  • Page 1 EFTERSMAK...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use Environmental concerns Clock functions IKEA guarantee Using the accessories Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.

  • Page 5: General Safety

    ENGLISH Keep children and pets away from the appliance when it • operates or when it cools down. Accessible parts may become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance of •...

  • Page 6: Safety Instructions

    ENGLISH Safety instructions Installation Built in depth of the 548 mm Warning! Only a qualified appliance person must install this appliance. Depth with open 1022 mm door • Remove all the packaging. • Do not install or use a damaged Ventilation opening 560x20 mm appliance.
  • Page 7 ENGLISH • The shock protection of live and • Do not let sparks or open flames to come insulated parts must be fastened in such in contact with the appliance when you a way that it cannot be removed without open the door.

  • Page 8: Installation

    ENGLISH • Before replacing the lamp, disconnect Care and Cleaning the appliance from the power supply. Warning! Risk of injury, fire, or • Use only lamps with the same damage to the appliance. specifications. • Before maintenance, deactivate the Service appliance and disconnect the mains plug •...

  • Page 9: Product Description

    ENGLISH Cable Total power (W) Section of the cable Cable types applicable for installation or (mm²) replacement: maximum 2300 3 x 1 H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, maximum 3680 3 x 1.5 H05 V2V2-F (T90), H05 BB-F For the section of the cable refer to the total The earth cord (green / yellow cable) must power on the rating plate.

  • Page 10: Control Panel

    ENGLISH Control panel Buttons Sensor field / Button Function Description OPTIONS To set the clock functions. To check the oven temperature. Use only while a heat- ing function operates. START To start a heating function. To confirm. Display A. Timer / Temperature B.

  • Page 11: Daily Use

    ENGLISH To remove the child lock, open the oven Using the Mechanical child lock door and remove the child lock with the torx The oven has the child lock installed. It is on key. The torx key is in the oven fitting bag. the right side of the oven, below the control panel.
  • Page 12 ENGLISH Heating func- Application Heating func- Application tion tion To bake cakes with crispy This function is designed to bottom and to preserve save energy during cook- food. ing. For the cooking instruc- Bottom Heat Eco Fan tions refer to "Hints and Cooking To roast larger meat joints tips"...

  • Page 13: Clock Functions

    ENGLISH The lamp turns on when the oven operates. function during cooking and press 3. To turn off the oven, turn the knob for confirm. the heating functions to the off position. Turn the control knob to change the Heat-up indicator temperature during cooking.
  • Page 14 ENGLISH 3. Turn the control knob to set the minutes Setting the DURATION function for DURATION time and press 1. Set a heating function. Press confirm. Turn the control knob to set the confirm. hours for DURATION time and press 2.

  • Page 15: Using The Accessories

    ENGLISH After 90% of the set time the signal COUNT UP TIMER sounds. Press again and again until the display 5. When the set time ends the signal shows time without any symbols. sounds for 2 minutes. "00:00" and flash in the display. Press any button to stop the signal.

  • Page 16: Additional Functions

    ENGLISH Additional functions Using the Child Lock When the Child Lock is on the oven cannot (°C) be turned on accidentally. 120 - 195 1. Ensure the knob for the oven functions is in the off position. 200 - 245 2.
  • Page 17 ENGLISH Always stand back from the oven when you deep pan. To prevent the smoke open the oven door. condensation, add water each time after it dries up. When the oven cools down, clean the cavity with a soft cloth. Cooking times Baking cakes Cooking times depend on the type of food,...
  • Page 18 ENGLISH Food Accessories Temperature Shelf posi- Time (min) (°C) tion Victoria Sand- baking dish on wire shelf 40 - 50 wich Poached fish, baking tray or dripping 20 - 25 0.3 kg Whole fish, 0.2 baking tray or dripping 25 - 35 Fish fillet, 0.3 kg pizza pan on wire shelf 25 - 30 Poached meat,...
  • Page 19 ENGLISH absorption than the light colour and Eco Fan Cooking - recommended reflective dishes. accessories Use the dark and non-reflective tins and containers. They have better heat Accessories Size Picture Pizza pan, dark, non-re- 28 cm diameter flective Baking dish, dark, non-re- 26 cm diameter flective Ramekins, ceramic...
  • Page 20 ENGLISH Food Function Accesso- Shelf Tem- Time (min) Comments ries posi- pera- tion ture (°C) Small Forced Air Baking 2 and 150 - 20 - 35 Put 20 small cakes cake Cooking tray per one baking tray. Apple pie Convention- Wire 70 - 90 Use 2 tins (20 cm...

  • Page 21: Care And Cleaning

    For additional cooking tables please refer frame of the oven cavity. to the Recipe Book which you can find on the website www.ikea.com. To find the Care and cleaning Clean the oven cavity after each use. Fat Warning! Refer to Safety accumulation or other food remains may chapters.
  • Page 22 ENGLISH Do not clean the non-stick accessories using aggressive agents, sharp-edged objects or in a dishwasher Stainless steel or aluminium ovens Clean the oven door with a damp cloth or sponge only. Dry it with a soft cloth. Install the removed accessories in the Do not use steel wool, acids or abrasive opposite sequence.
  • Page 23 ENGLISH 3. Close the oven door halfway to the first When the cleaning is completed, install the opening position. Then lift and pull glass panels, the door trim and the oven forward and remove the door from its door, close the levers on the both hinges. seat.

  • Page 24: Troubleshooting

    ENGLISH 1. Turn off the oven. Replacing the lamp 2. Remove the fuses from the fuse box or Put a cloth on the bottom of the interior of turn off the circuit breaker. the oven. It prevents damage to the lamp 3.

  • Page 25: Technical Data

    ENGLISH Problem Possible cause Remedy Steam and condensation You left the dish in the oven Do not leave the dishes in settle on the food and in the for too long. the oven for longer than 15 - cavity of the oven. 20 minutes after the cooking process ends.

  • Page 26: Energy Efficiency

    50 - 60 Hz Number of functions Energy efficiency Product Information and Product Information Sheet* Supplier's name IKEA Model identification EFTERSMAK 304.586.72 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conven- 0.93 kWh/cycle tional mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle...

  • Page 27: Environmental Concerns

    ENGLISH * For European Union according to EU Regulations 65/2014 and 66/2014. For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017, An- nexes A and B. For Ukraine according to 568/32020. Energy efficiency class is not applicable for Russia. EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.

  • Page 28: Ikea Guarantee

    IKEA. LAGAN or TILLREDA - from the original • In case of non-repairable product, the date of purchase of your appliance at IKEA retail value of the replacement will not or from the installation date with maximum exceed the purchase price that was paid...
  • Page 29 IKEA appliance in the dedicated IKEA address, then damage to the product kitchen furniture; that occurs during this delivery will be • ask for clarification on functions of IKEA covered by IKEA. appliances. • Cost for carrying out the initial To ensure that we provide you with the best installation of the IKEA appliance.
  • Page 30 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed contacts and relative national phone numbers. In order to provide You with a quicker service, we recommend that You use the specific phone numbers listed at the end of this manual.
