Automatic Cupping Tester
Version 201503
This manual shall be read carefully before starting. Directions included in this operation manual
shall be strictly followed.
Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China
E-mail:sales@bevsinfo.com
BEVS 1606
User Manual
PAGE 1
Http://www.bevsinfo.com
Advertisement
Table of Contents
Related Manuals for BEVS 1606
Summary of Contents for BEVS 1606
- Page 1 Automatic Cupping Tester BEVS 1606 User Manual Version 201503 This manual shall be read carefully before starting. Directions included in this operation manual shall be strictly followed. PAGE 1 Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China E-mail:sales@bevsinfo.com Http://www.bevsinfo.com...
- Page 2 Content 1 Company Profile 2 Product Introduction 2.1 Technical Specification 2.2 Feature 3 Operation Introduction 3.1 Operating Environment 3.2 Power 3.3 Operation Guideline 4 Maintenance 5 Attention 6 Order Information of Accessories PAGE 2 Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China E-mail:sales@bevsinfo.com Http://www.bevsinfo.com...
-
Page 3: Product Introduction
1 Company Profile BEVS Industrial Co., Ltd. is a leading manufacturer that specializes in coatings, ink, painting, resin testing instruments and laboratory whole solution. We offer the complete and unique products in this field to meet customer's challenging demands of today and tomorrow, the products are complied with the standards of ISO, ASTM, DIN, BS, EN etc. -
Page 4: Operating Environment
2.2 Features Touch screen control technology Customized operation system Mouse directly connect with instrument Directly input testing parameter via screen or mouse Realtime display cupping process Realtime monitor cupping image Realtime show cupping speed and depth ... - Page 5 Figure 1 3.3.2The main interfaces as shown in Figure 2: Figure 2 Realtime display Realtime show cupping The operation button cupping process speed and depth area PAGE 5 Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China E-mail:sales@bevsinfo.com Http://www.bevsinfo.com...
- Page 6 3.3.3 The Cupping Test： 1.If it’s the first time to do the cupping test，please click the button ”Preset” to enter into the below interface: Figure 3 1.1 In this interface, you can set the ”Depth” and “Speed” as request. 1.2 The option of “automatic back to zero” means when the test is finished, the machine will back to zero automatically.
- Page 7 Figure 4 2 If you first use the machine, the machine has been accurately calibrate to zero when out of factory. You can chose “confirm” to the interface below, just chose “Next” button: Figure 5 3 When in the interface below Figure 6, should install the test board firstly: PAGE 7 Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China E-mail:sales@bevsinfo.com...
-
Page 8: Zero Calibration
Figure 6 If you have not adjusted the camera, please adjust the camera in this step. The camera focus has been adjusted in place when out of factory, you only need to well-place the camera and the USB firstly, and then tighten the three screws. You can gently twist the shaft between the camera lens and test board to get the best viewing effect. -
Page 9: Normal "Power Off"
5.4 Not allow to operate in potential explosive environment and in liquid status 5.5 Must operate in the horizontal table 5.6 Not allow to touch the inner part when the instrument is working 6 Order Information BEVS 1606 Automatic Cupping Tester PAGE 9 Add: Floor3,Building A,No.257,Junye Road,Huangpu District,Guangzhou,China E-mail:sales@bevsinfo.com...
