Battery Installation - Logiblocs Spy Kit Inventors Manual

You will need four 1.5 V AA (LR6) batteries.
Open the battery box lid by loosening the large screw underneath
the battery box with a screwdriver or coin and then lifting the lid.
Put the batteries in, starting with the two centre ones. It is best
to put the flat end (-ve) of each battery in first, which depresses
the spring in the battery compartment.
Insert the two lugs into the holes and close the lid.
Do up the screw again. Do not tighten too much !
SCREW
(underneath)
FUSE REPLACEMENT
As an added safety feature there is a 1A fuse contained in the BATTERY
BOX. If in the unlikely event this gets broken you will need to obtain a
replacement BATTERY BOX. Please send the old one back to us, enclosing
your own address and tell us what you think caused the fuse to blow.

BATTERY INSTALLATION

LIFT LID TO
ADD BATTERIES
LOGIBLOCS HERE
JOIN OTHER
25
