- Page 1 PN-CD701 LCD MONITOR OPERATION MANUAL...
- Page 2 Batteries are collected at points of sale. Return is free of charge. If the equipment has been used for BUSINESS PURPOSES, please contact your SHARP dealer who will inform you about take-back. You might be charged for the costs arising from take-back. Small equipment (and small quantities) might be taken back by your local collection facility.
-
Page 3: Important Information
IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within CAUTION a triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” RISK OF ELECTRIC within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric... -
Page 4: Dear Sharp Customer
DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. - Page 5 SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only.
-
Page 6: Tips And Safety Instructions
- Never rub or tap the monitor with hard objects. so could result in electric shock. - Please understand that SHARP CORPORATION bears no - Unplug the power cord if it is not used for a long time. responsibility for errors made during use by the customer or... -
Page 7: Mounting Precautions
• Since the monitor is heavy, consult your dealer before installing, removing or moving the monitor. • Mounting the monitor on the wall requires special expertise and the work must be performed by an authorized SHARP dealer. You should never attempt to perform any of this work yourself. Our company will bear no responsibility for accidents or injuries caused by improper mounting or mishandling. -
Page 8: Table Of Contents
Specifications ..............31 Remote control operation range .........15 Turning Power On/Off ............16 Intellectual Property Rights and Other Matters ..35 Turning on the main power.........16 Mounting Precautions Turning power on ............16 (For SHARP dealers and service engineers) ....36 Turning power off ............16... -
Page 9: Supplied Components
* The remote control unit is supplied with the PN-ZR02 (optional). (Remote control sensor box is not used.) * SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission. * For environmental protection! Do not dispose of batteries in household waste. Follow the disposal instructions for your area. -
Page 10: Part Names
Part Names nFront view 9 10 11 12 13 3 4 5 6 7 1. USB port for external source (USB 3.0 compliant) (See 8. INPUT button (See page 21.) page 13.) 9. MENU button (See page 21.) 2. Pen Tray (See page 17.) 10. - Page 11 Part Names 24. HDMI input terminal (See page 12.) 25. Vents 26. AC input terminal (See page 15.) 27. Main power switch (See page 16.) 28. USB Type C output terminal (See page 13.) 29. USB port for storage expansion (USB 3.0 compliant) (See page 13.) 30.
-
Page 12: Connecting Peripheral Equipment
Connecting Peripheral Equipment nRear view nFront view 1. USB Type C 1 input terminal Caution 2. USB Type C 2 input terminal • Be sure to turn off the main power switch and disconnect • Use the USB Type C cable (supplied). the plug from the power outlet before connecting/ • You can connect a device that supports DisplayPort disconnecting cables. Also, read the manual of the alternate mode. - Page 13 Connecting Peripheral Equipment 8. LAN 2 terminal • You can connect to the Internet by connecting a commercially available LAN cable between this terminal and a network. 9. LAN 1 terminal • By connecting this terminal to a network, you can connect an external device connected via USB to the network. 10. USB port for storage expansion (USB 3.0 compliant) • You can expand the storage used by the main system on this terminal by inserting a commercially available USB storage drive.
-
Page 14: Mounting An Iot Sensor Hub
Mounting an IoT sensor hub It is possible to mount an IoT sensor hub in the following position. IoT sensor hub 1. Attach the supplied IoT sensor hub mounting brackets mounting bracket (L/R) to the IoT sensor hub with the supplied IoT sensor hub screws (M3) (x2). -
Page 15: Connecting The Power Cord
Connecting the Power Cord Caution • Use only the power cord supplied with the monitor. Main power switch 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the power outlet. AC input terminal For power outlet Power cord (Supplied) -
Page 16: Turning Power On/Off
Turning Power On/Off nOperations after first power-on Caution When the monitor is turned on for the first time after being • Turn on the monitor first before turning on the computer or shipped from the factory, the setting screen will be displayed. playback device. Configure the settings according to the screen. • When switching the main power switch or the POWER button off and back on, always wait for at least 5 seconds. -
Page 17: Touch Pen
Touch Pen Eraser TIPS • Incorrect operation may result if your finger is too close to the tip of the pen. • Hold the touch pen with your bare hand. The screen will not respond if you wear a glove. • When multiple touch pens are used, touch positions and touch pen information (color, thickness, etc.) may become interchanged, and lines may break. - When touched simultaneously. - When touch pens are moved near each other. • Do not press the pen tip on other than the screen. This may cause malfunctioning. • If the pen tip becomes worn or damaged, replace the touch pen. To purchase a new touch pen, consult your dealer. -
Page 18: Touch Action
Touch action Touch action Double-tap Same action as double-clicking a mouse. Touch actions that can be used with this monitor differ Quickly touch twice with your finger/touch pen. according to operating system and application. The functions of touch actions are also different. For details, check operating system Help and the application’s support documentation. - Page 19 Touch action nFinger actions Drag-and-drop Same action as drag-and-drop with a mouse. Zoom Touch the screen with your finger/touch pen and move without Use in a screen that is capable of enlargement/reduction. lifting. When you have finished the movement, lift your finger/ Touch the screen with two fingers and move your fingers touch pen.
