- Page 1 LOGIC CONTROLLER INSTALLATION MANUAL NTR 756 D /E...
-
Page 2: Table Of Contents
INSTALLATION MANUAL Table of contents 1. INTRODUCTION .......................... 1 2. HARDWARE DESCRIPTION ....................2 3. INSTALLATION..........................10 4. CONNECTION..........................13 5. USER SAFETY AND PROTECTION OF THE EQUIPMENT..........16 1. Introduction The MILLENIUM II series has been designed for use in the household goods, medical and industrial fields. Each module allows you to manage all the sensors and actuators in the installation. -
Page 3: Hardware Description
INSTALLATION MANUAL 2. Hardware description 2.1 Available part numbers Dimensions Weight Inputs Outputs Type Part numbers Power supply Type Type EC 12 R 88 950 023 100…240 VAC 100…240 VAC RELAY SA 12 R 88 950 043 EC 12 R 88 950 024 SA 12 R 88 950 044... - Page 4 INSTALLATION MANUAL NTR 756 D / e 09/2003- 3/13...
- Page 5 INSTALLATION MANUAL 2.2 Description of power supplies Max. consumption Max. inrush Immunity from Power supplies Specifications current micro power cuts 12 I/O 20 I/O 100…240 VAC -15% +10%, 50/60 Hz 7 VA 8 VA 10 ms 24 VAC -15% +10%, 50/60 Hz 2.5 A 7.5 VA 12 VA...
- Page 6 INSTALLATION MANUAL n 24 VDC Description Description of DC inputs 24 VDC Input voltage -15% +20% Current consumption 3.2 mA (typical) 5.5 mA max Input impedance 6.8 KΩ Level 0 < 5 VDC Level 1 > 15 VDC Response time 5 ms Galvanic isolation Status indication...
- Page 7 INSTALLATION MANUAL n 12 VDC Description Description of DC inputs 12 VDC Input voltage -15% +30% (XT20R -11% +30%) Current consumption 1.9 mA (typical) 2.3 mA max Input impedance 6.45 KΩ Level 0 < 3 VDC Level 1 > 8 VDC Response time 10 ms Galvanic isolation...
- Page 8 INSTALLATION MANUAL 2.4 Description of relay outputs Description Description of relay outputs Max. operating voltage 250 VAC, 30 VDC Max. operating current 8A/point Minimum load 10 mA at 5 VDC Response time 10 ms Type of contact AgNi (cadmium-free) Status indication LCD display Utilization Max.
- Page 9 INSTALLATION MANUAL LCD display Display with 4 lines of 12 characters. NTR 756 D / e 09/2003- 8/13...
- Page 10 INSTALLATION MANUAL Climatic conditions: Type Standard Amplitude Operating temperature IEC 60068-2-14 -5 °C +55 °C Storage temperature IEC 60068-2-1/2 -40 °C +70 °C Relative humidity IEC 60068-2-30 Max. 95% RH, without condensation Degree of protection IEC 60529 IP 20 Atmosphere Absence of corrosive gas.
-
Page 11: Installation
INSTALLATION MANUAL 3. Installation Ref. Description of front panel Fixing holes Power supply screw terminal LCD display Input screw terminal Escape key Slot for memory module or PC cable Scroll buttons Selection button Output screw terminal 3.1 DIN rail mounting The modules can be mounted on 35 mm DIN rails (EN 50022). - Page 12 INSTALLATION MANUAL 3.4 Mounting notes The MILLENIUM II series can be installed in any location, but the following points should be taken into consideration: - Do not install the unit in an environment that is excessively dusty, conductive, corrosive, gas- filled, damp, rainy or inflammable, or where there is excessive heat*, excessive shock or vibration.
- Page 13 INSTALLATION MANUAL NTR 756 D / e 09/2003- 12/13...
-
Page 14: Connection
INSTALLATION MANUAL 4. Connection 4.1 Connection notes The MILLENIUM II series has been designed to be easy to connect. A technician or engineer trained in national and local electrical standards should be able to connect MILLENIUM II series modules to the sensors and actuators without problem. •... - Page 15 INSTALLATION MANUAL 4.4 Input wiring diagram POWER: AC INPUT: AC 100…240 VAC (-15%, +10%) 50/60 Hz 24 VAC (-15%, +10%) Ambient temperature: -5 °C +55 °C Terminals L and N cannot be reversed. (1) fuse or cut-out SA/EC/CN 12 See local SA/EC/CN 20 extension manual EX - XT 20...
- Page 16 INSTALLATION MANUAL 4.5 Output wiring diagram OUTPUT: RELAY Resistive load: 8A 250 VAC/30 VDC SA/EC/CN 12R SA/EC/EX - XT/CN 20R OUTPUT: TRANSISTOR 5…28.8 VDC/0.7A max SA/EC/CN 12S SA/EC/EX - XT/CN 20S NTR 756 D / e 09/2003- 15/13...
-
Page 17: User Safety And Protection Of The Equipment
• All examples and diagrams in this manual are intended to assist understanding. The user is responsible for applying them correctly. Crouzet will not accept any responsibility for the actual use of this product based on these examples. • It is the user’s responsibility to assess the suitability of this product for his applications.
