Please use this manual together with the service manual for Model No. [SA-VK650GC/GN/GS/GCS/GCT-S,
Order No. MD0604118C3].
Specifications
n SYSTEM
SC-VK650(GCP)
(Refer to the original service manual for information of the technical
specifications.)
CONTENTS
Music Center: SA-VK650 (GCP)
Speaker: SB-VK650 (GC)
Subwoofer: SB-WVK650 (GC)
Page
SA-VK650GCP
Colour
(S) .... Silver Type
Notes:
1. Specifications are subject to change without notice. Mass and
dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
3
5
6
7
11
12
© 2006 Matsushita Electric Industrial Co. Ltd.. All
rights
distribution is a violation of law.
ORDER NO. MD0604120A3
DVD Stereo System
reserved.
Unauthorized
Page
16
18
19
22
23
24
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-VK650GCP and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic SA-VK650GCP

Summary of Contents for Panasonic SA-VK650GCP

  • Page 1: Table Of Contents

    ORDER NO. MD0604120A3 DVD Stereo System SA-VK650GCP Colour (S) ..Silver Type Please use this manual together with the service manual for Model No. [SA-VK650GC/GN/GS/GCS/GCT-S, Order No. MD0604118C3]. Specifications n SYSTEM Notes: SC-VK650(GCP) Music Center: SA-VK650 (GCP) 1. Specifications are subject to change without notice. Mass and dimensions are approximate.
  • Page 2 SA-VK650GCP 3.2. (B) Main P.C.B. 4 Exploded Views (Updating) 3.3. (C) Panel P.C.B. 4.1. Cabinet Parts Location 3.4. (E) Transformer P.C.B. 4.2. Packaging 3.5. (G) Power P.C.B. 5 Parts Location and Replacement Parts List (Updating) 3.6. (D) Tact Switch P.C.B., (F) Mic P.C.B., (H) Deck P.C.B.,...

  • Page 3: Notes

    SA-VK650GCP 1 Notes This service manual does not contain the following information, because of the reference to the original model of SA- VK650GC/GN/GS/GCS/GCT-S. (Order No. MD0604118C3) · Assembling & Disassembling · Service Positions · Self-diagnosis & special mode setting · Terminal function of IC’s...
  • Page 4 SA-VK650GCP...

  • Page 5: Schematic Diagram (Updating)

    SA-VK650GCP 2 Schematic Diagram (Updating)

  • Page 6: Optical Pickup Unit Circuit

    (FP8531) ON LD (CD) SCHEMATIC LD GND DIAGRAM-2 LD (DVD) GND (OEIC) LDU PCB VREF VREF1 SUB2 SUB2 SUB1 SUB1 PIN(CD) LD (CD) SUBSEL GND (IM) LD (DVD) 6.8K LDGND 6.8K 6.8K J0JCC0000307 0.22 J0JBC0000105 SA-VK650GCP OPTICAL PICKUP UNIT CIRCUIT...

  • Page 7: Dvd Module Circuit

    IC8695 SUBSEL R8533 C0JBAA000346 GND(VRCD) C8532 AND GATE LOGIC IC 220P R8557 C8553 C8551 6.3V47P C8552 R8556 R8553 C8554 R8558 OP_CPU_STAT 16V10P R8555 R8554 R8559 Q8552 B1ADGB000008 R8551 Q8551 SWITCH 2SD1819A0L LPC01 SWITCH R8552 OP_CPU_CMD SA-VK650GCP DVD MODULE (DV3.2) CIRCU...
  • Page 8 SA-VK650GCP SCHEMATIC DIAGRAM - 3 : MAIN SIGNAL LINE : DVD VIDEO SIGNAL LINE DVD MODULE (DV3.2) CIRCUIT : +B SIGNAL LINE : DVD AUDIO SIGNAL LINE IC8420 C0FBBK000049 2-CH DAC IC ZEROL ZEROR VOUTL EXADR15 EXADR16 VOUTR EXADR14 XBYTE...
  • Page 9 SA-VK650GCP SCHEMATIC DIAGRAM - 4 DVD MODULE (DV3.2) CIRCUIT : +B SIGNAL LINE RX8018 RX8017 (22 x 2) (82 x 4) R8041 C8051 MDQ0 MDQ15 DQ15 C8052 VDDQ VSSQ MDQ18 TRCDATA1 MDQ1 MDQ14 DQ14 TRCDATA0 C8018 0.1 VDD33 TRCCLK MDQ28...
  • Page 10 SA-VK650GCP SCHEMATIC DIAGRAM - 5 : CD-DA SIGNAL LINE : DVD VIDEO SIGNAL LINE DVD MODULE (DV3.2) CIRCUIT : +B SIGNAL LINE : DVD AUDIO SIGNAL LINE LB8011 J0JHC0000045 D+3.3V VDD12 C8001 C8011 LB8001 4V330P 6.3V100P J0JHC0000045 RX8031 (4.7K x 2)

