SETUP & OPERATION MANUAL
FEATURES
THREE SAWS IN ONE! COMPACT & VERSATILE
DESIGN. CAN BE USED AS A REGULAR SAW, BUT
INCLUDES A BUILT IN SLIDING TABLE FOR STABLE
EFFORTLESS CROSSCUTS & A SEPARATE SCORING
BLADE FOR CHIP FREE CUTS IN MELAMINE &
LAMINATES.
Powerful totally enclosed fan cooled (TEFC)
main motor and separate 1/2 HP motor for
scoring blade.
Separate safety lock out switch for scoring mo-
tor – can be turned off when cutting solid wood.
Quick release riving/see-through blade guard-
knife with direct dust extraction hook up.
Solid cast-iron table with anodized aluminum
coating for improved friction-free performance
and longer table life.
Includes deluxe cast-iron miter gauge - one
miter gauge T-slot in table.
Heavy-duty cabinet mounted cast-iron trun-
nions.
Precision built rip fence system with 50" guide
rails for maximum rip capacity.
Cross cut fence with precision angle indicator
fully adjusts up to 45° left or right, includes easy
to use flip up work stop and workpiece hold-
down.
Arbor lock for easy blade changes on main
and scoring arbor, with safety lock-out in blade
change area.
Second operator's safety stop switch.
SPECIFICATIONS
• Main blade / Arbor diameter
10" (254 mm) / 5/8" (16 mm)
• Scoring blade / Arbor diameter
4" (102 mm) / 20 mm
• Arbor tilt range
0° to 45° (to right)
• Arbor speed
(Main) 4200 rpm / (Scoring) 8000 rpm
• Maximum depth of cut at 90° / at 45°
3 1/8" (80 mm) / 2 1/8" (54 mm)
• Maximum crosscut capacity
(In front of blade) 55" (1400 mm)
• Maximum rip to right of blade
50" (1270 mm)
• Dado capacity
3/4" (19 mm)
• Dust outlet
Cabinet - 4" (102 mm) & 2 1/2" (64 mm) hose
Blade cover - 2 1/2" (64 mm)
• Sliding table dimensions
59" x 11" (1500 x 320 mm)
• Main table size (with one extension wing)
36 3/4" x 21" (935 x 600 mm)
• Extension table size (steel)
34 7⁄16" x 32 7/8" (875 x 835 mm)
• Main motor
M1 3 HP , 220 V, 1 Ph, 12.8 A
M2 5 HP , 220 V, 3 Ph, 13 A
M3 5 HP , 600 V, 3 Ph, 4.7 A
• Scoring motor
1/2 HP , M1: 3.4 A / M2: 1.9 A / M3: 0.8 A
• Weight
656 lbs (298 kg)
Version 2_Revision 2 - Mai 2016
© Copyright General International
10" SCORING SAW
- WITH BUILT-IN SLIDING TABLE & RIGHT TILT
MODEL
#50-560A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50-560A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for General 50-560A

  • Page 1 M3 5 HP , 600 V, 3 Ph, 4.7 A • Scoring motor 1/2 HP , M1: 3.4 A / M2: 1.9 A / M3: 0.8 A #50-560A • Weight 656 lbs (298 kg) Version 2_Revision 2 - Mai 2016 © Copyright General International...
  • Page 2 GENERAL® INTERNATIONAL 8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Telephone (514) 326-1161 • Fax (514) 326-5555 • www.general.ca THANK YOU for choosing this General International model 50-560A 10" ® right tilt scoring saw with built-in sliding table. This saw has been carefully tested and inspect- ed before shipment and if properly used and maintained, will provide you with years of reliable service.
  • Page 3 2 years (24 months) from the date of pur- chase. General® International agrees to repair or replace any part or component which upon exam- ination, proves to be defective in either workmanship or material to the original purchaser during this 2-year warranty period, subject to the “conditions and exceptions”...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Rules for safe operation ..................... 5 Electrical requirements ...................... 6 Identification of main parts and components ..............7 Basic functions ........................8 Installation ......................... 8 Unpacking .......................... 9 Clean up .......................... 10 Assembly instructions ....................10-29 Installing the sliding table ..........................10 Installing the magnetic switch ........................
  • Page 5: Rules For Safe Operation

