Draper MTC100 Instruction Manual

1.

TECHNICAL DESCRIPTION

NOTE: For safe and effective use of this tyre changer it MUST be securely bolted
down to the floor using suitable fixings.
2.

OPERATION

2.1. BREAKING THE BEAD - FIG. 1

• Remove all wheel weights and tyre valve core to release tyre pressure, lay the wheel flat on the base leg
in front of the bead breaker
• Adjust bead breaker (if required) and position the bead breaker head
wheel rim, using the tyre lever
Repeat around the wheel until bead is free from wheel rim, then turn the wheel over and repeat the
process until the tyre is free from both beads.

2.2. TYRE REMOVAL - FIG. 2

• Lubricate both tyre beads with appropriate tyre soap.
• Mount the wheel onto the support base (valve side up), ensure the locating pin
wheel holes and lock down using the slotted press plate
• Place the flat end of the tyre lever
to the tyre side wall, lever against the cap and rotate the tyre lever in a clockwise direction.
Repeat action on second bead.

2.3. FITTING - FIG. 3

• Lubricate both tyre beads.
• Using the tyre lever foot end, locate between the lower bead and wheel rim, lever against the cap and
rotate clockwise around the cap.
• Repeat action on second bead, then replace valve core, inflate tyre to ensure tyre locates correctly onto
rim (DO NOT exceed maximum allowance tyre pressure) the set tyre pressure to require valve.
• We would recommend that wheel is correctly balanced before use.
DRAPER TOOLS LTD, HURSLEY ROAD, CHANDLER'S FORD, EASTLEIGH, HANTS. SO53 1YF. U.K.
All manuals and user guides at all-guides.com
Manual Tyre Changer
Stock No.16395
INSTRUCTIONS
.
inserted into the force handle
and threaded cap
between the tyre bead and the wheel rim, while applying pressure
DBKC0516
Tyre bar
Support plate
Clevis pin
Bolt M10x25
Flat washer Ø10
Lock washer Ø10
Nut M10
Long leg
Short leg
Pedestal
Bead breaker
Locking pin
Force handle
Slotted press plate
Threaded cap
Locating pin
Bead breaker head
WARNING:
Extreme caution must be used if
attempting to replace tyres on
alloy wheels.
This machine is designed to be
used on steel wheels and Draper
Tools Ltd accepts no responsibility
for any damage to wheels or tyres.
between tyre wall and
and lever down to break the bead.
is through one of the
.
drapertools.com
Part No.MTC100
x1
x1
x2
x4
x4
x4
x4
x1
x1
x1
x1
x2
x1
x1
x1
x1
x1
FIG.1
FIG.2
FIG.3
e-mail: sales@drapertools.com
