- Page 1 Installation, use and maintenance instructions Forced draught gas burners Modulating operation CODE MODEL TYPE 20124422 RS 1300/E BLU S008T1 20124358 RS 1600/E BLU S009T1 20104154 RS 2000/E BLU S010T1 20126903 (3) - 12/2021...
- Page 2 Translation of the original instructions...
-
Page 3: Table Of Contents
Contents Declarations....................................3 Information and general warnings............................4 Information about the instruction manual ........................4 2.1.1 Introduction.................................. 4 2.1.2 General dangers................................4 2.1.3 Other symbols ................................4 2.1.4 Delivery of the system and the instruction manual...................... 5 Guarantee and responsibility............................5 Safety and prevention................................ - Page 4 Contents Combustion air adjustment ............................27 6.5.1 Air / gas adjustment and output modulation.......................27 Pressure switch adjustment ............................28 6.6.1 Air pressure switch - check CO..........................28 6.6.2 Maximum gas pressure switch...........................28 6.6.3 Minimum gas pressure switch............................28 6.6.4 PVP pressure switch kit .............................29 Final checks (with burner operating) ..........................29 Maintenance ....................................30 Notes on safety for the maintenance .........................30...
-
Page 5: Declarations
Declarations Declarations Declaration of Conformity in accordance with ISO / IEC 17050-1 These products are in compliance with the following Technical Standards: • EN 12100 • EN 676 According to the European Directives: 2006/42/EC Machine Directive 2014/35/EU Low Voltage Directive EMC 2014/30/EU Electromagnetic Compatibility The quality is guaranteed by a quality and management system certified in accordance with ISO 9001:2015. -
Page 6: Information And General Warnings
Information and general warnings Information and general warnings Information about the instruction manual 2.1.1 Introduction WARNING: MOVING PARTS The instruction manual supplied with the burner: This symbol indicates that you must keep limbs is an integral and essential part of the product and must not away from moving mechanical parts;... -
Page 7: Delivery Of The System And The Instruction Manual
Information and general warnings 2.1.4 Delivery of the system and the instruction The system supplier must carefully inform the user about: – the use of the system; manual – any further tests that may be required before activating the When the system is delivered, it is important that: system;... -
Page 8: Safety And Prevention
Safety and prevention Safety and prevention Introduction The burners have been designed and built in compliance with the type and pressure of the fuel, the voltage and frequency of the current regulations and directives, applying the known technical electrical power supply, the minimum and maximum deliveries for rules of safety and envisaging all the potential danger situations. -
Page 9: Technical Description Of The Burner
110/50/60 110V / 50-60Hz 1600 3/400/50 230/50/60 BASIC DESIGNATION EXTENDED DESIGNATION Models available Designation Voltage Start-up Code RS 1300/E BLU FS1 3/400/50 Direct/Inverter 20124422 RS 1600/E BLU FS1 3/400/50 Direct/Inverter 20124358 RS 2000/E BLU FS1 3/400/50 Direct/Inverter 20104154 Tab. A... -
Page 10: Burner Categories - Countries Of Destination
SE - FI - AT - GR - DK - ES - GB - IT - IE - PT - IS - CH - NO 2ELL (43.46 ÷ 45.3 MJ/m (0°C)) 2E(R)B LU - PL Tab. B Technical data Model RS 1300/E BLU FS1 RS 1600/E BLU FS1 RS 2000/E BLU FS1 Type S008T1 S009T1 S010T1 Power min - max 2500/7500 ÷... -
Page 11: Packaging Dimensions And Burner Weight
Bear in mind that inspection of the combustion head requires the thickness of the boiler door. burner to be opened and the rear part turned on the hinge. 20128338 20094543 Fig. 2 RS 1300/E BLU FS1 1880 DN 80 1585 1463 1782... -
Page 12: Firing Rates
1013 mbar (approx. 0 m limit of the diagram: a.s.l.), and with the combustion head adjusted as WARNING RS 1300/E BLU FS1 = 2500 kW shown on page 21. RS 1600/E BLU FS1 = 3065 kW RS 2000/E BLU FS1 = 4000 kW... -
Page 13: Burner Description
Technical description of the burner 4.10 Burner description 20129689 Fig. 5 Lifting rings The burner can be opened to the right or to the left without links to the fuel supply side. Fan motor When the burner is closed, the hinge pin can be Air damper servomotor CAUTION refitted on the opposite side. -
Page 14: Electrical Panel Description
Technical description of the burner 4.11 Electrical panel description 20097200 Fig. 6 Supply cables, external connections and kits 17 Flame sensor plug/sensor socket Volt-free contacts output relay 18 Main terminal supply board Electronic cam transformer 19 Air pressure switch Electronic control box 20 Kit terminal board Ignition transformer 21 Timer... -
Page 15: 4.13 Azl Display
The AZL ... display is a safety device! Avoid open- WARNING ing or modifying it, or forcing its operation. Riello S.p.A. cannot assume any responsibility for dam- age resulting from unauthorised interventions! The electronic cam is operated and programmed through the AZL5 interface... -
Page 16: Control Box For The Air/Fuel Ratio (Lmv51
Technical description of the burner 4.14 Control box for the air/fuel ratio (LMV51...) Warnings – avoid conditions that can favour the development of conden- sate and humidity. Otherwise, before switching on again, To avoid accidents, material or environmental make sure that the entire control box is perfectly dry! damage, observe the following instructions! –... - Page 17 Technical description of the burner Electrical wiring of the flame detector – Line capacitance reduces the magnitude of the flame signal. – Use a separate cable. It is important for signal transmission to be almost totally free of any disturbances or loss: •...
