- Page 1 Installation, use and maintenance instructions Forced draught gas burners Modulating operation CODE MODEL TYPE 20081190 RS 1300/EV C01 S001T2 20080871 RS 1600/EV C01 S006T2 20070919 RS 2000/EV C01 S007T2 20089633 (5) - 11/2021...
- Page 2 Translation of the original instructions...
-
Page 3: Table Of Contents
Contents Declarations....................................3 Information and general warnings............................4 Information about the instruction manual ........................4 2.1.1 Introduction.................................. 4 2.1.2 General dangers................................4 2.1.3 Other symbols ................................4 2.1.4 Delivery of the system and the instruction manual...................... 5 Guarantee and responsibility............................5 Safety and prevention................................ - Page 4 Contents Combustion air adjustment ............................27 6.5.1 Air / gas adjustment and output modulation.......................27 Pressure switch adjustment ............................28 6.6.1 Air pressure switch - check CO..........................28 6.6.2 Maximum gas pressure switch...........................28 6.6.3 Minimum gas pressure switch............................28 6.6.4 PVP pressure switch kit .............................29 Final checks (with burner operating) ..........................29 Maintenance ....................................30 Notes on safety for the maintenance .........................30...
-
Page 5: Declarations
Declarations Declarations Declaration of Conformity in accordance with ISO / IEC 17050-1 These products are in compliance with the following Technical Standards: • EN 12100 • EN 676 According to the European Directives: 2006/42/CE Machine Directive 2014/35/UE Low Voltage Directive EMC 2014/30/UE Electromagnetic Compatibility The quality is guaranteed by a quality and management system certified in accordance with ISO 9001:2015. -
Page 6: Information And General Warnings
Information and general warnings Information and general warnings Information about the instruction manual 2.1.1 Introduction WARNING: MOVING PARTS The instruction manual supplied with the burner: This symbol indicates that you must keep limbs is an integral and essential part of the product and must not away from moving mechanical parts;... -
Page 7: Delivery Of The System And The Instruction Manual
Information and general warnings 2.1.4 Delivery of the system and the instruction The system supplier must carefully inform the user about: – the use of the system; manual – any further tests that may be required before activating the When the system is delivered, it is important that: system;... -
Page 8: Safety And Prevention
Safety and prevention Safety and prevention Introduction The burners have been designed and built in compliance with the type and pressure of the fuel, the voltage and frequency of the current regulations and directives, applying the known technical electrical power supply, the minimum and maximum deliveries for rules of safety and envisaging all the potential danger situations. -
Page 9: Technical Description Of The Burner
110/50/60 110V / 50-60Hz 1600 3/400/50 230/50/60 BASIC DESIGNATION EXTENDED DESIGNATION Models available Designation Voltage Start-up Code RS 1300/EV C01 FS1 3/400/50 Direct/Inverter 20081190 RS 1600/EV C01 FS1 3/400/50 Direct/Inverter 20080871 RS 2000/EV C01 FS1 3/400/50 Direct/Inverter 20070919 Tab. A... -
Page 10: Burner Categories - Countries Of Destination
SE - FI - AT - GR - DK - ES - GB - IT - IE - PT - IS - CH - NO 2ELL (43,46 ÷ 45,3 MJ/m (0°C)) 2E(R)B LU - PL Tab. B Technical data Model RS 1300/EV C01 FS1 RS 1600/EV C01 FS1 RS 2000/EV C01 FS1 Type S001T2 S006T2 S007T2 Power min - max... -
Page 11: Packaging Dimensions And Burner Weight
Bear in mind that inspection of the combustion head requires the burner to be opened and the rear part turned on the hinge. The l position is reference for the refractory thickness of the boiler door. 20094543 Fig. 2 RS 1300/EV C01 FS1 1880 DN 80 1585 1463 1782... -
Page 12: Firing Rates
1013 mbar (approx. 0 m limit of the diagram: a.s.l.), and with the combustion head adjusted as WARNING RS 1300/EV C01 FS1 = 2500 kW shown on page 21. RS 1600/EV C01 FS1 = 3065 kW RS 2000/EV C01 FS1 = 4000 kW... -
Page 13: Burner Description
Technical description of the burner 4.10 Burner description 20094547 Fig. 5 Lifting rings 17 Air damper movement levers 18 Minimum air pressure switch (differential operating type) Fan motor 19 Combustion head air pressure test point Air damper servomotor 20 Rpm sensor Ignition pilot burner 21 QRI cell Combustion head... -
Page 14: Electrical Panel Description
Technical description of the burner 4.11 Electrical panel description 20094548 Fig. 6 Supply cables, external connections and kits 15 Servomotors axillary transformer fuses Volt-free contacts output relay 16 Auxiliary circuits fuse Electronic cam transformer 17 Flame sensor plug/sensor socket Electronic control box 18 Main terminal supply board Ignition transformer 19 Air pressure switch... -
Page 15: 4.13 Azl Display
The AZL ... display is a safety device! Avoid open- WARNING ing or modifying it, or forcing its operation. Riello S.p.A. cannot assume any responsibility for dam- age resulting from unauthorised interventions! The electronic cam is operated and programmed through the AZL5 interface... -
Page 16: Control Box For The Air/Fuel Ratio (Lmv52
Technical description of the burner 4.14 Control box for the air/fuel ratio (LMV52...) Warnings – avoid conditions that can favour the development of conden- sate and humidity. Otherwise, before switching on again, To avoid accidents, material or environmental make sure that the entire control box is perfectly dry! damage, observe the following instructions! –... - Page 17 Technical description of the burner Electrical wiring of the flame detector – Line capacitance reduces the magnitude of the flame signal. – Use a separate cable. It is important for signal transmission to be almost totally free of any disturbances or loss: •...
