From Usb Drive (Through A Software File Download) - Logicube ZXi-10G User Manual

Once completed, a screen will appear stating the update is complete and will prompt
you to turn the unit off then back on.
5. Turn the ZXi-10G off. Wait at least 5 seconds then turn the ZXi-10G back on.
6. Verify the software version by going to the Software Updates screen then go to section
6.4 Firmware Update

6.3.2 From USB Drive (Through a software file download)

Aside from the network option, the latest software can also be downloaded from Logicube's
website and be placed onto a USB flash drive to perform the software update/reinstall. It is
recommended to use an empty USB flash drive.
It is recommended to disconnect all
drives and drive adapters from the ZXi-
10G before the update/reinstall process.
1. Using a computer, download the latest software from the ZXi-10G product support
page at https://www.logicube.com/knowledgebase/zxi-10g/.
2. Extract the contents of the downloaded zip file to the root of the USB flash drive.
3. Turn the ZXi-10G on. When the main software screen appears, connect the USB flash
drive (that has the extracted software from step 2) to the U1 port (the leftmost USB
port on the front).
4. From the main menu on the ZXi-10G, tap/click Software Updates on the left side.
5. Select From USB Drive. The ZXi-10G will check for the version of the software on the
USB drive. After a few seconds, one of the following messages should appear:
•
•
6. Tap the Update icon to begin the update/reinstall. The ZXi-10G should begin the
update/reinstall process. Do not interrupt this process. It may take several minutes.
Once completed, a screen will appear stating the update is complete and will prompt
you to turn the unit off then back on.
7. Turn the ZXi-10G off. Wait at least 5 seconds then turn the ZXi-10G back on.
8. Verify the software version by going to the Software Updates screen then go to
6.4 Firmware Update
Logicube ZXi-10G™ User's Manual
to check if there is a firmware update available.
SOFTWARE FOUND – A software version is found on the USB flash drive. Tap
the OK icon to continue.
UPDATES NOT FOUND! – The ZXi-10G did not find any software on the USB
flash drive or could not detect the USB flash drive. If this message is seen, try
the following:
▪ Make sure the correct software was downloaded and the files were
extracted to the root of the USB flash drive, or
▪ Format and use a different USB flash drive, or
▪ Try using the "From Network" option (see
to check if there is a firmware update available.
UPDATING THE SOFTWARE AND FIRMWARE
Section 6.3.1)
Section
82