  • Page 11: B) Main (Tuner) Circuit

    SA-VK650GCP 2.3. (B) Main (Tuner) Circuit Note: With reference to page 88 (section 19.3) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. SCHEMATIC DIAGRAM - 6 : +B SIGNAL LINE : AM SIGNAL LINE : FM SIGNAL LINE...

  • Page 12: B) Main Circuit

    SA-VK650GCP 2.4. (B) Main Circuit Note: With reference to page 89~92 (section 19.4) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. SCHEMATIC DIAGRAM - 7 : MAIN SIGNAL LINE : FM/AM SIGNAL LINE : DVD VIDEO SIGNAL LINE...

  • Page 13: (S)

    SA-VK650GCP SCHEMATIC DIAGRAM - 8 : MAIN SIGNAL LINE : FM/AM SIGNAL LINE :PLAYBACK SIGNAL LINE MAIN CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE :RECORD SIGNAL LINE R2339 R2412 R2420 R2333 IC2103 C0ABBB000230 LM_L C2414 C2413 Q2051 B1GDCFJJ0047...
  • Page 14 SA-VK650GCP SCHEMATIC DIAGRAM - 9 : MAIN SIGNAL LINE MAIN CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE R2302 C2301 3.3K Q2942 C2302 R2303 B1ACKD000006 100K A_GND FAN MOTOR ON/OFF SWITCH M+9V R2944 C2945 C2944 4.7K C2941 R2952 R2945...
  • Page 15 SA-VK650GCP SCHEMATIC DIAGRAM - 10 : MAIN SIGNAL LINE : MIC SIGNAL LINE :PLAYBACK SIGNAL LINE MAIN CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE :RECORD SIGNAL LINE HP_R HP_R HP_GND HP_L HP_L HP_GND R2007 MIC_IN W2941 P_GND MIC_GND C2004 0.1...

  • Page 16: C) Panel Circuit & (D) Tact Switch Circuit

    SA-VK650GCP 2.5. (C) Panel Circuit & (D) Tact Switch Circuit Note: With reference to page 93~94 (section 19.5) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. SCHEMATIC DIAGRAM - 11 : -B SIGNAL LINE : MAIN SIGNAL LINE...
  • Page 17 SA-VK650GCP SCHEMATIC DIAGRAM - 12 : -B SIGNAL LINE PANEL CIRCUIT : +B SIGNAL LINE : MIC SIGNAL LINE Q6907 B1GBCFJJ0051 R6945 MUTING CONTROL 5.6K MIC_OUT ECHO_MUTE R6944 MIC_GND BP_1 R6921 R6922 C6937 10V1 C6922 0.01 W6802 R6943 IC6931 C6932...

  • Page 18: E) Transformer Circuit

    SA-VK650GCP 2.6. (E) Transformer Circuit Note: With reference to page 95 (section 19.6) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. SCHEMATIC DIAGRAM - 13 TRANSFORMER CIRCUIT MIC CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : +B SIGNAL LINE...

