3. Installation
3.1 DIN rail mounting
The modules can be mounted on 35 mm DIN rails (EN 50022).
(Mounting at the back of the enclosure on a metal grid or mounting in a DIN 43 880 box).
3.2 Panel mounting
Recommended fixing screw diameter: M4.
3.3 Screw terminal connection
The end of the wire should be fitted with a ferrule.
NTR 756 D / e
INSTALLATION MANUAL
Ref.
1
Fixing holes
2
Power supply screw terminal
3
LCD display
4
Input screw terminal
5
Escape key
Slot for memory module or PC
6
cable
7
Scroll buttons
8
Selection button
9
Output screw terminal
Description of front panel
09/2003- 10/13
