MODEL G0702
12" DISC SANDER w/BRAKE
OWNER'S MANuAL
(For models manufactured since 12/11)
Copyright © SEptEMBEr, 2009 By grizzly induStrial, inC. rEviSEd novEMBEr, 2011 (Kn)
WARNING: NO pORtION Of thIS MANuAL MAy BE REpRODuCED IN ANy ShApE
OR fORM WIthOut thE WRIttEN AppROvAL Of GRIzzLy INDuStRIAL, INC.
(For ModElS ManuFaCturEd SinCE 12/11) #Cr12124 printEd in taiWan.

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G0702

Summary of Contents for Grizzly G0702

  • Page 1 OWNER'S MANuAL (For models manufactured since 12/11) Copyright © SEptEMBEr, 2009 By grizzly induStrial, inC. rEviSEd novEMBEr, 2011 (Kn) WARNING: NO pORtION Of thIS MANuAL MAy BE REpRODuCED IN ANy ShApE OR fORM WIthOut thE WRIttEN AppROvAL Of GRIzzLy INDuStRIAL, INC.
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Calibration ... 22 SECtION 8: WIRING ... 23 Wiring Safety instructions ... 23 Wiring diagram... 24 SECtION 9: pARtS ... 25 Main Breakdown and parts list ... 25 label parts list ... 26 Model g0702 (Mfg. since 8/09) table of Contents...

  • Page 4: Introduction

    Bellingham, WA 98227-2069 Email: manuals@grizzly.com Machine Description the Model g0702 disc Sander features a 1 hp, 120v, 1720 rpM motor equipped with a motor brake and a 12" diameter sanding disc. the preci- sion ground cast iron table is cut with two miter...

  • Page 5: Machine Data Sheet

    Machine Data Sheet Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0702 12" DISC SANDER WITH BRAKE Product Dimensions: Weight... 84 lbs. Width (side-to-side) x Depth (front-to-back) x Height... 26-1/2 x 17-1/8 x 16-3/8 in.

  • Page 6: Identification

    Wear eye and ear protection. b) Support workpiece on worktable. c) Maintain the smallest gap possible d) Avoid kickback by sanding in accordance Identification figure 1. Model g0702 disc Sander. dust port (opening not visible) adapter Base tilt Scale universal lock lever...

  • Page 7: Section 1: Safety

    NIOSH-approved respirator to reduce your risk. Model g0702 (Mfg. since 8/09) WEARING PROPER APPAREL. Do not wear clothing, apparel, or jewelry that can become entangled in moving parts. Always tie back or cover long hair.
  • Page 8 Do­ not­ handle­ ­ cord/plug­with­wet­hands.­Avoid­cord­damage­by­ keeping­it­away­from­heated­surfaces,­high­traffic­ areas,­harsh­chemicals,­and­wet/damp­locations. EXPERIENCING DIFFICULTIES. If­ at­ any­ time­ you­ are­ experiencing­ difficulties­ performing­ the­ intended­ operation,­ stop­ using­ the­ machine!­ Contact­ our­ Technical­ Support­ Department­ at­ (570)­546-9663. Model g0702 (Mfg. since 8/09)

  • Page 9: Additional Safety For Disc Sanders

    If normal safety pre- cautions are overlooked or ignored, serious personal injury may occur. Model g0702 (Mfg. since 8/09) pOSItION tABLE CORRECtLy. Make sure the gap between the table and sanding disc does not exceed ⁄...

  • Page 10: Section 2: Power Supply

    This machine is prewired to operate on a 110V power supply circuit that has a verified ground and meets the following requirements: Nominal voltage ... 120v Cycle ...60 hz phase ... Single-phase power Supply Circuit ... 15 Amps plug/Receptacle ... NEMA 5-15 Model g0702 (Mfg. since 8/09)

  • Page 11: Grounding Requirements

    Grounding Prong 5-15 PLUG Neutral Hot figure 2. typical 5-15 plug and receptacle. Model g0702 (Mfg. since 8/09) SHOCK HAZARD! Two-prong outlets do not meet the grounding requirements for this machine. Do not modify or use an adapter on the plug provided—if...

  • Page 12: Section 3: Setup

    Before cleaning, gather the following: • Disposable Rags Model g0702 (Mfg. since 8/09) • Cleaner/degreaser (WD•40 works well) • Safety glasses & disposable gloves...

