INTRODUCTION
Thank you for choosing Tornado Industrial Vacuum Cleaner, a high-quality product
based on the newest state-of-the-art technology. We hope that this device will be
to your satisfaction and meet your expectations. We are continuously striving to
improve our products in our product segment and will continue to supply the
market with new equipment.
NOTICE!
1.These instructions are only for the air scrubber B2000.
2. The air cleaner can only be used to collect dry, non-explosive materials. It is not suitable for
picking up liquids.
3. Please pay particular attention to the safety regulations and safety instructions
4. Read the complete instruction manual before using.
5. All spare parts and accessories used with this device must be those specified by Tornado.
6. Check before and after use that all the switches are in OFF position.
Environmental protection
The packaging material can be recycled. Please do not throw the packaging material into
household waste; please send it for recycling.
Old devices contain valuable materials that can be recycled; these should be sent for
recycling. Batteries, oil, and similar substances must not enter the environment. Please dispose
of your old devices using appropriate collection systems.
UNPACKING
When unpacking the machine, please check that the air cleaner has not been damaged in
transport

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tornado B2000

  • Page 1 3. Please pay particular attention to the safety regulations and safety instructions 4. Read the complete instruction manual before using. 5. All spare parts and accessories used with this device must be those specified by Tornado. 6. Check before and after use that all the switches are in OFF position.
  • Page 2: Safety Instructions

    1. SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: WARNING – To reduce the risk of fire, electric shock or injury: Cables damaged through crushing or splitting can be dangerous if used and should be replaced ...
  • Page 3: Warranty

    • The absolute filters cannot be cleaned and must be replaced when full Filter indicator B2000 has two filter indicators connected to a warning light which measures the pressure drop over the filter. If the pressure drop is too high, an orange lamp light up, indicating that the filter is clogged and should be changed.
  • Page 4: Problem Solving

    Loose top cover Adjust Sealing defect Change current seal Defective or loose filter Adjust/Replace filters Dust blown from motor Abnormal noise Order service 10. TECHNICAL DATA Model B2000 Power 610W Voltage 230V Current 2.9A Power supply 1-phase Airflow 2000 m3/h Pre filter area 0.64m2...
  • Page 5 Explosive view Description Qty Dimension Note S8065 B2000 Pre filter protect cover S8064 B2000 Pre filter C2326 B2000 Front frame cover S8063 B2000 Hepa filter C2328 B2000 inlet S9035 Protective net for outlet S9037 Buckle C3051 B2000 Frame carbinet S1056...
