Summary of Contents for IKEA EFTERSMAK

  • Page 1 EFTERSMAK...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use Environmental concerns Clock functions IKEA guarantee Using the accessories Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.
  • Page 5 ENGLISH WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be • activated.

  • Page 6: Safety Instructions

    ENGLISH Safety instructions Installation Ventilation opening 560x20 mm Warning! Only a qualified person minimum size. Open‐ must install this appliance. ing placed on the bot‐ tom rear side • Remove all the packaging. • Do not install or use a damaged Mains supply cable 1500 mm appliance.
  • Page 7 ENGLISH • Do not pull the mains cable to disconnect – do not put water directly into the hot the appliance. Always pull the mains plug. appliance. • Use only correct isolation devices: line – do not keep moist dishes and food in protecting cut-outs, fuses (screw type the appliance after you finish the fuses removed from the holder), earth...

  • Page 8: Installation

    ENGLISH Internal lighting • Use original spare parts only. Warning! Risk of electric shock. Disposal Warning! Risk of injury or • Concerning the lamp(s) inside this suffocation. product and spare part lamps sold separately: These lamps are intended to • Disconnect the appliance from the mains withstand extreme physical conditions in supply.

  • Page 9: Product Description

    ENGLISH Product description General overview Control panel Knob for the heating functions Display Control knob Heating element Lamp Shelf support, removable Shelf positions Accessories For cakes and biscuits. • Grill- / Roasting pan x 1 • Wire shelf x 1 To bake and roast or as pan to collect fat.

  • Page 10: Before First Use

    ENGLISH Display A. Timer / Temperature B. Heat-up and residual heat indicator C. Core temperature sensor (selected models only) D. Door lock (selected models only) E. Hours / minutes F. Demo mode (selected models only) G. Clock functions Before first use Using the Mechanical child lock Warning! Refer to Safety chapters.

  • Page 11: Daily Use

    ENGLISH Warning! Be careful not to scratch the control panel. Daily use Warning! Refer to Safety Heating func‐ Application chapters. tion Retractable knobs To bake pizza. To make in‐ tensive browning and a To use the appliance press the knob. The crispy bottom.

  • Page 12: Clock Functions

    ENGLISH Heating func‐ Application Heating func‐ Application tion tion This function is designed to To turn on the lamp without save energy during cook‐ a cooking function. It can be ing. For the cooking instruc‐ used with residual heat in fi‐ Eco Fan Light tions refer to "Hints and...
  • Page 13 ENGLISH 3. Turn the control knob to set the minutes Clock function Application and press to confirm. Turn the control Use to set a countdown knob to set the hours and press time. This function has no MINUTE MIND‐ confirm. effect on the operation of When the set Duration time ends the signal the oven.

  • Page 14: Using The Accessories

    ENGLISH Turn the control knob to set the minutes 1. Press again and again until starts for END time and press to confirm. to flash. 2. Turn the control knob to set the seconds The display shows and the set and than the minutes.

  • Page 15: Additional Functions

    ENGLISH Wire shelf and baking tray / deep pan together: Small indentation at the top increase safety. The indentations Push the baking tray / deep pan between the are also anti-tip devices. The high guide bars of the shelf support and the wire rim around the shelf prevents shelf on the guide bars above.

  • Page 16: Hints And Tips

    ENGLISH overheating. To prevent this, the oven has a power supply. The oven turns on again safety thermostat which interrupts the automatically when the temperature drops. Hints and tips Cooking meat and fish Warning! Refer to Safety Use a deep pan for very fatty food to prevent chapters.
  • Page 17 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Swiss roll baking tray or dripping 25 - 35 Brownie baking tray or dripping 25 - 30 Soufflè, 6 pieces ceramic ramekins on wire 25 - 30 shelf Sponge flan flan base tin on wire shelf 15 - 25 base...
  • Page 18 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Vegetarian ome‐ pizza pan on wire shelf 25 - 30 lette Vegetables, baking tray or dripping 25 - 30 mediterrean 0.7 Eco Fan Cooking - recommended accessories Use the dark and non-reflective tins and containers.
  • Page 19 ENGLISH Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Small Convention‐ Baking 20 - 30 Put 20 small cakes cake al (Top and tray per one baking Bottom tray. Heat) Small Forced Air Baking 150 - 20 - 35 Put 20 small cakes cake...

  • Page 20: Care And Cleaning

    For additional cooking tables please refer to cavity. the Recipe Book which you can find on the website www.ikea.com. To find the proper Care and cleaning Warning! Refer to Safety chapters.
  • Page 21 ENGLISH Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dish‐ washer. Do not clean the non-stick accessories using abrasive cleaner or sharp- Accessories edged objects.
  • Page 22 ENGLISH installation the surface of the glass panel frame on the screen-printing zones is not rough when you touch it. When installed correctly the door trim clicks. 6. Pull the door trim to the front to remove 7. Hold the door glass panels by their top edge and carefully pull them out one by one.

  • Page 23: Troubleshooting

    ENGLISH Back lamp Step 1 Turn the glass cover to remove it. Step 2 Clean the glass cover. Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp. Step 4 Install the glass cover. Troubleshooting Warning! Refer to Safety chapters.

  • Page 24: Technical Data

    ENGLISH Problem Possible cause Remedy The display shows an error There is an electrical fault. • Deactivate the oven with code that is not in this table. the house fuse or the safety switch in the fuse box and activate it again. •...

  • Page 25: Energy Efficiency

    50 - 60 Hz Number of functions Energy efficiency Product Information and Product Information Sheet* Supplier's name IKEA Model identification EFTERSMAK 604.118.81 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, convention‐ 0.93 kWh/cycle al mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle...

  • Page 26: Environmental Concerns

    IKEA. This guarantee at IKEA. The original sales receipt is required applies to domestic use only. The exceptions as proof of purchase. If service work is are specified under the headline “What is not...
  • Page 27 ENGLISH What will IKEA do to correct the problem? • The use of the appliance in a non- domestic environment i.e. professional IKEA appointed service provider will examine use. the product and decide, at its sole discretion, • Transportation damages. If a customer if it is covered under this guarantee.
  • Page 28 ENGLISH Please do not hesitate to contact IKEA After SAVE THE SALES RECEIPT! It is Sales Service to: your proof of purchase and required for the guarantee to 1. make a service request under this apply. Note that the receipt guarantee;...
  • Page 29 Magyarország 06-1-252-1773 Belföldi díjszabás Hétköznap 8.00 és 17.00 óra között 050-7111267 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg +31 507111267 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00 (internationaal) Norge l i t Österreich...
  • Page 32 21552 © Inter IKEA Systems B.V. 2022 AA-2048780-5...
