- Page 1 AUTOMATIC FILM APPLICATOR BEVS 1818 User Manual （Version V201805） This manual shall be read carefully before starting. Directions included in this operation manual shall be strictly followed.
-
Page 2: Table Of Contents
Content 1.Company Profile..........................1 2.Product Introduction ........................1 2.1 Technical Specifications ......................2 3. Product Operation Introduction ....................3 3.1 Name and description of each part ..................3 3.2 Operation Steps ........................3 3.3 Touch Screen Operation。 ...................... 4 3.4 Parameter Setting ........................6 3.5 System Setting......................... -
Page 3: Company Profile
1.Company Profile BEVS Industrial Co., Ltd. is a leading manufacturer that specializes in coatings, ink, painting, resin testing instruments and laboratory whole solution. Our company has passed ISO9001:2008 quality system certification. We offer the complete and unique products in this field to meet customer's challenging demands of today and tomorrow, the products are complied with the standards of ISO, ASTM, DIN, JIS, BS, etc. -
Page 4: Technical Specifications
2.1 Technical Specifications 2.11 Model：BEVS1818GV、BEVS1818G、BEVS1818V 2.12 Maximum Film Length：250mm 2.13 Speed: 1mm/s-200mm/s (Adjustable) 2.14 Speed Precision：1mm/s 2.15 Dimensions (length × width × height)：450 mm× 300 mm× 210 mm 2.16 Test platform: glass test platform or vacuum test platform 2.17 N.W: 14Kg 2.18 Film distance can be adjusted freely 2.19 Power: 120W... -
Page 5: Product Operation Introduction
3. Product Operation Introduction 3.1 Name and description of each part 3.2 Operation Steps 1. Place the instrument on horizontal surface. 2. Clean the vacuum test platform (or glass test platform) to avoid dust affecting the film. 3. Connect the power and turn on the power switch. 4. -
Page 6: Touch Screen Operation
screw. At this time, it is measured as the lower station. If you loosen the locking screw of the clamp kits, let it automatically bounce to the highest position, and then tighten the screw, this is the upper station. 7．Refer to the 3.3, Touch Screen Operation 8．Press the “Run”... - Page 7 3.3.4 After selecting the language, enter the system screen (as shown). Click the "Open Vacuum" button and vacuum will turn on. and then it will fix the coating test panel. Note: 1. Firstly, put the base material on the vacuum table and then turn on the vacuum, otherwise it will be difficult to adjust the position after vacuum adsorption.
-
Page 8: Parameter Setting
3.3.6 Make sure that the specimens, vacuum test platform (or glass test platform) is clean, place the applicator or wire bar coater smoothly, and then put the paint in front of the applicator. 3.3.7 Make sure that all the testing condition is ready, click the “Start” button to start testing. 3.3.8 Press “Stop”... -
Page 9: Maintenance
2）Changing the language (switch between Chinese and English) 3）Turn on or off the buzzing 4）When you choose the power saving mode, the screen brightness will be off if the screen is not touched for a long time. Changing Brightness Changing Language Turn on/off the buzzing When you choose the power saving mode, the screen... -
Page 10: Attention
5.Attention 5.1. Make sure the machine is being used in the environment of dry and no-corrosiveness 5.2. Place the machine in the solid working platform 5.3. Reliable ground lead is necessary in power outlet 5.4. Working Environment: Using the machine in the inside room and the temperature is between 15℃~35℃...