  • Page 19: G) Power Circuit

    1000P C5123 C5124 C5120 C5119 C5345 C5344 35V470P 35V470P 35V470P 35V470P 1000P 1000P R5326 R5329 R5529 PGND SUB+B_GND DGND ASP_GND TGND CD8V CD8V MAIN P_CON CIRCUIT L5102 L5502 J0JKB0000037 J0JKB0000037 (CN2808) MUTE_A SCHEMATIC DIAGRAM-10 SW5V SW5V CN5103 SA-VK650GCP POWER CIRC...
  • Page 20 CURRENT LIMITER SWITC 1.2K R5207 6.3V100 R5132 Q5202 6.8K C5158 R5131 B1ADCF000063 0.01 2.2K C5113 D5109 50V33 B0BA01100004 FREQUENCY HOPPING X5201 SWITCH H2A415300001 R5130 C5205 R5208 C5208 C5204 6.3V220 100P C5112 D5108 25V10 B0BA5R700008 R5209 SW5V TGND SA-VK650GCP POWER CIRC...
  • Page 21 R5114 W5502 Q5101,Q5102 D5102 B1DEGM000026 B0BA02600018 W5500 E5100 CURRENT CONTROL SWITCH E5102 Q5108 B1ABCF000176 Q5102 SWITCH R5107 Q5108 R5108 C5152 C5552 C5104 C5153 C5163 35V4700 0.047 R5106 Q5109 R5109 2SB0709AHL VOLTAGE REGULATOR R5105 R5110 D5103 2.2K B0BA5R100013 SA-VK650GCP POWER CIRCUIT...

  • Page 22: H) Deck Circuit & (I) Deck Mechanism Circuit

    SA-VK650GCP 2.8. (H) Deck Circuit & (I) Deck Mechanism Circuit Note: With reference to page 100 (section 19.9) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. SCHEMATIC DIAGRAM - 17 MAIN CIRCUIT (CN2803) ON : +B SIGNAL : PLAYBACK SIGNAL...

  • Page 23: Printed Circuit Board (Updating)

    SA-VK650GCP 3 Printed Circuit Board (Updating)

  • Page 24: Dvd Module P.c.b

    SA-VK650GCP 3.1. (A) DVD Module P.C.B. Note: With reference to page 102 (section 20.1) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. DVD MODULE P.C.B (REP4012D) FP8531 TO OPTICAL PICKUP UNIT C8256 C8258 R8263 R8251 2526 R8261 C8530...
  • Page 25 SA-VK650GCP 3.2. (B) Main P.C.B. Note: With reference to page 103 (section 20.2) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. MAIN P.C.B (REPX0547E) W2594 W2153 C2926 Q2552 W3000 W2590 W2902 W2151 W2614 W2189 C2553 C2923 C2552 W2527...
  • Page 26 SA-VK650GCP 3.3. (C) Panel P.C.B. Note: With reference to page 104 (section 20.3) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. PANEL P.C.B (REPX0541A) S6303 (OPEN / CLOSE) S6101 S6302 (POWER) (DISC CHECK) S6304 (DISC CHANGE) S6102 (S_SEQ)
  • Page 27 SA-VK650GCP 3.4. (E) Transformer P.C.B. Note: With reference to page 106 (section 20.5) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. TRANSFORMER P.C.B (REPX0519A) CN5955 250V 2A T5951 (SUB-TRANSFORMER) W5963 Z5950 C5964 L5950 Q5950 Q5954 W5906 R5952 RL5950...
  • Page 28 SA-VK650GCP 3.5. (G) Power P.C.B. Note: With reference to page 108 (section 20.7) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. POWER P.C.B (REPX0522B) W5184 W5185 C5102 W5186 W5181 W5183 H5104 D5121 Q5201 Q5202 W5188 W5105 R5107 C5202...

  • Page 29: D) Tact Switch P.c.b., (F) Mic P.c.b., (H) Deck P.c.b., (I) Deck Mechanism P.c.b. & (J) Tuner P.c.b

    SA-VK650GCP 3.6. (D) Tact Switch P.C.B., (F) Mic P.C.B., (H) Deck P.C.B., (I) Deck Mechanism P.C.B. & (J) Tuner P.C.B. Note: With reference to page 109 (section 20.8) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates. DECK MECHANISM P.C.B TACT SWITCH P.C.B (REPX0541A)
  • Page 30 SA-VK650GCP...

  • Page 31: Exploded Views (Updating)

    SA-VK650GCP 4 Exploded Views (Updating)

  • Page 32: Cabinet Parts Location

    SA-VK650GCP 4.1. Cabinet Parts Location Note: With reference to page 115 (section 24.1) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates.

  • Page 33: Packaging

    SA-VK650GCP 4.2. Packaging Note: With reference to page 122 (section 24.3) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S. Below is the updates.
  • Page 34 SA-VK650GCP...