    To help ensure safe operation, please take a moment to learn the machine’s applications and limitations, as well as potential hazards. General ® International disclaims any real or implied warranty and holds itself harmless for any injury that may result from the improper use of its equipment.
  • Page 6: Electrical Requirements

    ELECTRICAL REQUIREMENTS BEFORE CONNECTING THE MACHINE TO THE POWER SOURCE, VERIFY THAT THE VOLTAGE OF YOUR POWER SUPPLY CORRESPONDS WITH THE VOLTAGE SPECIFIED ON THE MOTOR I.D. NAMEPLATE. A POWER SOURCE WITH GREATER VOLTAGE THAN NEEDED CAN RESULT IN SERIOUS INJURY TO THE USER AS WELL AS DAMAGE TO THE MACHINE.
  • Page 7: Identification Of Main Parts And Components

    IDENTIFICATION OF MAIN PARTS AND COMPONENTS FRONT VIEW CABINET RIGHT EXTENSION WING BLADE TILT ADJUSTMENT HANDWHEEL MAIN RIP FENCE BODY SAFETY STOP SWITCH STEEL TABLE EXTENSION MITER GAUGE STORAGE BRACKET FRONT FENCE RAIL CROSS CUT FENCE ADJUSTABLE SUPPORT LEGS AUXILIARY TABLE CABINET DUST HOSE SLIDING TABLE SCORING MOTOR SAFETY LOCK-OUT SWITCH...
  • Page 8: Basic Functions

    INSTALLATION THIS MODEL 50-560A 10” SCORING SAW IS HEAVY. DO NOT OVER-EXERT. A HOIST OR FORKLIFT WITH STRAPS SHOULD BE USED TO LIFT THIS MACHINE. TO LIMIT THE RISK OF SERIOUS INJURY OR DAMAGE TO THE MACHINE, ANY EQUIP- MENT USED TO LIFT THIS MACHINE SHOULD HAVE A RATED CAPACITY IN EXCESS OF 656 LBS (298 KG).
  • Page 9: Unpacking

    Carefully unpack and remove the saw and its components from the shipping crate and check for damaged or missing items as per the list of contents below. NOTE: PLEASE REPORT ANY DAMAGED OR MISSING ITEMS TO YOUR GENERAL® INTERNATIONAL DISTRIBUTOR IMMEDIATELY. LIST OF CONTENTS RIP FENCE FACE ...............
  • Page 10: Clean Up

    CLEAN UP The protective coating on the saw table prevents rust from forming during shipping and storage. Remove it by rubbing with a rag dipped in kerosene, mineral spir- its or paint thinner. (Dispose of potentially flammable solvent-soaked rags according to manufacturer’s safe- ty recommendations).
  • Page 11 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE SLIDING TABLE (CONTINUED) Place the two spacers A between the sliding table Note: To use the saw with a dado blade, place the spacers...
  • Page 12: Installing The Magnetic Switch

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE SLIDING TABLE (CONTINUED) Place a square or a straight edge across the table and 10.
  • Page 13: Installing The Safety Stop Switch

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE SAFETY STOP SWITCH Install the switch on the front support by aligning its Secure the switch to its support by tightening the...
  • Page 14: Installing The Table Extension Wing

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE DUST OUTLET AND CONNECTING THE INTERNAL HOSE (CONTINUED) Install the hose clamp onto the end of the hose in- Slide the hose onto the outlet, then tighten the hose...
  • Page 15: Installing The Rear Auxiliary Table

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE REAR AUXILIARY TABLE Set the auxiliary table upside down and align the Using a 12 mm wrench, secure each leg to the ta-...
  • Page 16 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE REAR AUXILIARY TABLE (CONTINUED) Secure each flange to its rod using a Phillips screw- Measure the distance from the top of the table ex-...
  • Page 17: Installing The Rip Fence