-
Page 18: 4.15 Servomotor
Technical description of the burner 4.15 Servomotor Warnings To avoid accidents, material or environmen- tal damage, observe the following instruc- tions! WARNING Avoid opening, modifying or forcing the ac- tuators. All interventions (assembly and installation operations, assistance, etc.) must be carried out by qualified personnel. ... -
Page 19: Installation
Installation Installation Notes on safety for the installation After carefully cleaning all around the area where the burner is to The installation of the burner must be carried out be installed, and arranging for the environment to be illuminated by qualified personnel, as indicated in this manual correctly, proceed with the installation operations. -
Page 20: Operating Position
Installation Operating position The burner is designed to work only in posi- Any other position could compromise the cor- tions 1 and 4 (Fig. 11). rect operation of the appliance. Installation 1 is preferable, as it is the only ... -
Page 21: Blast Tube Length
Installation 5.6.2 Blast tube length This protective fettling must not compromise the extraction of the blast tube. The length of the blast tube must be selected according to the in- For boilers with a water-cooled front piece, a refractory lining 2)- dications provided by the manufacturer of the boiler, and in any 5)(Fig. -
Page 22: Access To Head Internal Part
Installation Access to head internal part In order to reach inside the combustion head (Fig. 16) proceed as disconnect the cable of the pilot electrode 4); follows: open the burner fully; disconnect the gas servomotor socket 1); ... -
Page 23: Gas Feeding
Installation 5.11 Gas feeding Explosion danger due to fuel leaks in the pres- MBC “threaded” ence of a flammable source. Precautions: avoid knocking, attrition, sparks and heat. Make sure the fuel interception tap is closed be- fore performing any operation on the burner. The fuel supply line must be installed by qualified personnel, in compliance with current standards and laws. -
Page 24: 5.11.2 Gas Train
Installation 5.11.2 Gas train 1 p (mbar) 2 p (mbar) Approved according to standard EN 676 and provided separately G 20 G 25 G 20 G 25 from the burner. 9500 10000 5.11.3 Gas train installation 10500 11100 Disconnect the electrical power using the main switch. -
Page 25: 5.11.5 Pilot - Gas Train Connection
5.11.6 Ignition pilot burner For proper operation, adjust gas pressure (measured at pressure test point 1)(Fig. 24) as follows: Model mbar RS 1300/EV C01 FS1 RS 1600/EV C01 FS1 RS 2000/EV C01 FS1 Tab. K Check pilot flame stability before starting up the 20094558 main burner. -
Page 26: Electrical Wiring
Installation 5.12 Electrical wiring Notes on safety for the electrical wiring The electrical wiring must be carried out with the electrical supply disconnected. Electrical wiring must be made in accordance with the regulations currently in force in the country of destination and by qualified personnel. -
Page 27: 5.12.2 Shielding The Connections
Installation 5.12.2 Shielding the connections For the burner to operate correctly, where re- quired, it is necessary to shield the connections. WARNING To shield the motor connection, proceed as follows: to access the motor casing, loosen the four screws 1)(Fig. -
Page 28: Start-Up, Calibration And Operation Of The Burner
Start-up, calibration and operation of the burner Start-up, calibration and operation of the burner Notes on safety for the first start-up The first start-up of the burner must be carried out Check the correct working of the adjustment, com- by qualified personnel, as indicated in this manual mand and safety devices. -
Page 29: Burner Ignition
Start-up, calibration and operation of the burner Burner ignition The burner should light after having performed the above steps. In the event the burner stops, in order to prevent If the motor starts up, but the flame does not appear and the con- any damage to the installation, do not unblock the trol box goes into lockout, reset it and wait for a new ignition at- burner more than twice in a row. -
Page 30: Pressure Switch Adjustment
