Panasonic SA-VK960GCP Service Manual

Notes: This model is based on SA-VK960GC/GCS/GCT/GS-K. Please refer to the original service manual
(Order no. MD0707009CE).
Specifications
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch (High Ch)
Front Ch (Low Ch)
Surround Ch
Center Ch
All manuals and user guides at all-guides.com
110 W per channel (3 Ω), 1 kHz,
10% THD
55 W per channel (6 Ω), 100 Hz,
10% THD
110 W per channel (3 Ω), 1 kHz,
10% THD
110 W per channel (3 Ω), 1 kHz,
10% THD
DVD Stereo System
SA-VK960GCP
Colour
(K).......................Black Type
Subwoofer Ch
Total RMS Dolby Digital mode power
PMPO output power
FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
© 2007 Matsushita Electric Industrial Co Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. MD0707015AE
110 W per channel (3 Ω), 100 Hz,
10% THD
880 W
10000 W
FM 20 stations
AM 15 stations
Unauthorized copying and
