- Page 1 Windows Collaboration Display PN-CD701 Installation Guidelines <Ver. 1.0> October 2019 Visual Solutions Unit Business Solutions Division SHARP Corporation Copyright © All rights reserved, SHARP CORPORATION Confidential...
-
Page 2: Table Of Contents
12. How to connect using USB-C Out …20 change according to future evaluation without 13. Notes on setup …21 prior notice. 14. About HIDDEN MENU …23 Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 3: Precautions For Temperature, Clearance And Environment
・Do not use the product where strong light hits such as direct sunlight. Upward >20ｃｍ Downward >5ｃｍ Please install display(s) under the environment which meets Backward >5.5 cm these conditions. (Peripheral devices also should be installed keeping their specifications.) Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 4: Precautions For Opening The Package
After removal of the joints, please lift up the both side of it. box along the longest side. sides of the carton box straight. Back side of inside of the carton box Camera box IoT sensor box Accessories Packaging Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 5: Precautions For Installation And Handling
When the display is temporary put on the desk etc without a stand, please spread a soft sheet under it because the mounting bracket interfere with the desk. ・Please refer to “Mounting precautions (For SHARP dealers and service engineers)” which is described in the operation manual and “Mounting precautions (For SHARP dealers and service engineers)”... - Page 6 In order to lift up the display, such as the move from a packing box to a cart, 4 persons are required. Please check the position and assignment for each worker by referring to the illustration below. Do not touch the USB terminal and the buttons. Copyright © All rights reserved, SHARP CORPORATION Confidential...
-
Page 7: Conditions Of Tilt Angle
* Portrait installation is not supported. ○ < 20 degree 45 degree Installation angle is only supported Installation methods other than vertical are not supported. vertically. Usable ambient temperature range of this display is 5℃-35℃. Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 8: Precautions For A Stand Installation
5. Precautions for a stand installation NOTE : Optional stand has NOT been set for PN-CD701. The stand described in chapter 5 is using only for explanation. Recommended working space We recommend to secure the following space to install the display and the stand. - Page 9 サイズΦ7.5mm以下 (less than or equal to 7.5mm) Screw (M6) 固定用ネジ(M6) VESA compliant screw 固定ボス Captive nut for fixing holes 取付金具 Mounting bracket ディスプレイ Rear cover of Back of the display 背面キャビネット display Copyright © All rights reserved, SHARP CORPORATION Confidential...
- Page 10 *Adjust the display position so as the screw and package. * Lift it vertically because it becomes hard to hang if long hole shares their center. the set inclines Take care that the display does not fall down. Copyright © All rights reserved, SHARP CORPORATION Confidential...
- Page 11 They can cause malfunction. * After move, please confirm that the fixation of stand pillar have not become loose. * After move, please confirm that the screws attached to the display are tight. Copyright © All rights reserved, SHARP CORPORATION Confidential...
-
Page 12: Precautions For Transportation Of Packed Display
In case a cart cannot be used, move the packed display Hold the side of the package so that it will not fall down. by more than persons, with each person holding each side of the package. Copyright © All rights reserved, SHARP CORPORATION Confidential... - Page 13 Height PN-CD701 > 1,850mm > 350mm > 1,200mm 1,200mm In case transportation in landscape position is impossible (the depth of the elevator is short), it may be transported temporary in portrait position. Copyright © All rights reserved, SHARP CORPORATION Confidential...
- Page 14 (In case width of a cart is <350mm and height of a cart is <150mm) Space Width Height PN-CD701 > 1,000mm PN-CD701 > 350mm > 1,400mm Ceiling Wall 1,000mm 1,400mm Wall 1,000mm Wall Wall Wall 350mm Wall Product Cart Copyright © All rights reserved, SHARP CORPORATION Confidential...
- Page 15 Width of the door ： Width of the door Position of the door： Distance between the side wall to the edge of the door ： Tilting angle of the product when carrying in an elevator Angle Copyright © All rights reserved, SHARP CORPORATION Confidential...
-
Page 16: Other Precautions
LAN1 is a terminal for connecting a computer connected to the product via USB-C or USB-B to the network. ・Role of LAN2 LAN2 is used for WSI service. Please check the “10.About WSI(Workspace Intelligence)”. Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 17: Option Parts List
We can’t recommend any parts other than those listed above. Please don’t recommend them for dealers , SIers and end-users. Available options vary depending on the countries and regions. *Planning. But Not yet officially announced. Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 18: System Requirement
Chrome book is supported multi touch(touch digitizer), but Touch pen does not work. ＜Referenced information＞ PN-CD701 , because of featuring 4K resolution, should be recommended the controller which has sufficient ability for 4K resolution. “Sufficient” means -60Hz refresh rate on 4K resolution. -
Page 19: Usb Cable Connection
Please do not connect all I/F(HDMI, USB-B touch cable and USB-C cables) together when a PC is connected. The following combinations are available. Pattern A. USB-C cable Pattern B. HDMI + USB-B cable Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 20: Handling Of Pn-Zu01 (8M Usb-C Cable)
• Do not to be routed inside the building structure (e.g., walls, ceilings, etc.). • If a cable is damaged, never use the cable. • If you connect this cable to PN-CD701, please fix the cable with a clamp. Figure. Fixed the cable The USB-C cable has a “SOURCE”... -
Page 21: How To Connect Using Usb-C Out
PN-CD701 HDMI cable Touch cable (USB-B cable) If you want to touch on the second display, please connect as follows. unit ->However, touch settings on the PC must be set. Copyright © All rights reserved, SHARP CORPORATION Confidential... -
Page 22: Notes On Setup
1.When PN-CD701 is started for the first time, and around 10 minutes to update. the following screen is displayed. If FW of PN-CD701 is the latest FW, skip this section. 2. When you proceed, the network settings will be displayed. Connect the LAN cable to the LAN2 terminal and update the settings to connect to the network. - Page 23 USB memory directly under the root. 3. Insert the USB flash drive into the USB terminal of “FOR CAM”. *If you do not have the tool, please contact an authorized SHARP Figure. OOBE servicing dealer or service center. Copyright © All rights reserved, SHARP CORPORATION...
-
Page 24: About Hidden Menu
2.Click “Admin” text 10 times to enable HIDDEN MENU. 4.Whiteboard Title Only. Not Available 5.Application Display the list of apps installed on PN-CD701. 6.Update Channel This is the setting for debugging. Be sure to set it to “stable”. Do not change to “Canary”. - Page 25 Copyright © All rights reserved, SHARP CORPORATION Confidential...
