Generac Power Systems 5622 Specifications

GP SERIES
FEATUREs:
• High performance alternator
• Steel fuel tank with incorporated

fuel gauge

• Mobility kit with locking fold-down handles
and never-flat wheels
• 1-1/4" diameter hardened
steel tube cradle
• Hour meter with maintenance resets
• Circuit breaker protected outlets
• Low-tone muffler
AC Rated Output
AC Maximum Output
AC Voltage
AC Frequency
120 VAC Amperage
240 VAC Amperage
Engine Type and Displacement
Oil Capacity
Low Oil Shutdown
Maximum wattage and current are subject to, and limited by, such factors as fuel Btu content, ambient temperatures, altitude, engine condition, etc. Maximum power decreases about 3.5%
for each 1,000 feet above sea level; and will also decrease about 1% for each 6° C (10° F) above 16° C (60° F) ambient temperature.
COMMERCIAL / RESIDENTIAL PORTABLE GENERATORS
Ratings
5kW / 5000 Watts
6.25 kW / 6250 Watts
120V/240V
60 Hz
Rated 41.6/Max 52.1
Rated 20.8/Max 26.0
Engine
OHV Single Cylinder 389cc
1.1 Qt. (1.16 liter)
Standard
Generac Power Systems, Inc. • P .O. Box 297, Whitewater, WI 53190 • generac.com
©2008 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0178060SBY/Printed in U.S.A. 05.08, rev: 06.08
Fuel Capacity
Run Time @ ½ Load
Assembled Dimensions and Weight
Dimensions L x W x H (inches)
Dimensions L x W x H (mm)
Unit Weight
Residential
Commercial
Outlets
4 x 5-20R
GP5000
Model 05622
Running Watts: 5000
Starting Watts: 6250
Fuel
6.6 Gallons (24.98 liters)
10 Hours
33.5 x 26.5 x 27.5
850.9 x 673.1 x 698.5
180 lbs. (81.6 kg.)
Warranty
2 Year Limited
1 Year Limited
1 x L14-30R