Start-up, calibration and operation of the burner Pressure switch adjustment 6.6.1 Air pressure switch - check CO Adjust the air pressure switch after performing all other burner adjustments with the air pressure switch set to the start of the scale (Fig. 31). With the burner operating at MIN output, insert a combustion analyser in the stack, slowly close the suction inlet of the fan (for example, with a piece of cardboard) until the CO value does not... -
Page 31: Pvp Pressure Switch Kit
Start-up, calibration and operation of the burner 6.6.4 PVP pressure switch kit Adjust the pressure switch for the leak detection control (PVP kit) (Fig. 34) according to the instructions supplied with the kit. D3855 Fig. 34 Final checks (with burner operating) ... -
Page 32: Maintenance
Maintenance Maintenance Notes on safety for the maintenance The periodic maintenance is essential for the good operation, safety, yield and duration of the burner. Turn off the burner's power supply using the main It allows you to reduce consumption and polluting emissions and system switch. -
Page 33: Electrical Panel
Maintenance Voltage on the QRI cell Minimum value for correct operation: 3.5V DC (value on AZL dis- play at about 50%). If the value is lower, it could be due to: – cell not positioned correctly – low voltage (lower than 187V) –... -
Page 34: Safety Components
Maintenance 7.2.6 Safety components The safety components should be replaced at the end of their life cycle indicated in the following table. The specified life cycles do not refer to the warranty terms indi- cated in the delivery or payment conditions. Safety component Life cycle 10 years or 250.000... -
Page 35: Opening The Burner
Maintenance Opening the burner Remove the gas pressure switch connection 1)(Fig. 38). Disconnect the socket 3) of the gas servomotor. Turn off the burner's power supply using the main Remove the screws 2). system switch. Open the burner partially; DANGER ... -
Page 36: Faults - Possible Causes - Solutions
Faults - Possible causes - Solutions Faults - Possible causes - Solutions If faults arise in ignition or operations, the burner performs a “safety stop”, which is signalled by the red burner lockout LED. The display visualises alternately the lockout code and the rela- tive diagnostic. -
Page 37: A Appendix - Accessories
Type Code Temperature - 100...+ 500°C PT 1000Ni1000 3010377 Inverterkit (VSD) Burner Electrical Inverter Output Code RS 1300/EV C01 FS1 3Ph/400V/50Hz 30 kW 20030338 RS 1600/EV C01 FS1 3Ph/400V/50Hz 37 kW 20095475 RS 2000/EV C01 FS1 3Ph/400V/50Hz 45 kW 20095476 The use of inverters other than those indicated by the manufacturer may lead to burner failure and, in extreme cases, a potential risk of harm to people and damage to property. -
Page 38: Appendix - Electrical Panel Layout
Appendix - Electrical panel layout Appendix - Electrical panel layout Index of layouts Indication of references Layout of unifilar output LMV52..operational layout LMV52..operational layout LMV52..operational layout LMV52..operational layout LMV52..operational layout LMV52..operational layout LMV52..operational layout LMV52.. - Page 39 Appendix - Electrical panel layout 20089633...
- Page 40 Appendix - Electrical panel layout 20089633...
- Page 41 Appendix - Electrical panel layout 20089633...
- Page 42 Appendix - Electrical panel layout 20089633...
- Page 43 Appendix - Electrical panel layout 20089633...
- Page 44 Appendix - Electrical panel layout 20089633...
- Page 45 Appendix - Electrical panel layout 20089633...
- Page 46 Appendix - Electrical panel layout 20089633...
- Page 47 Appendix - Electrical panel layout 20089633...
- Page 48 Appendix - Electrical panel layout 20089633...
- Page 49 Appendix - Electrical panel layout 20089633...
- Page 50 Appendix - Electrical panel layout 20089633...
- Page 51 Appendix - Electrical panel layout 20089633...
- Page 52 Appendix - Electrical panel layout Wiring layout key Control box XSM1 Servomotor connector SM3 Display for control box XVP1 Connector VP1 Output probe in current XVP2 Connector VP2 Output device in current to modify remote setpoint Main terminal supply board Load indicator with input under current Terminal board kit O Device with current output for remote modulation...
