INSTALLATION INSTRUCTIONS
安装说明书
11679T
安装之前
所有的资料是按最新出版的产品资料编写而成。科
勒公司保留任何时候不经通知即可改变产品特性、
包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项：
1. 遵守当地管路安装条例。
2. 关闭主供水源。
3. 尽可能在安装面盆之前安装水龙头。
使用说明
按压提拉头，打开排水。
安装尺寸
Ø54
Ø36.5
176.5
Ø31.75
1155382-2-A
Deck-Mount Pop-Up Drain
台面式提拉落水
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication. Kohler
Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They
contain important information.
NOTES:
1. Observe local plumbing codes.
2. Shut off the main water supply.
3. If possible, install this drain before installing the
lavatory.
HANDLE OPERATION
Press the button to open the drain.
ROUGH-IN DIMENSIONS
Ø27
Ø20
210