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE REAR AUXILIARY TABLE (CONTINUED) 13.
  • Page 18 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE RIP FENCE (CONTINUED) Hand tighten a nut with a flat washer onto each rod Remove the stop at the end of the rail using a 5 mm...
  • Page 19 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE RIP FENCE (CONTINUED) 11.
  • Page 20 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE RIP FENCE (CONTINUED) 15.
  • Page 21: Installing And Connecting The Dust Tube

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE RIP FENCE (CONTINUED) 21.
  • Page 22 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING AND CONNECTING THE DUST TUBE (CONTINUED) Install the motor cover door on the back of the ma- Pull back the lock lever, close the door, and then...
  • Page 23: Installing A Main Blade (Optional)

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING A MAIN BLADE (OPTIONAL) This saw is intended for use with 10”...
  • Page 24: Installing A Scoring Blade (Optional)

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING A MAIN BLADE (OPTIONAL) Install a blade on the arbor making sure the teeth Re-install the flange with the concave side against...
  • Page 25 BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING A SCORING BLADE (OPTIONAL) Remove the arbor nut by turning it counterclockwise, Install a scoring blade on the arbor with the teeth...
  • Page 26: Installing And Connecting The Blade Cover

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING AND CONNECTING THE BLADE COVER Open the lower blade guard.
  • Page 27: Installing The Sliding Table Handle

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING AND CONNECTING THE BLADE COVER (CONTINUED) Slide one end of the hose onto the dust tube, then Slide the other end of the hose onto the blade cover...
  • Page 28: Installing The Cross Cut Fence

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE CROSS CUT FENCE Slide the fence face onto the fence body as shown.
  • Page 29: Installing The Small Auxiliary Table

    BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS UN- PLUGGED. DO NOT PLUG IN OR TURN ON THE SAW UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL. INSTALLING THE SMALL AUXILIARY TABLE Install the auxiliary table lock lever.
  • Page 30: On/Off Magnetic Power Switch (Main Blade)

    ON/OFF MAGNETIC POWER SWITCH (MAIN BLADE) This machine is equipped with a magnetic 2-step safety switch to prevent unintentional start-up and unauthorized use. The switch assembly is equipped with a “START” but- ton A, an extra-large easy access stop panel B, and a lock-out key C.
  • Page 31: Blade Tilt (Bevel) Adjustment

    BLADE TILT (BEVEL) ADJUSTMENT Loosen the bevel lock knob F by turning it counter- clockwise. Using the graduated scale G as a guide, turn the handwheel left or right as required to set the blade to the desired angle. The blade can be tilted to the left anywhere from 0°...
  • Page 32 MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORM- ING ANY MAINTENANCE OR ADJUSTMENTS. RIVING KNIFE ADJUSTMENT (CONTINUED) To set the splitter/knife 90º to the table proceed as follows: Position the blade at 90° by turning the tilt hand- Raise the blade by turning the blade height hand- wheel all the way to the right.
  • Page 33: Aligning The Table To The Blade

    MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORM- ING ANY MAINTENANCE OR ADJUSTMENTS. Aligning the riving knive to the blade. Note: To perform this adjustment, the riving knife must first be squared to the table. Unscrew screws A using a 4 mm Allen key.
  • Page 34: Scoring Blade Alignment To The Main Blade

    MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORM- ING ANY MAINTENANCE OR ADJUSTMENTS. ALIGNING THE TABLE TO THE BLADE (CONTINUED) Loosen screws A with a 8 mm Allen key. Loosen screws B and move the main table on its slotted holes so that the table is aligned with the blade.
  • Page 35: Level The Table Insert

    If you do not already own a dust collection system con- sider contacting your General® International distrib- utor for information on our complete line of dust col- lection systems and accessories or visit our web site at www.general.ca.
  • Page 36 NEVER REACH IN TOWARDS THE BLADE WHILE THE BLADE IS STILL SPINNING! WHENEVER A RIP CUT IS COMPLETED, TURN OFF THE SAW AND WAIT FOR THE BLADE TO COME TO A COMPLETE STOP BEFORE REACHING IN TO REMOVE THE WORKPIECE OR THE WASTE MATERIAL. TYPES OF CUTS (CONTINUED) Ripping (continued) •...
  • Page 37: Using A Dado Blade

