J9 - Hdmi; J10 - Csi-2 Ab; J11 - Usb 3.0 - 3.1 - Auvidea JNX30D Technical Reference Manual

5.6

J9 - HDMI

Standard pinout
CEC is not supported (pin 13 of HDMI connector)
Power pin 18 is current limited by PTC fuse (5V 50mA)
5.7

J10 - CSI-2 AB

22 pin 0.5mm pitch FPC connector
Pin Description
1 3.3V
2 CAM-I2C_SDA
3 CAM-I2C_SCL
4 GND
5 CAM1-MCLK
6 CAM1_PWDN
7 GND
8 CSI_B_D1_P
9 CSI_B_D1_N
10 GND
11 CSI_B_D0_P
12 CSI_B_D0_N
13 GND
14 CSI_A_CLK_P
15 CSI_A_CLK_N
16 GND
17 CSI_A_D1_P
18 CSI_A_D1_N
19 GND
20 CSI_A_D0_P
21 CSI_A_D0_N
22 GND
See further details in the J5 description.
5.8 J11 - USB 3.0 – 3.1
USB 3.0 Type A standard pinout
In Rev 1: power control is always on (5V 1A)
In Rev 2 and up: Controllable with GPIO pin 126 power on[0]/off[1] (default on[0]) (5V 1A)
VERSION: 1.4
Socket pin
Power: connected with bead to 3.3V
(5V optional if bead is moved)
215
213
IN: Input - connect to 1.8V or 3.3V output of the camera to
drive the CAM LED.
1: enable CAM LED
0: disable CAM LED
206 OUT: Output (open drain with 2.2k pullup to 3.3V) - connect
to power enable of camera. The control signal is connected
via level shifting inverter to pin 152 of the compute module.
17
15
5
3
12
10
18
16
6
4
Page 12 of 28