  • Page 13: Site Considerations

    Test all cleaners in an inconspicuous area before using to make sure they will not damage paint. Model g0702 (Mfg. since 8/09) Avoid chlorine-based solvents, such as acetone or brake parts cleaner, that may Site Considerations damage painted surfaces.

  • Page 14: Mounting

    Connecting power 1. Turn the machine power switch OFF. 2. Insert the power cord plug into a matching power supply receptacle. The machine is now connected to the power source. figure 6. Connecting power. Lag Screw Flat Washer Model g0702 (Mfg. since 8/09)

  • Page 15: Test Run

    Make sure all tools and objects used during setup are cleared away from the machine. Model g0702 (Mfg. since 8/09) Connect the machine to the power source. verify that the machine is operating correctly by turning the machine ON.

  • Page 16: Section 4: Operations

    OMMEND that you read books, review industry trade magazines, or get formal training before beginning any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training. -14- Operation Overview this overview gives you the basic process that happens during an operation with this machine.

  • Page 17: Attaching Sandpaper

    Attaching Sandpaper the Model g0702 sander accepts 12" diameter adhesive-backed sanding discs. these are avail- able in a variety of grits. See the current grizzly catalog for prices and ordering information. the sanding disc sticks to the surface of the cast iron disc platen, using the pressure sensitive adhesive backing (pSa).

  • Page 18: Miter Sanding

    (figure 13). rotation figure 13. Sanding with table angled. Model g0702 (Mfg. since 8/09) Low Trapping Hazard Low Kickback Hazard...

  • Page 19: Section 5: Accessories

    Grizzly. NOTICE Refer to the newest copy of the Grizzly Catalog for other accessories available for this machine. Sanding Discs from ISO 9002 factories MODEL and typE g1220 12"...

  • Page 20: Section 6: Maintenance

    Cleaning Cleaning the Model g0702 is easy. vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. if any resin has built up, use a resin dissolving cleaner to remove it.

  • Page 21: Section 7: Service

    3. Workpiece is incorrect for machine. 4. Motor connection wired incorrectly. 5. Motor overheated. 6. Centrifugal switch at fault. 7. Motor at fault. Model g0702 (Mfg. since 8/09) troubleshooting possible Solution 1. reinstall switch disabling key. 2. trace/replace broken or corroded wires, fix loose connections, correct wiring.
  • Page 22 4. use different stock. or, accept the characteristics of the stock and plan on cleaning/replacing sandpapers frequently. 5. replace sandpaper. 6. reduce sanding depth or install coarser sandpaper. 1. Store sandpaper away from extremely dry, hot, or damp conditions. Model g0702 (Mfg. since 8/09)

  • Page 23: Table/Disc Parallelism

    Model g0702 (Mfg. since 8/09) Miter Gauge Calibration at 90˚ the miter gauge should be perpendicular to the face of the wheel when it is mounted in the table slot.

  • Page 24: Table Tilt Calibration

    0˚, and retighten the screw. recheck the scale accuracy with the square. Model g0702 (Mfg. since 8/09)

  • Page 25: Section 8: Wiring

    You can view these pages in color at www.grizzly.com. Model g0702 (Mfg. since 8/09) WIRE/COMPONENT DAMAGE. Damaged wires or components increase the risk of serious per- sonal injury, fire, or machine damage. If you notice...

  • Page 26: Wiring Diagram

    20. Electrical system. REGULATOR TYPE CS-021 MOTOR ELECTRICAL BOX COVER The motor wiring shown here is current at the time of printing, but it match your machine. Always use the wiring diagram inside the motor junction box. Model g0702 (Mfg. since 8/09)

  • Page 27: Section 9: Parts

    P0702011 ADJUSTABLE HANDLE P0702012 TRUNNION SCALE POINTER PS07M PHLP HD SCR M4-.7 X 8 PLW03M LOCK WASHER 6MM Model g0702 (Mfg. since 8/09) REF PART # PS03M PS14M PW03M PS32M PS04M PN03M PWRCRD110L POWER CORD 16AWG X 3C X 73"L...

  • Page 28: Label Parts List

    Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com. -26-...
  • Page 29 Do you think your machine represents a good value? Would you recommend Grizzly Industrial to a friend? Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times.
  • Page 30 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...

  • Page 31: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 32 Buy Direct and Save with Grizzly – Trusted, Proven and a Great Value! ® ~Since 1983~ Visit Our Website Today For Current Specials! ORDER 24 HOURS A DAY! 1-800-523-4777...
