Panasonic SA-VK860GC Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Stereo System
  5. SA-VK860GC
  6. Service manual
Panasonic SA-VK860GC Service Manual

Panasonic SA-VK860GC Service Manual

Dvd stereo system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's DVD changer mechanism unit is CRS1D. Please refer to the original Service Manual
(Order No. MD0603065A3) for this mechanism.
Specifications
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch
Surround Ch
Center Ch
Subwoofer Ch
Total RMS Dolby Digital mode power
PMPO output power
110 W per channel (3 Ω), 1 kHz,
10% THD
110 W per channel (3 Ω), 1 kHz,
10% THD
110 W per channel (3 Ω), 1 kHz,
10% THD
110 W per channel (3 Ω), 100 Hz,
10% THD
660 W
7000 W
DVD Stereo System
SA-VK860GC
SA-VK860GCS
SA-VK860GS
Colour
(K)... Black Type
FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26 dB
Antenna terminals
Amplitude Modulation (AM)
Frequency range
© 2007 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0707030CE
FM 20 stations
AM 15 stations
87.50 to 108.00 MHz (50 kHz
step)
4.0 µV (IHF)
2.2 µV
75 Ω (unbalanced)
522 to 1629 kHz (9 kHz step)
520 to 1630 kHz (10 kHz step)
Unauthorized
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-VK860GC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SA-VK860GC

Summary of Contents for Panasonic SA-VK860GC

  • Page 1 ORDER NO. MD0707030CE DVD Stereo System SA-VK860GC SA-VK860GCS SA-VK860GS Colour (K)... Black Type Notes: This model’s DVD changer mechanism unit is CRS1D. Please refer to the original Service Manual (Order No. MD0603065A3) for this mechanism. Specifications AMPLIFIER SECTION FM/AM TUNER, TERMINALS SECTION...
