Nitecore Thumb LEO User Manual

The All-Round Flashlight Expert

Features

·A handy, versatile, tiltable worklight
·Two high-performance LEDs emit white and ultraviolet light
·Up to 45 lumens white light
·500mW radiant power, 365nm wavelength ultraviolet light
·For currency inspection and document examination, anti-forgery and
fluorescent detecion
·Over 120 degree adjustable angles with one-handed operation
·Integrated intelligent Li-ion battery charging circuit (via micro USB charging
port)
·Dual switch design offers access to all functions via one-handed operation
·Direct access to red/blue police warning signal mode
·A screw fastened clip for multiple purposes
·Constructed from durable Polycarbonate materials
·Extremely lightweight, compact and portable
·Impact resistant to 1 meter

Dimensions

Size: 2.91" x 0.94" x 0.62" (74mm×24mm×15.8mm)
Weight: 0.88oz (25g, with battery and clip)
Accessories
Key ring
Output & Runtime
White UV Police Warning Signals
45 *
- -
LUMENS
2 2 >48
h
h h
24m
- -
150
cd
- -
1
m (Impact Resistant)
IP65
(Dust & Water Resistant)

Operation Instructions

Dual Switch Description
The upper switch (closer to the head) controls the white and UV LEDs, the
lower switch controls the red/blue police warning signal.
White And UV Light Operations
Turn On
With the Thumb LEO turned off, press the upper switch to turn the Thumb LEO
on.
Light Modes
Within three seconds of activation, press the upper switch repeatedly to cycle
®
through "White-UV-Standby" modes.
Turn Off
To turn the Thumb LEO off, cease any operation in white mode for three
seconds, and press the upper switch.
Red/Blue Police Warning Signal Operations
In any status (including standby), press the lower switch to turn red/blue police
warning signal on.
Lockout/Unlock
With the Thumb LEO turned off, press both switches simultaneously to lockout
the Thumb LEO. The red/blue power indicator will blink three times to indicate
the lockout status. In the lockout status, all functions will be rendered
inoperative. To unlock, press both switches simultaneously again.

Charging

Remove the port cover to expose the USB charging port. Connect the charging
port to an external power source (adapter, computer or other device) via a USB
cord.
The red power indicator will stay on to indicate
charging in progress, it will turn green to
indicate charging completed.
Note: Recharge the Thumb LEO when output
appears to be dim. The charging process takes
approximately 3 hours to complete.

Warranty Service

NOTICE:
All NITECORE products are warranted for quality. Any defective /malfunctioning
Stated data has been
NITECORE Tube can be repaired free of charge for a period of 24 months from
measured in accordance with
the date of purchase. Beyond 24 months, a limited warranty applies, covering
the international flashlight
the cost of labor and maintenance, but not the cost of accessories or
testing standards ANSI/NEMA
replacement parts. The warranty is nullified in either or both of the following
FL1 using an integrated and
situations:
fully charged 3.7V 220mAh
1. The product(s) is/are broken down, reconstructed and/or modified by
rechargeable Li-ion battery
under laboratory conditions.
2. The product(s) is/are damaged through improper use.
End-user results may vary due
For the latest information on NITECORE® products and services, please contact
to individual usage habits and
a local NITECORE® distributor or send an email to service@nitecore.com.
environmental conditions.
※All images, text and statements specified herein this user manual are for
reference purpose only. Should any discrepancy occurs between this manual
and information specified on www.nitecore.com, information on our official
website shall prevail. SYSMAX Innovations Co., Ltd. reserves the rights to
interpret and amend the content of this document at any time without prior
notice.
