General 90-200 M1 Setup & Operation Manual

15” adjustable height wood cutting bandsaw
Table of Contents

Advertisement

Quick Links

SETUP & OPERATION MANUAL
FEATURES
Cast-iron frame & precision-balanced cast-
iron wheels with replaceable rubber tires.
Closed stand model features a rigid one
piece welded stand.
Deluxe 2-position extruded aluminum rip
fence, ideal for ripping thin stock and re-
sawing taller work pieces.
Deluxe blade guide bearings included.
2 cutting speeds for excellent results in
either hard or soft wood.
Smooth 0° - 45° handwheel controlled
table tilting mechanism.
Table tilting scale is located on table top
for easy reading.
Adjustable cutting depth from 5 5/8" to 12".
Hinged doors & easily accessible blade
tensioning knob, for fast blade changes or
adjustments.
Quick release blade tension lever.
93 1/2" X 3/8" & 105" X 3/8" blades included.
Aluminum miter gauge, laser line marker
and worklight included.
SPECIFICATIONS
WHEEL SIZE
15" (375 MM)
WHEEL SPEED
405 & 700 RPM
MAXIMUM BLADE WIDTH
3⁄4" (19 MM)
MINIMUM BLADE WIDTH
1⁄4" (6.4 MM)
BLADE LENGTH
93 1⁄2" TO 106 3/8" (2375 TO 2702 MM)
BLADE SPEEDS
1570 & 2660 FPM (480 & 810 MPM)
TABLE SIZE
16" x 16" (408 x 408 MM)
TABLE TILT
0° TO 45° (RIGHT)
TABLE HEIGHT
41 3⁄4" (1060 MM)
MAXIMUM WIDTH OF CUT
14 3⁄4" (374 MM)
MAXIMUM DEPTH OF CUT
5 5/8"-12" (142 - 305 MM)
DUST COLLECTION PORT
4" (102 MM)
OVERALL DIMENSIONS
30" X 37 13⁄16" X 65 3⁄4"
(762 X 960 X 1670 MM)
MOTOR
1 1⁄2 HP , 110 V, 15 A
WEIGHT
398 LBS (181 KG)
15" ADJUSTABLE HEIGHT
WOOD CUTTING BANDSAW
MODEL
# 90-200 M1
VERSION 1_REVISION 1 - February 23/09 (91578708)
© Copyright General® International 02/2009
