Summary of Contents for hydrotab BT Series
- Page 1 Hydro Hydro Marine Engineering Marine Engineering NMEA 2000 NMEA 0183 Hydrotab BT installation & Moby Automatic controller Hydrotab BT Series...
-
Page 2: Disclaimer
Trademark Notice Fair use statement Hydrotab is a registered trademark of Olympic This manual can be printed or copied for your Engineering Ltd, Greece. All other trademarks, own use only. Copies should not be provided... -
Page 3: Table Of Contents
Required Tools for Installation Before Installation Safety precautions Proper Interceptor Installation in Transom Interceptor Installation BT Series Interceptor and Anode Mounting and Coating Instructions Interceptor Installation (Indirect Air Supply) Air Unit Installation Air Unit Fuse Replacement Moby Controller Installation Air Unit: Direct Installation Diagram... -
Page 4: Installation Kit
Lower edge of the hull Use drill Ø5.5mm x 9 holes Άκρη γάστρας Χρησιμοποιήστε τρυπάνι Ø5.5mm x 9 τρύπες 4. Cables 3. One Hydrotab AIR unit 12 OR 24VDC Inline terminator 3m-supply cable - Female 12V or 24V 24V only... -
Page 5: Required Tools For Installation
Hydro Marine Engineering Required Tools for Installation Marking tool (pencil or marker) Drill Ø3 Drill Ø4 Drill Ø5.5 Drill Ø8,5 Hole Saw Ø70 Screwdriver Allen Key No 5 Drilling tool Sikaflex gun Before Installation Make sure there are no obstructions behind the Attention! Please make sure that the pipe drilling area (tanks, fuel lines, cabling) which can insertion hole is accessible from the engine room... -
Page 6: Proper Interceptor Installation In Transom
Hydro Marine Engineering Proper interceptor installation in transom Right Transom Interceptor Wrong Transom Interceptor If the boat's transom has a significant curvature, it is necessary to create a flat plane for the installation (acceptable flatness tolerance: 2mm). For aluminum hulls, it is suggested Isolation Plates between hull and interceptors to be installed. You can find installation instructions in the Isolation Plates Kit. -
Page 7: Interceptor Installation
Hydro Marine Engineering Interceptor Installation Tape Drill all the pattern holes with a 3mm bore without removing the pattern Remove the pattern and drill according the pattern indications You will need No 5,5 No 4 No 8,5... - Page 8 Hydro Marine Engineering Interceptor Installation Optional: Connecting Interceptors with Earthing Grid of boat Except periodical replacement of anodes, you can enhance protection of interceptors from electrolytic corrosion by connecting them to the earthing grid of the boat: 1. Drill through the hull one of the mounting pattern-holes on the transom. 2.
- Page 9 Hydro Marine Engineering Interceptor Installation Optional: Direct air supply Indirect Air Supply Kit...
- Page 10 Hydro Marine Engineering Interceptor Installation...
- Page 11 Hydro Marine Engineering Interceptor Installation Right Wrong WARNING! Do not try to place the screw without using the guide pipe! If the screw falls in the internal of the interceptor, you must disassemble the rear plastic cover, and restore the screw. Hose Air fitting M6,3x32...
- Page 12 Hydro Marine Engineering Interceptor Installation M4,8x25 Attention! The anodes replacement, depends on the sea water quality you have dropped anchor. As the corrosion of an anode looks like a sponge, for more efficient checking you should touch it to feel that its smooth surface has become porous.
