  • Page 1 MANUAL CMSQ108...

  • Page 2: Safety Precaution

    Thanks for purchasing our APart CMSQ108 speaker. We have put great care and effort in the design in order to bring you high quality sound. The CMSQ108 is an elegant and very natural sounding in-wall/in-ceiling speaker. It easily outperforms many standard cabinet speakers, both in sound quality and appearance.

  • Page 3: Features And Benefits

    Turn your living room walls into a wall of sound, at the highest possible hifi standards, exactly there where you feel at home. CMSQ108 features a 5.5” bass- mid speaker with a paper/Kevlar sandwich cone and a low loss rubber surround.

  • Page 4: Recommended Applications

    If possible, mount the speakers close to the sides of your flatscreen TV, about 1.5 meters or more apart from each other, depending on screen size and listening distance. In general, the listening position and the left and right speaker should form an equilateral triangle and the speaker should be positioned halfway the screen or slightly higher.
  • Page 5 For hifi setups, mount the speakers between 1/2 and 2/3 of total wall height, for walls up to 3 meters height, and stay at least 50 cm clear of adjacent walls. You can also mount the speakers in a ceiling if necessary. Speaker mounting instructions Recommended minimum installation volume is 4 liters.
  • Page 6 Using the cutout template Note: when making the hole in your mounting panel, double check if there are no cables or any other obstructions behind the mounting panel. Cutting the mounting panel without this check might result in damaged infrastructure or power lines.
  • Page 7 The CMS5BBI built-in box Because we want to make the lives of installers easy APart offers a built-in box for our square CMSQ108 speaker. The box is insulated to prevent resonance and is custom-built. Once again, APart proves to be your one stop solution for all your...

  • Page 8: Connecting The Speaker

    Connecting the speaker Use the correct polarity when daisy chaining speakers! When a mistake occurs in your daisy chain, it can severely impact speaker performance as there will be audio-cancellation. The daisy chain options are endless and the setup will depend on the capabilities of your amplifier.

  • Page 9: Specifications

    Specifications Speaker type in-wall/in-ceiling, square mounting frame, two way hifi. Recommended amplifier power 15 to 120 watts per channel Rated RMS power 50 W Nominal impedance 8 Ohms Frequency range 50* – 25000 Hz Sensitivity 87 dB spl (2.83V/1m) Dispersion at 1 kHz, 2 kHz, 4 kHz, 180, 170, 120, 80 8 kHz Crossover frequency and slope...
  • Page 10 Polar diagrams Polar diagram 1000 Hz Polar diagram 2000 Hz Polar diagram 4000 Hz Polar diagram 8000 Hz...

  • Page 11: Warranty Info

    Technical drawing with measurements Warranty info APart-Audio warrants this product to be free of defects in material and workmanship for a period of one year for parts and for a period of one year for labor from the date of original end-user purchase. This warranty is valid only for the original end- user and cannot be transferred.
  • Page 12 Send your ideas or suggestions to suggestions@apart-audio.com Company names, product names, and names of formats etc. are the trademarks or registered trade- marks of their respective owners. © 2011 APart-Audio specifications subject to change without notice. developed by Audioprof nv Industriepark Brechtsebaan 8 bus 1...