  • Page 35: Parts Location And Replacement Parts List (Updating)

    5 Parts Location and Replacement Parts List (Updating) Note: With reference to page 119 ~ 134 (sections 25) of original service manual for SA-VK650GC/GN/GS/GCS/GCT-S (for section of Cabinet and Chassis) The electrical part list section is for SA-VK650GCP-S. Below are the updates. Notes: ·...
  • Page 36 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks Q1017 B1AARC000003 TRANSISTOR Q6908 B1GBCFJJ0051 TRANSISTOR Q2051 B1GDCFJJ0047 TRANSISTOR Q6909 B1GBCFJJ0051 TRANSISTOR Q2052 B1GFECYY0001 TRANSISTOR Q6910 B1GDCFJJ0047 TRANSISTOR Q2061 B1ABCF000176 TRANSISTOR...

  • Page 37: Variable Resistors

    SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks D5964 B0BA6R800008 DIODE CN2803 K1MN11A00008 11P CONNECTOR D5965 B0AACK000004 DIODE CN2805 K1MN14A00049 14P FFC CONNECTOR D5966 B0AACK000004 DIODE CN2806 K1MN16A00073 16P FFC CONNECTOR...

  • Page 38: Packing Materials

    SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks FP5100 K5G401A00008 RESISTOR LB8001 J0JHC0000045 CHIP INDUCTOR FP5950 K5G402A00025 FUSE PROTECTOR LB8011 J0JHC0000045 CHIP INDUCTOR LB8257 ERJ3GEY0R00V CHIP JUMPER HOLDERS LB8258...
  • Page 39 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R1010 D0GB183JA007 18K 1/16W R2086 ERJ3GEYJ392V 3.9K 1/16W R1011 ERJ3GEYJ822V 8.2K 1/16W R2087 ERJ3GEYJ334V 330K 1/16W R1012 D0GB472JA041 4.7K 1/16W R2101 ERJ3GEYJ332V 3.3K 1/16W...
  • Page 40 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R2316 D0GB272JA007 2.7K 1/16W R2625 D0GB471JA041 470 1/16W R2317 D0GB104JA007 100K 1/16W R2626 ERJ3GEYJ102V 1K 1/16W R2318 D0GB272JA007 2.7K 1/16W R2627...
  • Page 41 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R2886 D0GB105JA007 1M 1/16W R5130 D0GB151JA007 150 1/16W R2887 ERJ3GEYJ102V 1K 1/16W R5131 ERDS1FVJ222T 2.2K 1/2W R2888 ERJ3GEYJ102V 1K 1/16W R5132...
  • Page 42 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R5958 D0AE103JA048 10K 1/4W R6912 D0GB273JA007 27K 1/16W R5960 D0AE472JA048 4.7K 1/4W R6913 D0GB331JA007 330 1/16W R5961 D0AE151JA048 150 1/4W R6914...
  • Page 43 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R8420 ERJ2GEJ222X 2.2K 2W W6800 ERJ3GEY0R00V CHIP JUMPER R8421 ERJ2GE0R00X 0 2W W6801 ERJ3GEY0R00V CHIP JUMPER R8531 ERJ2GEJ152X 1.5K 2W W6802...
  • Page 44 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C1019 F1H1H102A219 1000P 50V C2207 F1H1C104A041 0.1 16V C1020 F1H1H471A219 470P 50V C2208 F1H1H102A219 1000P 50V C1021 F1H1H471A219 470P 50V C2211 F1H1C104A041 0.1 16V...
  • Page 45 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C2621 ECA1HAKR47XB 0.47 50V C2920 F2A0J102A130 1000P 6.3V C2622 ECA1HAK010XB 1 50V C2922 F2A0J102A130 1000P 6.3V C2623 ECA1HAK010XB 1 50V C2923 F2A0J102A130 1000P 6.3V...
  • Page 46 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C5313 ECJ1VB1H153K 0.015 50V C5962 ECA1CAM471XB 470 16V C5314 F1K2A1040006 0.1 100V C5963 ECA1HAK4R7XB 4.7 50V C5315 ECJ1VB1H104K 0.1 50V C5964 F1B1H103A007 0.01 50V...
  • Page 47 SA-VK650GCP Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C8008 ECJ0EF1C104Z 0.1 16V C8522 F1G1A1040006 0.1 10V C8011 F2G0J101A066 100P 6.3V C8523 ECJ0EF1C104Z 0.1 16V C8012 ECJ0EF1C104Z 0.1 16V C8524 ECJ0EF1C104Z 0.1 16V...