-
Page 13: Bt Series Interceptor And Anode Mounting And Coating Instructions
Hydro Marine Engineering BT Series Interceptor and Anode Mounting and Coating Instructions Note 1: You may apply protection coating on interceptor if you'd like so, but: 1. Do not apply coating on anodes 2. Do not apply coating on the area of interceptors which is in contact with anode (see Fig. 1a, 1b, 1c). -
Page 14: Interceptor Installation (Indirect Air Supply)
Hydro Marine Engineering Interceptor Installation (indirect air supply) In case of indirect air supply, you can use the components included in the kit as shown in the image. Air Unit Installation WARNING: WARNING: DO NOT MOUNT DO NOT MOUNT the Air Unit upside-down the Air Unit upside-down... -
Page 15: Air Unit Fuse Replacement
Hydro Marine Engineering Air Unit Installation M4,8x25 Pneumatic Connection Cut the 8mm pipe at the proper length and connect it to the Air Unit After you install the hose through the transom, mount the air fitting into the hose. Connect the push-infitting Air Unit Fuse Replacement WARNING: Remove carefully the Air Unit Top Cover, and ensure that the mounted cables are not pulled out from the connector... -
Page 16: Moby Controller Installation
Hydro Marine Engineering Moby Controller Installation Tape 1. Place the Moby Drilling Pattern in the desired position (preferably a clean and easy-to-access area near the steering wheel of the boat, and with max. inclination angle at 80°). 3. Drill the 4 holes according to the provided drilling 4. -
Page 17: Air Unit: Direct Installation Diagram
Hydro Marine Engineering Direct Installation Diagram Moby Controller Flybridge OPTIONAL controller USE INLINE TERMINATOR CABLE 3m - MF CABLE 3m - F CABLE CABLE 10m - MF 10m - FF CABLE 3m - F 12/24V 12/24V In case a new NMEA 2000 instrument to be added, a proper NMEA Network must be built. Installation diagram on existing NMEA Network Flybridge Moby Controller... -
Page 18: Double Speed Air Unit: Direct Installation Diagram
Hydro Marine Engineering Direct Installation Diagram - Double Speed Air Unit Attention! Amps Fuse Moby Controller *Advice the fusing table and ensure that you apply the right fuse according to your boat’s voltage. Flybridge OPTIONAL controller USE INLINE POWER TERMINATOR CABLE CABLE 3m - MF... -
Page 19: Single Air Unit Electrical Diagram
Single Air Unit Electrical Diagram Single Air Unit Pneumatic Diagram Compressor NM E A 2000 V 2.1 CAN-H VALVE GROUP CAN-L -12/24V RM+12V -12/24V FAN +12V +12/24V F1 F1 Battery Exhaust Compressor (REV-00305) (PNE-01107) SYMBOL PART No DESCRIPTION NOTES PNE-00924 VALVE COIL STARBOARD RETRACT PNE-00924... -
Page 20: Double Speed Air Unit Electrical Diagram
Double Speed Air Unit Electrical Diagram Double Speed Air Unit Pneumatic Diagram Compressor Compressor NM E A 2000 500.AIR-N2Κ-ΤΗ-V2.1 CAN-H CAN-L VALVE GROUP -12/24V RM+12V -12/24V +12/24V Compressor Exhaust (PNE-00050) (PNE-01107) Battery SYMBOL PART No DESCRIPTION NOTES PNE-00924 VALVE COIL STARBOARD RETRACT PNE-00924 VALVE COIL STARBOARD EXTEND... -
Page 21: Spare Parts List - Model: 160Bt (Asm-00928)
Hydro Marine Engineering Spare parts list MOD: 160BT (ASM-00928) BOM ID BOM ID PartNo PartNo Description Description GEN-00276 GEN-00276 SIDE CAP SIDE CAP GEN-00279 GEN-00279 ANODE ANODE GEN-00290 GEN-00290 BLADE BLADE LAS-00826 LAS-00826 HOUSING, 160BT HOUSING, 160BT LAS-00851 LAS-00851 HOLDING BLADE PLATE, 160BT HOLDING BLADE PLATE, 160BT SPR-00025 SPR-00025... -
