Page 2: Technical Data
HLP-V Series ■ Contents Safety Safety regulations Warning against unintended start Installation of mechanical brake Technical data General technical data Electrical data Fuses Dimensions Mechanical dimensions Installation Mechanical installation Electrical installation - mains supply Safety grounding Extra protection (RCD) RFI switch Installation of motor cables Connection of motor Direction of motor rotation... - Page 3 HLP-V Series Programming Operation & Display Load and motor References and limits Parameters - Inputs and outputs Special functions Parameters - Serial communication Parameters - Technical functions and diagnostics Messages Trouble-shooting Display - Status messages Warnings and alarms Warnings Parameters...
- Page 4 HLP-V Series Holip-V Series Instruction Manual This Instruction Manual can be used for all Holip-V Series adjustable frequency drives. The software version number can be seen from parameter 624. The HLP-V Adjustable Frequency Drive It is the responsibility of the user or the contains dangerous voltages when con- person installing the Holip to provide nected to line voltage.
-
Page 5: Safety Regulations
HLP-V Series ■ Safety regulations ■ Warning against unintended start 1. The frequency converter must be disconnected 1. The motor can be brought to a stop by means of from mains if repair work is to be carried out. Check digital commands, bus commands, references or that the mains supply has been disconnected and a local stop, while the adjustable frequency drive... - Page 6 HLP-V Series ■ HLP-V series namelate explanation MODEL: HLPV4040EBC3DV10 INPUT: 3PH380-440V 50/60Hz OUTPUT: 3PH380-440V 61A,73A/55.6KVA Freq-Range: 0~1000Hz HOLIP ELECTRONIC TECHNOLOGY CO., LTD.
-
Page 7: General Technical Data
HLP-V Series ■ General technical data AC line supply (R,S,T): 3 x 380/400/415/440 V ±10% Supply voltage 380-440 V units Supply frequency 48-62 Hz +/- 1 % Max. imbalance of supply voltage: ±2.0% of rated supply voltage HLP-V 4015-4550V True Power factor () 0.90 nominal at rated load Displacement Power Factor (cos .) near unity (>0.98) - Page 8 HLP-V Series Contorl card, analog inputs: No. of programmable analog voltage inputs/thermistor inputs Terminal no. 53, 54 0 - ±10 V DC (scalable) Voltage level Input resistance, Ri 10 No. of programmable analog current inputs Terminal no. 0/4 - ±20 mA (scalable) Current range Input resistance, Ri Resolution...
- Page 9 HLP-V Series Maximum load to ground (terminal 39) at analog output Accuracy of analog output Max. error: 1.5% of full scale Resolution on analog output. 8 bit Reliable galvanic isolation: All digital and analog outputs are galvanically isolated from the supply voltage (PELV)*, as well as other inputs and outputs.
- Page 10 HLP-V Series Cable, cross-sections and connectors: Max. cable cross-section for 24 V external DC supply - HLP-V 4015-4100 4 mm /10 AWG - HLP-V 4125-4550 5 mm /12 AWG Max. cross-section for control cables 1.5 mm /16 AWG Max. cross-section for serial communication 1.5 mm /16 AWG Connectors are for use of both copper and aluminium cables, unless other is specified.