-
Page 20: Other Functions
Touch action Rotate Use this action in a screen that is capable of image rotation. Touch the center point of the rotation with one finger. While holding that finger still, move another finger in the desired direction of rotation. Move another finger in the desired direction of rotation With one finger touching TIPS... -
Page 21: Basic Operation
Basic Operation Button Operation IoT accessories Operation 1. Camera module Camera module build with camera and Mic array. Which provide conference video function. Camera IoT sensor Hub 5 4 3 1. POWER button See page 16. 2. VOLUME DOWN / UP buttons 2.1 No device connection Controlling this monitor volume up/down. -
Page 22: Using The Remote Control Unit (Option)
Basic Operation Using the remote control unit (option) 1. POWER When “Operation Mode” is set to “Mode1” Press the POWER button to turn the power OFF (standby mode). When “Operation Mode” is set to “Mode2” When you press the POWER button, the brightness will be reduced. -
Page 23: Menu Items
Menu Items Displaying the menu Dashboard Button 1. Home screen The Home Screen is the default screen that users will see when they launch this monitor. Displays the measurement results of the IoT sensor. (Temperature, Humidity, CO2 Levels, TVOC Levels, Motion) Home Button The Home button can be tapped at any time to get the... - Page 24 Menu Items 4. Instruction panel USB Type C instructions HDMI instructions Windows instructions Android instructions The instruction panel is broken down to different sections each with a different purpose. Wired Instructions The wired section will show you the status of the wired connections within each of the boxes.
-
Page 25: Main Function In Action Panel
Menu Items Main function in Action Panel Multi-input source This monitor can detect up to two external sources input. For Multi-input source, this monitor can also The Action Panel can be controlled all panel setting which support PbyP display. including OSD functions and input source switching. The below documentation links provide deeper dive into each button’s expanded content. - Page 26 Menu Items 2. Settings The Settings button will open up the Settings panel and allow the user to change device settings. Quick Settings Volume 0-100% /Mute Mic toggle On/Off Brightness 0-100 Display White Balance On/Off Contrast 0-100% Sharpness 0-100% Color 0-100% Tint 0-100%...
- Page 27 Menu Items Device Information OS/OS Version Model Hardware ID/Serial number Software License Open Source Library Admin Wireless LAN Name Choose A New Wallpaper Choose Install New Apps Choose Country Select Province / Region / State Select City Select Operation Mode Mode1 Power Saving Timeout: 5 mins (Standby mode) In Device Motion Sensor: Off...
- Page 28 Menu Items 2.1 Quick Settings 2.4 System In Quick Settings menu, it can be controlled Volume / System menu is focus on this monitor adjustment Mic toggle / Brightness in both this monitor and external which including High Contrast / Font Size / Time devices.
-
Page 29: Network
Network This monitor can be connected to a LAN. The connection requires a commercially available LAN cable (UTP cable, Category 5, straight through). Network (LAN) LAN 2 terminal LAN cable (commercially available, straight) nSettings to connect to a LAN (LAN 2) 1. -
Page 30: Troubleshooting
Troubleshooting If you are experiencing any problem with your display, before calling for service, please review the following troubleshooting tips. There is no picture or sound. • The power LED is off. - Is power supplied to this monitor? - Is the power cord disconnected? (See page 15.) - Is the main power switch off? (See page 16.) • The power LED lights amber. -
Page 31: Specifications
*4 When “Operation Mode” is set to “Mode1”. When “Operation Mode” is set to “Mode2”: 2.0 W As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from... - Page 32 When mounting the monitor, be sure to use a wall-mount bracket that complies with the VESA-compatible mounting method. SHARP recommends using M6 screws and tighten the screws. Note that screw hole depth of the monitor is 3/8 inch (10 mm). Loose mounting may cause the product to fall, resulting in serious personal injuries as well as damage to the product.
- Page 33 Specifications nCompatible signal timing Screen resolution Vsync HDMI USB Type C VESA 640 × 480 60Hz 72Hz 75Hz 800 × 600 56Hz 60Hz 72Hz 75Hz 848 × 480 60Hz 1024 × 768 60Hz 70Hz 75Hz 1152 × 864 75Hz 1280 × 768 60Hz 75Hz 1280 ×...
- Page 34 Specifications nChannels that can be used in wireless LAN Frequency band Standard Channel (center frequency) EUROPEAN COUNTRIES IEEE802.11b/g/n 1-13ch 2412-2472MHz HONG KONG IEEE802.11ac/a/n 36/40/44/48ch 5180-5240MHz INDIA KUWAIT NEPAL OMAN PHILIPPINES RUSSIA SAUDI ARABIA SINGAPORE SOUTH AFRICA SRI LANKA THAILAND TURKEY UNITED ARAB EMIRATES VIETNAM AUSTRALIA...
-
Page 35: Intellectual Property Rights And Other Matters
The copyrights for the software components and various relevant documents included with this product that were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws. This product also makes use of freely distributed software and software components whose copyrights are held by third parties. -
Page 36: Mounting Precautions (For Sharp Dealers And Service Engineers)
Mounting Precautions (For SHARP dealers and service engineers) • When installing, removing or moving the monitor, ensure that this is carried out by at least 4 people. • Be sure to use a wall-mount bracket designed or designated for mounting the monitor. • This monitor is designed to be installed on a concrete wall or pillar. Reinforced work might be necessary for some materials such as plaster / thin plastic board / wood before starting installation. This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor. - Page 37 PN-CD701 Me EN20A(2)