Page 22: Spare Parts List - Model: 320Bt (Asm-00560)
Hydro Marine Engineering Spare parts list MOD: 320BT (ASM-00560) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00479 HOUSING, 320BT LAS-00489 HOLDING BLADE PLATE, 320BT SPR-00025 SPRING ASM-00550 TUBOLAR ASSEMBLY, 320BT... -
Page 23: Spare Parts List - Model: 480Bt (Asm-00561)
Hydro Marine Engineering Spare parts list MOD: 480BT (ASM-00561) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00480 HOUSING, 480BT LAS-00490 HOLDING BLADE PLATE, 480BT SPR-00025 SPRING ASM-00551 TUBOLAR ASSEMBLY, 480BT... -
Page 24: Spare Parts List - Model: 640Bt (Asm-00562)
Hydro Marine Engineering Spare parts list MOD: 640BT (ASM-00562) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00481 HOUSING, 640BT LAS-00491 HOLDING BLADE PLATE, 640BT SPR-00025 SPRING ASM-00552 TUBOLAR ASSEMBLY, 640BT... -
Page 25: Spare Parts List - Model: 800Bt (Asm-00563)
Hydro Marine Engineering Spare parts list MOD 800BT (ASM-00563) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00482 HOUSING, 800BT LAS-00492 HOLDING BLADE PLATE, 800BT SPR-00025 SPRING ASM-00553 TUBOLAR ASSEMBLY, 800BT... -
Page 26: Spare Parts List - Model: 960Bt (Asm-00564)
Hydro Marine Engineering Spare parts list MOD: 960BT (ASM-00564) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00483 HOUSING, 960BT LAS-00493 HOLDING BLADE PLATE, 960BT SPR-00025 SPRING ASM-00554 TUBOLAR ASSΕMBLY, 960BT... -
Page 27: Spare Parts List - Model: 1500Bt (Asm-00940)
Hydro Marine Engineering Spare parts list MOD: 1500BT (ASM-0940) BOM ID PartNo Description GEN-00276 SIDE CAP GEN-00279 ANODE GEN-00290 BLADE LAS-00832 HOUSING, 1500BT LAS-00834 HOLDING BLADE PLATE, 1500BT SPR-00025 SPRING ASM-01009 TUBOLAR ASSEMBLY, 1500BT... -
Page 28: Spare Parts List - Model: 2000Bt (Asm-00941)
Hydro Marine Engineering Spare parts list... -
Page 29: Spare Parts List - Air Unit (Asm-01065)
USB SEALING CAP ELE-00647 MINI USB PORT, FEMALE FAS-02323 NUT FOR AIR UNIT FAS-02324 WASHER FOR AIR UNIT GEN-00156 HYDROTAB AIR UNIT, TOP COVER GEN-00157 HYDROTAB AIR UNIT, BASE GEN-00168 SPRING CLAMP GEN-00505 SILICON PROTECTION TUBE LAS-01170 TEMPERATURE SENSOR BASE... -
Page 30: Spare Parts List - Double Speed Air Unit (Asm-01174)
Hydro Marine Engineering Spare parts list DOUBLE SPEED AIR UNIT (ASM-01174- BOM ID PartNo DESCRIPTION QTY. ELE-00612 AIR UNIT DOUBLE SPEED BOX LAS-01007 MOUNTING BASE AIR UNIT COOLING FAN ELE-00591 REV-00443 LONG PCB SPACER LAS-01009 FAN MOUNTING FLANGE REV-00487 PLATE SPACER GEN-00461 SIDE PROTECTION GRILL PNE-01208... -
Page 31: Moby Troubleshooting
Hydro Marine Engineering Moby Troubleshooting Moby controller is Moby controller is on but flaps do not on but flaps do not operate on manual operate on manual Go to System Information. Do you notice N2K error and Temperature Offline? 1) Is there power supply 1) Open the air unit. -
Page 32: Warranty Conditions
Hydrotab's warranty only covers the repair or replacement of spare parts. System selections It is the sole responsibility of the buyer to choose the correct system and even with Hydrotab’s suggestion for a system, the overall responsibility is with the buyer. - Page 33 Hydro Marine Engineering Notes...
- Page 34 Hydro Marine Engineering Notes...
- Page 35 Hydro Marine Engineering Notes...
- Page 36 Hydro Marine Engineering 4, Papazoglou str. Hydro GR-17778 Athens Greece email: info@hydrotab.gr website: www.hydrotab.gr Marine Engineering REV.B...
