Male Elbow ..........16814 CONNECTOR ASSEMBLY, Male ........16809 NUT, Fitting - ..............16808 FITTING, Sleeve ............... 16807 CONNECTOR,Male ............30230 TUBING, S. S ...............