    USING A DADO BLADE ALWAYS VERIFY THE DADO BLADE CLEARANCE BEFORE CONNECTING THE SAW TO THE POWER SOURCE. RE-ATTACH THE GUARD AND ADJUST AFTER DADO CUT IS FINISHED. THE MAXIMUM DADO HEAD WIDTH FOR THIS SAW IS 3/4” (19 MM) AND THE MAXIMUM DADO BLADE DIAMETER IS 8”.
  • Page 38: Maintenance

    MAINTENANCE MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORM- ING ANY MAINTENANCE OR ADJUSTMENTS. PERIODIC MAINTENANCE • Inspect/test all the switches before each use. Do not operate the saw with a damaged switch - replace a damaged switch immediately •...
  • Page 39: Adjusting The Bevel Angle Pointer

    MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORM- ING ANY MAINTENANCE OR ADJUSTMENTS. ADJUSTING THE BEVEL ANGLE POINTER The bevel pointer should read “0” when the blade is at 90° to the table. If not, proceed as follows: 90°...
  • Page 40: Lubrication

    We offer a large variety of products to increase convenience, productivity, accuracy and safety when using your saw. Here’s a small sampling of optional accessories available from your local General International dealer. For more information about our products, please visit our website at www.general.ca...
  • Page 41: Parts List & Diagrams

    DIAGRAM 50-560A - SLIDING TABLE ASSEMBLY (1500 MM)
  • Page 42 PARTS LIST 50-560A - SLIDING TABLE ASSEMBLY (1500 MM) IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. PART NO. REF. NO.
  • Page 43 PARTS LIST 50-560A - SLIDING TABLE ASSEMBLY (1500 MM) IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. PART NO. REF. NO.
  • Page 44 DIAGRAM 50-560A - TABLE AND CABINET ASSEMBLY...
  • Page 45 PARTS LIST 50-560A - TABLE AND CABINET ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO.
  • Page 46 PARTS LIST 50-560A - TABLE AND CABINET ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO.
  • Page 47 DIAGRAM 50-560A - RIP FENCE ASSEMBLY...
  • Page 48 PARTS LIST 50-560A - RIP FENCE ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO. DESCRIPTION...
  • Page 49 DIAGRAM 50-560A - MOTOR AND TRUNNION ASSEMBLY...
  • Page 50 PARTS LIST 50-560A - MOTOR AND TRUNNION ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO.
  • Page 51 PARTS LIST 50-560A - MOTOR AND TRUNNION ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO.
  • Page 52 PARTS LIST 50-560A - MOTOR AND TRUNNION ASSEMBLY IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO.
  • Page 53 DIAGRAM 50-560A - SCORING UNIT SYSTEM ASSEMBLY...
  • Page 54 PARTS LIST 50-560A - SCORING UNIT SYSTEM ASSEMBLY IMPORTANT: Lorsque vous commandez des pièces de remplacement, veuillez indiquer le numéro du modèle et le numéro de série de la machine. Veuillez également fournir le numéro de pièce, une brève description, ainsi que la quantité requise pour chacune des pièces.
  • Page 55 DIAGRAM 50-560A - BLADE COVER...
  • Page 56 PARTS LIST 50-560A - BLADE COVER IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. PART NO. REF. NO. DESCRIPTION SPECIFICATIONS...
  • Page 57 DIAGRAM 50-560A - REAR AUXILIARY TABLE IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired. #PART NO. REF. NO. DESCRIPTION SPECIFICATIONS...
  • Page 58 WIRING DIAGRAM SINGLE PHASE...
  • Page 59 WIRING DIAGRAM THREE PHASE...
  • Page 60: Contact Information

    8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Tel.: (514) 326-1161 Fax: (514) 326-5565 - Parts & Service / (514) 326-5555 - Order Desk orderdesk@general.ca www.general.ca Follow us:...