-
Page 18: 4.15 Servomotor
Technical description of the burner 4.15 Servomotor Warnings To avoid accidents, material or environmen- tal damage, observe the following instruc- tions! WARNING Avoid opening, modifying or forcing the ac- tuators. All interventions (assembly and installation operations, assistance, etc.) must be carried out by qualified personnel. ... -
Page 19: Installation
Installation Installation Notes on safety for the installation After carefully cleaning all around the area where the burner is to The installation of the burner must be carried out be installed, and arranging for the environment to be illuminated by qualified personnel, as indicated in this manual correctly, proceed with the installation operations. -
Page 20: Operating Position
Installation Operating position The burner is designed to work only in posi- Any other position could compromise the cor- tions 1 and 4 (Fig. 11). rect operation of the appliance. Installation 1 is preferable, as it is the only ... -
Page 21: Blast Tube Length
Installation 5.6.2 Blast tube length This protective fettling must not compromise the extraction of the blast tube. The length of the blast tube must be selected according to the in- For boilers with a water-cooled front piece, a refractory lining 2)- dications provided by the manufacturer of the boiler, and in any 5)(Fig. -
Page 22: Access To Head Internal Part
Installation Access to head internal part In order to reach inside the combustion head (Fig. 16) proceed as open the burner completely; follows: disconnect the electrode pilot cable 7); disconnect the gas servomotor socket 1); release the ignition pilot connector 8); ... -
Page 23: Gas Feeding
Installation 5.11 Gas feeding Explosion danger due to fuel leaks in the pres- MBC “threaded” ence of a flammable source. Precautions: avoid knocking, attrition, sparks and heat. Make sure the fuel interception tap is closed be- fore performing any operation on the burner. The fuel supply line must be installed by qualified personnel, in compliance with current standards and laws. -
Page 24: 5.11.2 Gas Train
Installation 5.11.2 Gas train Approved according to standard EN 676 and provided separately from the burner. 5.11.3 Gas train installation Disconnect the electrical power using the main switch. DANGER 20128345 Check that there are no gas leaks. Fig. 22 Pay attention when handling the train: danger of crushing of limbs. -
Page 25: 5.11.5 Pilot - Gas Train Connection
Installation Example RS 1300/E BLU FS1 with natural gas G20: Operation at maximum modulating output Gas pressure at test point 1)(Fig. 23) 102 mbar Pressure in combustion chamber 10 mbar 102 - 10 92 mbar A pressure of 92 mbar, column 1, corresponds in Tab. J to an out- put of 12200 kW. -
Page 26: Electrical Wiring
Installation 5.12 Electrical wiring Notes on safety for the electrical wiring The electrical wiring must be carried out with the electrical supply disconnected. Electrical wiring must be made in accordance with the regulations currently in force in the country of destination and by qualified personnel. -
Page 27: Calibration Of The Thermal Relay
Installation 5.13 Calibration of the thermal relay The thermal relay (Fig. 26) serves to avoid damage to the motor due to an excessive absorption increase or if a phase is missing. For calibration 2), refer to the table indicated in the electrical lay- out (electrical wiring in charge of the installer). -
Page 28: Start-Up, Calibration And Operation Of The Burner
Start-up, calibration and operation of the burner Start-up, calibration and operation of the burner Notes on safety for the first start-up The first start-up of the burner must be carried out Check the correct working of the adjustment, com- by qualified personnel, as indicated in this manual mand and safety devices. -
Page 29: Burner Ignition
Start-up, calibration and operation of the burner Burner ignition The burner should light after having performed the above steps. In the event the burner stops, in order to prevent If the motor starts up, but the flame does not appear and the con- any damage to the installation, do not unblock the trol box goes into lockout, reset it and wait for a new ignition at- burner more than twice in a row. -
