- Page 1 Shanghai Baudcom Communication Device Co.,LTD Model:BD-5800H 1550nm External Modulated Optical Transmitter Operating Manual Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn...
-
Page 2: Table Of Contents
5.1 RS232 Communication Interface Description ......... - 16 - 5.2 Set up the Hyper Terminal............... - 16 - 5.3 Operating Parameters Configuration ............- 17 - 5.4 Remote Monitoring: SNMP ..............- 20 - - 1 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 3: Safety Instruction
6.1 Cleaning Fiber Optic Connectors ............- 23 - 6.1.1 Cleaning Patch Cord or Pigtail Fiber Optical Connectors ....- 24 - 6.2 Troubleshooting ..................- 24 - 6.3 Disclaimer ....................- 25 - Safety Instruction - 2 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 4: Overview
The core of transmitter is the optical modulator. The 1550nm signal input the optical modulator, make the laser intensity changed follow the external RF signal voltage, and then generate the AM optical signal. - 3 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 5: Product Applications
CSO install failed, the RF indicator will flash red, see details in 6.2 Troubleshooting. Block Diagram 1.3 Product Applications • High-performance long-distance transmission • High-power distribution network • Redundancy loop architecture • FTTx network • RFOG application • DWDM network - 4 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 6: Technique Parameters
CNR Link 1 55.0 53.5 52.0 54.0 CNR Link 2 53.0 52.5 50.5 52.5 CNR Link 3 50.5 50.5 49.0 51.0 CSO Tx/Rx and Link 1 CSO Link 2 CSO Link 3 - 5 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 7: Test Condition
AGC control range MGC adjustable range 0~15 Optical connector SC/APC, FC/APC ～ Operating temperature °C ～ Storage temperature °C 90～265VAC Power Source Specification 36～72VDC Consumption ≤60 483(L) × 455(W) × 44(H) Dimension Total Weight - 6 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 8: Panel Interface And Menu System Description
LED flash red Bias current, cooling current and LED green output power are all normal Laser indicator At least one of bias current, cooling current and output power LED flash red is abnormal - 7 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 9: Rear Panel
3.3 Power Module 3.3.1 220V Power Module Mounting screws 220V power outlet Fuse Power switch 3.3.2 48V Power Module Mounting screws + Positive terminal block - Negative terminal block - 8 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 10: Menu Operation
1550nm external modulated optical transmitter operating manual 3.4 Menu Operation 3.4.1 Main Menu Displayed parameters Comments Boot display Menu one: Display parameters 1.Disp Parameters Menu two: Set parameters 2.Set Parameters Menu three: Alarm status 3.Alarm Status - 9 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 11: Display Menu
RF Mode Adjusted value with AGC mode S/N： Serial number Adjusted value with MGC mode Version number Version： +5V monitor voltage Work time +5V Read: Work Time: -5V Read: -5V monitor voltage - 10 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 12: Set Menu
Set subnet mask Set Mask Set gateway Set Gateway Set Trap1 Address Set trap1 address Set trap2 address Set Trap2 Address Set buzzer alarm ON/OFF Set Buzzer Alarm Restore factory Restore Factory Cfg settings - 11 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 13: Alarm Menu
1550.12nm. In the 1545-1560nm band, the frequency distance and the wavelength distance is very similar to linear relationship. 50GHz frequency distance reflects to wavelength is very approximate to 0.4nm width; - 12 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 14: Sbs Suppression Adjustment
The plug-socket combination must be accessible at all times, because it serves as the main disconnecting device. Warning La combinaison de prise de courant doit être accessible à tout Attention moment parce qu'elle fait office de système principal de déconnexion. - 13 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 15: Mounting The Equipment
NOTE: Any contamination of optical connector can significantly degrade optical link performance. This degradation will most likely manifest itself as poor signal-to-noise (SNR) performance. 4. Note to butt the nick of the connectors and align them accordingly. - 14 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 16: Connecting The Ethernet Cable
Turn on the power source. It takes about 60 seconds for all systems to operate. When connect one power supply, the power indicator is yellow; when connect two power supplies, the power indicator is green. - 15 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 17: Communication Setup
5.2 Set up the Hyper Terminal If you have not setup the Hyper Terminal in your Windows system, follow the steps: Click “start menu program accessorycommunicationHyper Terminal”: This results in the following screen: - 16 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 18: Operating Parameters Configuration
5.3 Operating Parameters Configuration Under the condition of power off, use the serial port lines to connect the RS232 port with the computer port. Open the Windows Hyper Terminal which you have set up. - 17 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... - Page 19 1550nm external modulated optical transmitter operating manual Then turn on the power, you will see the page as follows. Enter the password to enter the configuration interface. Enter the password, display the following screen: - 18 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn...
- Page 20 This command shows current application program version, program name and the internal commands list of the system as follows: You can also use the “help” command to show help information of other commands, such as “help ethcfg”，ethcfg’s help information appears as follows: - 19 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn...
-
Page 21: Remote Monitoring: Snmp
1: TX+ 2: TX- 3: RX+ 4: No Connect 5: No Connect 6: RX- 7: No Connect 8: No Connect A: Green indicator flashing means that the LAN port is sending data. - 20 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 22: Web Network Management
5.5 WEB Network Management Open the IE browser, type the IP address and enter the interface as follows: Type the user name admin and the password 123456 (factory default), enter the following interface: - 21 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... - Page 23 New column, and click the corresponding Update button to update the parameters. The change steps in the Items are the same, but finally need to click the Restart Device button to take effect. - 22 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn...
-
Page 24: Maintenance And Troubleshooting
Using low-grade cleaning paper or other cloth to wipe an optical connector can leave microscopic fibers on the optical connector Surface. - 23 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 25: Cleaning Patch Cord Or Pigtail Fiber Optical Connectors
Disconnect the RF connection, CSO nonlinearity CSO Initialization failed wait 10 seconds before indexes are poor reconnecting the RF signal. Laser Laser Bias HIGH The laser is off Contact Customer Service. indicator is - 24 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn... -
Page 26: Disclaimer
Nothing hereunder constitutes a representation or warranty that using any products in the manner described herein will not infringe any patents of third parties. - 25 - Website: www.baudcom.com.cn Tel：+86-21-37709251 Email: info@baudcom.com.cn...
