Takegawa 09-12-1010 Instruction Manual

・Thank you for purchasing one of our TAKEGAWA-made products. Please strictly follow the following instructions in installing and using the parts.
・Before installing the products, please be sure to check the their contents. Should you have any questions about the products, please contact your
local motorcycle dealer.
○ This rear stand, for performing maintenance of motorcycles, is made of lightweight aluminum, coming with a caster.
○ This maintenance stand weighs as light as about 2 kg, and is strong and rigid, being made of aluminum.
○ The width of the stand is adjustable in 5 steps from 222 mm to 258 mm to meet the swing arm width.
This rear stand matches any kinds of swing arms from a stock swing arm on the Monkey and Ape to our aluminum swing arm.
○ The rubber hook of the bracket is anti-slip finished with grooves. And the caster with 6 spokes comes in two colors: clear red and black.
Both the rubber hook and the caster have an original logo on each of them.
○As this rear stand is designed for use with 12-inch or smaller tires, it is compact in size and light in weight. This stand is for mini bikes only, being easy
to handle even when loading onto a space-limited car.
Read all instructions first before starting the installation.
◎This stand is designed and manufactured solely for motorcycle maintenance. Therefore, do not place this stand under the weight of more than the
body weight such as getting on the motorcyle or kick-starting with the motorcycle placed on the stand. Otherwise, the stand may get damaged or
break.
◎ As the caster is attached to this product, be sure to use this stand on level, even ground.
◎ We do not take any responsibility for any accident or damage whatsoever arising from the use of the products not in conformity with the instructions
in this manual.
◎ We shall be held free from any responsibility or compensation whatsoever for any glitch in the parts other than ours if the glitch takes place after the
installation and use of these products.
◎ If you make modifications to any product, we shall be held free from any guarantee of the product.
The following show the envisioned possibility of human death or serious injuries to human bodies as a result of disregarding the
WARNING
following warnings.
・Always start the engine in a well-ventilated place, and do not turn on the engine in an airtight place.
(Otherwise, you will suffer from carbon monoxide poisoning.)
・Before doing work, make sure your motorcycle is secure on level ground for safety's sake.
(Otherwise, your motorcycle could overturn and injure you while you are working.)
・Keep plastic bags for packing the products out of children's reach, or discard them.
(If children get them on, there will be a danger of their suffocating.)
◎ Please be informed that, mainly because of improvement in performance, design changes, and cost increase, the product specifications and
prices are subject to change without prior notice.
◎ This manual should be retained for future reference.
Instruction Manual for
Aluminum Rear Stand with Caster
〜 Features 〜
：０９−１２−１０１０
Item No.
：for general use, but limited to bikes
Fits
with tire sizes of 8 to 12 inches
‑ 1 ‑
Mar./29/ 07