Page 30: Pressure Switch Adjustment
Start-up, calibration and operation of the burner Pressure switch adjustment 6.6.1 Air pressure switch - check CO Adjust the air pressure switch after performing all other burner adjustments with the air pressure switch set to the start of the scale (Fig. 30). With the burner operating at MIN output, insert a combustion analyser in the stack, slowly close the suction inlet of the fan (for example, with a piece of cardboard) until the CO value does not... -
Page 31: Pvp Pressure Switch Kit
Start-up, calibration and operation of the burner 6.6.4 PVP pressure switch kit Adjust the pressure switch for the leak detection control (PVP kit) (Fig. 33) according to the instructions supplied with the kit. D3855 Fig. 33 Final checks (with burner operating) ... -
Page 32: Maintenance
Maintenance Maintenance Notes on safety for the maintenance The periodic maintenance is essential for the good operation, safety, yield and duration of the burner. Turn off the burner's power supply using the main It allows you to reduce consumption and polluting emissions and system switch. -
Page 33: Electrical Panel
Maintenance Voltage on the flame sensor Minimum value for correct operation: 3.5V DC (value on AZL dis- LMV... play at about 50%). X10-02 / 6 If the value is lower, it could be due to: X10-02 / 4 X10-02 / 2 –... -
Page 34: Opening The Burner
Maintenance Opening the burner Turn off the burner's power supply using the main system switch. DANGER Turn off the fuel interception tap. DANGER Wait for the components in contact with heat sources to cool down completely. Disconnect the socket 3) of the gas servomotor. ... -
Page 35: Faults - Possible Causes - Solutions
Faults - Possible causes - Solutions Faults - Possible causes - Solutions If faults arise in ignition or operations, the burner performs a “safety stop”, which is signalled by the red burner lockout LED. The display visualises alternately the lockout code and the rela- tive diagnostic. -
Page 36: A Appendix - Accessories
Appendix - Accessories Appendix - Accessories Probe for checking temperature/pressure Parameter to be checked Probe Adjustment field Type Code Temperature - 100...+ 500°C PT 100 3010110 0...2.5 bar Output probe 3010213 Pressure 0...16 bar 4..20 mA 3010214 Software interface kit Burner Code All models... -
Page 37: B Appendix - Electrical Panel Layout
Appendix - Electrical panel layout Appendix - Electrical panel layout Index of layouts Indication of references Layout of unifilar output Star/delta starter operational layout LMV51..operational layout LMV51..operational layout LMV51..operational layout LMV51..operational layout LMV51..operational layout LMV51..operational layout LMV51.. - Page 38 Appendix - Electrical panel layout 20126903...
- Page 39 Appendix - Electrical panel layout 20126903...
- Page 40 Appendix - Electrical panel layout 20126903...
- Page 41 Appendix - Electrical panel layout & & 20126903...
- Page 42 Appendix - Electrical panel layout 20126903...
- Page 43 Appendix - Electrical panel layout 20126903...
- Page 44 Appendix - Electrical panel layout 20126903...
- Page 45 Appendix - Electrical panel layout 20126903...
- Page 46 Appendix - Electrical panel layout 20126903...
- Page 47 Appendix - Electrical panel layout 20126903...
- Page 48 Appendix - Electrical panel layout 20126903...
- Page 49 Appendix - Electrical panel layout 20126903...
- Page 50 Appendix - Electrical panel layout 20126903...
- Page 51 Appendix - Electrical panel layout 20126903...
- Page 52 Appendix - Electrical panel layout 20126903...
- Page 53 Appendix - Electrical panel layout Wiring layout key Control box Servomotor auxiliary transformer Display for control box Pilot valve 1 Pilot valve 2 Output probe in current Output device in current to modify remote setpoint XAZL AZL display connector Load indicator with input under current XAUX Auxiliary terminal board Device with current output for remote modulation...
- Page 56 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.riello.com Subject to modifications...
