3.4 Mounting notes
The MILLENIUM II
! taken into consideration:
- Do not install the unit in an environment that is excessively dusty, conductive, corrosive, gas-
filled, damp, rainy or inflammable, or where there is excessive heat*, excessive shock or
vibration.
- Do not install the module in water or near any possible leaks.
- Protect the module from external debris during installation.
Keep as far away as possible from power cables and equipment. The MILLENIUM II
in enclosures complying with standard DIN 43880.
* To ensure adequate module ventilation, there should be a gap of 10 mm between the front panel and the
enclosure door, and also between the back of the enclosure and the back of the module.
6
4
10
10
71.2
6
4
10
10
NTR 756 D / e
+
series can be installed in any location, but the following points should be
90
4
6
124.6
INSTALLATION MANUAL
60
90
4
6
+
series module can be installed
60
